USER ` S MANUAL
GRATIA P R ESTIGE
2
1
2
3
4
5
6
7
Technical data
–
2
Safety tips
Introduction
–
3
Installation
–
3
Unpacking
–
3
Package content
–
3
Interconnections
–
4
Interconnection
–
4
Hook up the signal source
–
4
Power cord hook up
–
4
Getting started
–
5
TROUBLE-SHOOTING GUIDE
–
5
TECHNICAL DATA
TABL E OF CON T E NTS
Typ: Vacuum tube phono stage
Model: Gratia Prestige, Line: Evolution
Tubes type: 2x ECC82/12AU7
AC supply: Stablilized + toroidal Supreme Audio Grade transformer by Toroidy.pl
Gain MM/MC: 42 dB / 60 dB
Nominal output level: 0,5 V
Input sensitivity MM/MC: 0,5 mV / 4 mV
Total harmonic distortion: <0,1%
Stereo crosstalk MM/MC: >88 dB / >82 dB
Signal-noise ratio MM/MC: >90dB / >86dB
Power consumption: 20W
Net weight 8 kg
Dimensions 355x380x95mm
1
3
- Never place the preamplier near heat sources, such as radiators, heaters or direct sunlight. Ensure adequate ventilation
and airow
- We also warn against exposure of the preamplier to conditions such as very low temperatures and/or high humidity.
- The preamplier should be plugged directly into a wall socket. If you must use an extension cord, please make sure that it
has load parameters sucient to ensure proper handling of current delivery to the device.
- When cleaning, always disconnect the preamplier from the power source. Use a dry, soft cloth. Do not use water or
cleaning agents.
- If your preamplier starts to misbehave or to work incorrectly, if it’s temperature gets too high or you start feeling smoke -
immediately disconnect the device from the mains.
- Due to the risk of exposure to high voltages – please do not open the lid of the preamplier. ATTENTION: This warning
remains in force also in a situation where the device is already disconnected from the wall outlet.
- Always replace fuses in accordance with the original, intended specication.
- Do not make repairs on your own, or adjustments beyond those as described in this manual. Execution of any
unauthorized repairs or modications of the device result in a loss of warranty
Completely rebuilt, vacuum tube version of Fezz Gratia phonostage. Two step signal amplication section is based on well
known operational amplier - Burson Supreme Sound Opamp V5i and two low-noise 12AU7 vacuum tubes. Special design
power supply is based on the Supreme Audio Toroidy.pl transformer. Thanks to the easily accessible vacuum tubes, located
under the sliding glass on the top panel, unit gives the opportunity to create and adjust sound tone according to your own
taste. It`s brilliant dynamics, improved bass response and greater resolution of details make Gratia prestige an undeniable
upgrade compared to previous model. The distinct character of vacuum tubes reveals an unique avor to your audio,
elevating your listening sessions to a level of sophistication that is synonymous with our brand.
INTRODUCTION
SAFE T Y TIPS
3
2
In order to obtain the highest possible sound reproduction quality and for the sake of your own safety,
please kindly refer to the following.
Please kindly check if the packaging of the Gratia Prestige phono stage has not been damaged during transit. If you nd any
damages, please immediately contact your dealer. Remove the preamplier and accessories from the packaging. Make sure
that the content is not damaged.
Do not connect the device to the power supply if it has visible signs of damage on it. Please do not
dispose the original packaging, so as to facilitate possible shipment of the device in the future.
INSTALLAT ION
UNPACK I NG
4
Package contains:
• Gratia Prestige vacuum tube phono stage
• Power cord
• User`s manual
If any of the above items are missing in your package, contact your dealer.
CON TENT S OF T HE PACK A G E
