Important: Read before use. • Importante: Leer antes de usar.
16-Port Gigabit Ethernet
PoE+ Switch with 2 SFP Ports
Instructions
Model 561983 (IPS-16G02-250W )
For additional benets:
or go to: register.intellinet-network.com/r/561983
Scan to
register your
product warranty
2English
Instructions
The Intellinet Network Solutions 16-Port Gigabit Ethernet PoE+ Switch with 2 SFP Ports offers an
array of time-saving, cost-effective features while providing superior network throughput. No
configuration is required and installation is plug and play. With a backplane speed of 36 Gbps,
plenty of performance is available for your computers, servers and other networking devices. Each
of the ports automatically senses the link speed of the connected network device and adjusts to
10, 100 or 1000 Mbps for compatibility and maximum performance. This PoE switch is designed to
provide compatible devices with enough power when needed. It offers up to 30 watts of power
per port until its power budget of 250 watts is reached. The Powered Device Monitor feature
(PDM) restarts any connected PoE device that fails to respond or send out network traffic.
Green Ethernet Technology
This Intellinet Network Solutions switch detects link status to all connected devices and
reduces the power usage of ports not in use. In addition, the switch can adjust the level of
power output based on the length of the network cable connected to a particular port. This
feature allows for the enjoyment of maximum network performance, and when things slow
down, it automatically scales back power usage to conserve energy and save money.
For specifications, visit . Register your product at intellinetnetwork.com
register.intellinet-network.com/r/561983 or scan the QR code on the cover.
Front Panel
LED COLOR STATUS STATUS DESCRIPTION
PWR Green Off Power Off
On Power On
LNK/ACT
(1-16; 17S &
18S [SFP])
Green
Off No device is connected to the port.
On A device is connected to the port.
Flashing Sending or receiving data
PoE (1-16) Orange
Off No powered device (PD) is connected to the port.
On The connected device is receiving power.
Flashing Abnormal power supply
PoE Max Orange On The system has reached a total power output of 200 W.
The PoE total is nearing its maximum level of 250 W.
Cat5e/6/6a/8.x UTP/STP cables provide optimal performance; if a status LED doesn’t indicate
a link or activity, check the corresponding device for proper setup and operation.
Slide Switch
• : default mode; allows normal communication between ports 1 – 18.Default
• : isolates ports 1 – 16 from each other while VLAN
allowing them to connect to ports 17 and 18.
• : set PoE ports to full 10 Mbps and extend Ethernet up to 250 meters (820 ft.).Extend
3
English
Rear Panel
Power
Use the included power cord to connect the device (on the rear panel) to
an AC outlet. The device supports AC 100 – 240 V, 50/60 Hz.
Chassis Ground Column
Located on the side of the power supply connector, a grounding terminal connector is used to
provide proper grounding for your Intellinet Network Solutions switch. If you use the chassis
grounding screw, it should be wired to an object that provides earth ground. In rackmount
installations, grounding is typically provided by the metal frame of the mounting rack.
Placement
Desktop Installation
Prior to use, it is recommended that the switch be placed/positioned on a level surface that
can support the weight of the switch (and possibly other objects) with at least 25 mm (approx.
1”) of clearance for ventilation; away from sources of electrical noise (radios, transmitters,
broadband amplifiers); and within 100 m (approx. 328’) of network devices it’s to be connected
to. Attach the rubber feet to the bottom of each corner of the switch to increase stability.
Rackmount Installation
The switch can be mounted in an EIA standard-sized, 19-inch rack. Attach the mounting brackets
on the switch’s side panels (one on each side) and secure them with the screws provided.
Use the screws provided with the equipment rack to mount the
Intellinet Network Solutions switch to the rack.
Instructions
