1. INTRODUCTION
Heatit Z-TRM6 DC is an electronic thermostat with a
potential free relay, designed for boiler control, heat pumps
and actuators. The thermostat can be controlled through
your Z-Wave® network or via the buttons on the front. The
thermostat has a user friendly interface.
Heatit Z-TRM6 DC has 3 modes; Heat - Cool and Eco.
The thermostat fits in standard European junction boxes and
may be used with most System 55 frames. It has a sturdy metal
frame for secure fastening on the junction box. The thermostat
has one built-in room temperature sensor. Two additional
external temperature sensors may also be connected.
Heatit Z-TRM6 DC allows you to set the power metering value
manually.
The thermostat can be set up with multiple associations and
can be used as a master thermostat. It can control up to 10
thermostats and 10 external relays E.g wall plugs.
The device has a built-in potential free relay of max 3A that is
designed for the usage of up to 3x 24VDC actuators.
2. STATEMENT REGARDING PRODUCTS FROM MULTIPLE
MANUFACTURERS
Please read this before installation
This device may be used with all devices certified with the
Z-Wave Plus® certificate and should be compatible with
such devices produced by any manufacturer. Every primary
controller is dierent depending on the manufacturer, their
target audience and intended use/application. Please review
the functionalities implemented by the primary controller you
intend to use with our Z-Wave Plus certified device to ensure
that it provides the necessary controls to take full advantage of
our product’s capabilities.
3. BEHAVIOR WITHIN THE Z-WAVE NETWORK
This device may be operated within any Z-Wave® network
with Z-Wave-certified devices from other manufacturers. All
non-battery-operated nodes within the network will act as
repeaters regardless of manufacturer to increase the reliability
of the network. On delivery, the device does not belong to any
Z-Wave network. The device needs to be added to an existing
network to communicate with the other devices within it.
Devices may also be removed from a network. The add/
remove processes are initiated by the primary controller of the
Z-Wave network.
PRODUCT
DOCUMENTS
HEATIT
Z-TRM6 DC
Installers manual
Firmware version Document version
FW 1.0 2024-B
Article no. Document date
54 305 61
54 305 63 22.02.2024
Org. doc. date 02.01.2024
White RAL 9003
54 305 61
TABLE OF CONTENTS
1. Introduction
2. Statement regarding
products from multiple
manufacturers
3. Behavior within the
Z-Wave network
4. Quick start
5. Disclaimer installation
6. Connections
7. Installation
8. Add/Remove
9. Factory reset
10. Startup
11. Principles of regulation
12. Local settings menu
13. Display menu structure
14. Temperature shown in
display
15. Standby and main screen
16. KWh value in menu
17. Size of load
18. Choice of sensor
19. Selecting sensor value
20. Calibration
21. Brightness
22. Display on/o
23. Display icons
24. Child lock
25. Open window detection
26. Error codes
27. Safety features
28. QR-Code placement (DSK)
29. Security
30. Node information frame
31. Associations
32. Association groups
33. Configuration parameters
34. Command classes
35. Supported command
classes
36. Controlled command
classes
37. Thermostat dimensions
38. Thermostat controls
39. Chart - Display menu
Product info
Black matt
54 305 63
4. QUICK START
1. Switch o the mains voltage (disable the fuse).
2. Open the junction box.
3. Connect the wires according to the description in
Chapter 6; ”Connections”. Optional: Connect external wired
sensors.
4. After verifying the connections, switch on the mains voltage.
5. Set the primary controller in add mode (security/non-
security).
6. Hold the Center button until “OFF” is shown in the display
(approx. 5 seconds).
7. Press the ”+” button once to reach “CON”, and hold the
center button until the display shows a rotating light pattern.
8. The thermostat will display “INCL” when the thermostat is
successfully added. NB! If adding/removing fails, Err (error)
will appear.
5. INSTALLATION DISCLAIMER
Installation must be done by a qualified electrician in
accordance with national building codes. Before installation,
disconnect the power to the device from the mains. During
installation of the device, power to the device must be
disconnected AT ALL TIMES!
6. CONNECTIONS
Max tightening torque for terminal screws: 2Nm.
If the cable used has multiple strands, using a end sleeve is
advised.
The product allows for wiring of cables with a cross section of
up to 1x2.5mm.
The screw terminals are located at the back of the device, and
are accessable at all times.
Floor sensor NTC type 6.8, 10, 12, 15, 22, 33, 47 or 100kΩ.
Default 10kΩ.
External sensor NTC type 6.8, 10, 12, 15, 22, 33, 47 or 100kΩ.
Default 10kΩ.
Out Output.
In Input.
N Power connection (Neutral) 230VAC.
L Power connection (Live) 230VAC.
7. INSTALLATION
To install the thermostat in the junction box, hold the sides of
the display and gently pull outwards to detach the front piece.
Connect all wires according to the correct diagram. Align the
thermostat with the junction box mounting screws, and mount
it into the junction box using 2 screws. Position the thermostat
front over the part mounted in the junction box, then carefully
