Seite 1/31
SOL-CHARGE01 / 02
MANUAL (p. 2 )
Solar Trickle Charger
ANLEITUNG (s. 4 )
Solar-Ladegerät
MODE D’EMPLOI (p. 6 )
Chargeur Solaire
GEBRUIKSAANWIJZING (p. 8 )
Zonnepaneel druppellader
MANUALE (p. 10 )
Caricatore solare
MANUAL DE USO (p. 12 )
Cargador Solar
HASZNÁLATI ÚTMUTATÓ (o. 14 .)
Napelemes töltő
KÄYTTÖOHJE (s. 16 )
Aurinkolaturi
BRUKSANVISNING (s. 18 )
Solladdare
NÁVOD K POUŽITÍ (s. 20 )
Solární nabíječka
MANUAL DE UTILIZARE (p. 22 )
Încărcător solar
ΕΓΧΕΙΡΙΔΙΟ XPHΣ ΣH (σελ. 24 )
Ηλιακός Φορτιστής
BRUGERVEJLEDNING (p. 26 )
Soloplader
VEILEDNING (p. 28 )
Solcellelader
2
ENGLISH
Solar Trickle Charger
Contents:
SOL-CHARGE01
1. Hole for suction cups
2. Suction cups
3. Cable
4. Battery clamps
5. LED indicator
6. Cigarette lighter plug
SOL-CHARGE02
1. Mounting holes
2. Connection cable
3. Battery clamps
4. Cigarette lighter plug
Specifications:
SOL-CHARGE01 SOL-CHARGE02
Power: 1.5 W max. Power: 4.8 W max.
Nominal Voltage: 17.5 V Nominal Voltage: 17.5 V
Current: 125 mA max. Current: 260 mA max.
Dimensions: 340x120x14 mm Dimensions: 352x338x16 mm
Weight: 0.45 kg Weight: 1.5 kg
• Built-in blocking diode
• Easy to install & maintenance-free
• 4 Precut holes for installation & 4 screws
• Supplied with battery clamps and cigarette lighter plug adapter
• 10 ft of cable
Tested under standard conditions: AM1.5, 100 mW/cm², module at 25°C.
Operating Instructions:
Mount the charger so it catches direct sun light. Use the suction caps (SOL-CHARGE01) or screws
(SOL-CHARGE02) to mount the charger.
3
Connect the cable to either the cigarette lighter or directly to the battery. As long as there is sufficient
sunlight, the charger will produce a small electrical current to trickle charge your battery.
The LED will flash when the panel is trickle charging the battery (only for SOL-CHARGE01).
Disconnect the charger before starting the car or driving it. The electrical surges from the car engine
may damage the charger.
Note:
• Some vehicles have tinted windows that seriously affect the performance of the solar charger if it
is positioned behind them. For optimum results, place the charger outside the vehicle in direct
sunlight.
• The charger will not overcharge or damage the battery. Similarly, a blocking diode ensures that
the charger cannot flatten your battery.
• Please note that the charger is designed to trickle charge batteries to compensate for natural
drainage. It is not intended to recharge a completely discharged battery.
• When using the battery clamps, please make sure you connect the charger with the right polarity
to the battery (red = +, black = -)
Safety precautions:
To reduce risk of electric shock, this product should ONLY be
opened by an authorized technician when service is required.
Disconnect the product from mains and other equipment if a
problem should occur. Do not expose the product to water or
moisture.
Maintenance:
Clean only with a dry cloth. Do not use cleaning solvents or abrasives.
Warranty:
No guarantee or liability can be accepted for any changes and modifications of the product or damage
caused due to incorrect use of this product.
General:
Designs and specifications are subject to change without notice.
All logos brands and product names are trademarks or registered trademarks of their respective
holders and are hereby recognized as such.
Keep this manual and packaging for future reference.
Attention:
This product is marked with this symbol. It means that used electrical and electronic products
should not be mixed with general household waste. There is a separate collections system for
these products.
