Large size Fixed Frame Projection Screen
ezFrame Plus Series
User’s Guide
PARTS LIST_
1. 6 pcs (4 top Fram a x e P rts ’s /bottom am m fr e pcs. + 2 side fra e pcs)
2. Tension Rods ox’s 6 pcs (4 t p/bottomrods + 2 side rods)
3. Screen Materialx’s 1 pc
4. Center joints x’s pcs 2
5. Elbow Jointsx’s4pcs
6. x’s pcs Wall brackets 2-4
7. x’s 16 pcs Screws
8. User Guide pc x’s
9. Center Support Bar x’s 1 2 pcs (depending on model – /size)
10. Support joinerx’s 2 4 pcs (depending on model – /size)
11. Fix Plates x’s 30 90 pcs (depending on model – /size)
Note:&Please&make&sure&all&parts&are&included&in&your&package&before&proceeding&to&assemble&your&
Elite&Screens&fixed&frame&projection&screen.&
ASSEMBLING THE FRAME
1. center jointInsert the connector to the horizontal frame pieceand then fasten it with 2screws.
Rev.040114-JA 1 www.elitescreens.com
2. center joint Insertthe other horizontal frame piece to the connectorand then fasten it with 2 screws.
Make sure the frame piece lines up correctly beforeyou tighten the screws completely.
3. Insert both connectors into the long horizontal frame . elbowjoint (fig.1)
4.
Push
Push
Short frame
Short frame
Push Push
Joint
Long frame
( fig.1)
1/2Long frame
Push
Rev.040114-JA 2 www.elitescreens.com
Push
Push
( fig.2)
Insert the exposed ends of the joint connectors
into the short (vertical) frame and align the four
corners so that they meet at perfect right angles
4. Join all four frame parts together following the steps showed below (fig.2).
5. After making sure that all four corners join at right angles to form a perfect rectangle,fasten the four
angles together by using the (x8) joint screws included . (fig.3)
Screw
( fig.3)