press the front until it clicks into place.
24VDC
H a Z M DC
heatit.com
230VAC~50/60Hz
3A 24VDC
N
In
L
Out
Ext.
sensor
Floor
sensor
Art. no. 54 305 61
54 305 62
54 305 63
NTC
NTC
Potential-free input
e.g. for boiler control, heat pumps etc.
Heatit Z-TRM6 DC
heatit.com
230VAC~50/60Hz
3A 24VDC
N
In
L
Out
Ext.
sensor
Floor
sensor
Art. no. 54 305 61
54 305 62
54 305 63
NTC
NTC
Potential-free
input
When either of these procedures has been performed, the
thermostat will perform a complete factory reset. The device
will display “RES” for 5 seconds while performing a factory
reset. When “RES” is no longer displayed, the thermostat has
been reset.
Please use this procedure only when the primary controller is
missing or otherwise inoperable.
10. STARTUP
After powering up the device for the first time, all parameters
will have default settings and the thermostat will start by asking
which sensor mode should be used.
11. PRINCIPLES OF REGULATION
The thermostat uses temperature readings retrieved from the
internal sensor and/or from external wired sensors to regulate
the temperature. The thermostat will regulate the temperature
using hysteresis or PWM, based on the setpoint temperature.
To select either “HYST” or “PWM” you can find the “REG” menu
option or use Parameter 13 “REG”.
11.1 Hysteresis
Hysteresis will turn on and o the load based on the hysteresis
value in comparison to the setpoint. You can make changes to
the thermostat hysteresis. You may choose hysteresis values
between 0.3°C and 3.0°C using Parameter 14 “HYST”. The
default setting is 0.5°C. When using waterbased heating we
recommend a hysteresis of 1.0°C.
You may also change the hysteresis by entering the local
settings menu and holding the Center button for 2 seconds
when “REG” is displayed. Here you can choose values
between 0.3 and 3.0.
11.2 Pulse-width modulation PWM
With pulse-width modulation (PWM) regulation enabled, the
thermostat will regulate based on duty cycles. The thermostat
is turned on and o in percentage intervals of the cycle. The
amount of time the relay will be on is based on how far the
measured temperature is from the setpoint.
12. LOCAL SETTINGS MENU
To enter the settings menu, hold the Center button for 5
seconds. The display will display “OFF”. You are now in the
settings menu. While in the settings menu, “SET” will be
displayed in the bottom right of the display. You can now scroll
up and down using the Left and Right buttons. Some options
have submenus. To navigate the submenus, press the Center
button once to enter or exit the submenu. Press the Left and
Right buttons to find your desired value and hold the Center
button for 2 seconds to confirm your selection. “STOR” will
appear to indicate settings are stored.
13. DISPLAY MENU STRUCTURE
See flowchart at the end of this manual.
8. ADD/REMOVE
Please read this before installation
The primary controller/gateway has a mode for adding or
removing devices. Please refer to your primary controller
manual on how to set the primary controller in add/remove
mode. The device may only be added or removed from the
network if the primary controller is in add/remove mode.
When the device is removed from the network, it will NOT
revert to factory settings.
An always listening node must be powered continuously
and reside in a fixed position in the installation to secure the
routing table. Adding the device within a 2 meter range from
the gateway can minimize faults during the Interview process.
There are two ways to add the device to a Z-Wave network.
8.1 Method 1: Standard (Manual)
Add/remove mode is indicated on the device by rotating
LED segments on the display. It indicates this for 90 seconds
until a timeout occurs, or until the device has been added to/
removed from the network. Configuration mode can also be
cancelled by performing the same procedure used for starting
Configuration mode.
1. Hold the Center button for 5 seconds.
The display will show “OFF”.
2. Press the ”+” button once to see “CON” in the display.
3. Start the add/remove device process in your primary
controller.
4. Start the configuration mode on the thermostat by holding
the Center button for approximately 2 seconds.
The device is now ready for use with default settings.
NB! When the device is removed from the gateway, the
parameters are not reset. To reset the parameters, see Chapter
”Factory reset”.
If inclusion fails, please perform a ”remove device” process and
try again. If inclusion fails again, please see “Factory reset”.
8.2 Method 2: SmartStart (Automatic)
SmartStart enabled products may be added to a Z-Wave
network by scanning the Z-Wave QR-Code on the product
if your primary controller supports SmartStart inclusion. No
further action is required and the SmartStart product will be
added automatically after being powered on within range of
the primary controller.
9. FACTORY RESET
Enter the menu by holding the Center button for about 5
seconds, navigate in the menu with the ”+” button til you see
FACT. Press the Center button until you see “-- --” blinking in
the display, then hold for about 5 seconds to perform a reset.
You may also initiate a reset by holding the Right and Center
buttons for 60 seconds.

Produktspezifikationen

Marke: Heatit
Kategorie: Thermostat
Modell: Z-TRM6 DC

Brauchst du Hilfe?

Wenn Sie Hilfe mit Heatit Z-TRM6 DC benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Thermostat Heatit

Heatit

Heatit PRO Bedienungsanleitung

24 September 2024
Heatit

Heatit MULTIREG6 Bedienungsanleitung

24 September 2024
Heatit

Heatit WiFi6 Bedienungsanleitung

5 September 2024
Heatit

Heatit Z-TRM6 DC Bedienungsanleitung

5 September 2024
Heatit

Heatit WiFi Bedienungsanleitung

5 September 2024
Heatit

Heatit External Room Sensor Bedienungsanleitung

5 September 2024
Heatit

Heatit HEAE5430499 Bedienungsanleitung

22 Juli 2024
Heatit

Heatit Z-TRM3 Bedienungsanleitung

13 Januar 2024
Heatit

Heatit Z-Wave Plus Bedienungsanleitung

18 November 2023
Heatit

Heatit Z-Wave Bedienungsanleitung

20 Juni 2023

Bedienungsanleitung Thermostat

Neueste Bedienungsanleitung für -Kategorien-

Siemens

Siemens RDG100T Bedienungsanleitung

16 Oktober 2024
Siemens

Siemens N2264 Bedienungsanleitung

7 Oktober 2024
Honeywell

Honeywell Round on-off T87G1006 Bedienungsanleitung

5 Oktober 2024
Theben

Theben RAM 811 Top - 811 9 901 Bedienungsanleitung

5 Oktober 2024
Siemens

Siemens DESIGO RXA Bedienungsanleitung

5 Oktober 2024
Drayton

Drayton RTS10 Bedienungsanleitung

5 Oktober 2024
Honeywell

Honeywell Day Night Round T8700A Bedienungsanleitung

4 Oktober 2024
Busch-Jaeger

Busch-Jaeger 1097 U Bedienungsanleitung

3 Oktober 2024
Eberle

Eberle RTR-E 3545 Bedienungsanleitung

2 Oktober 2024
Eberle

Eberle RTR 9164 Bedienungsanleitung

2 Oktober 2024
