Seite 1/8
www.elitescreens.com
info@elitescreens.com
Note: Regardless of the mounting method, the screen should be securely supported so that
when retracted, deployed, or even abusive pulling on the screen, the case will not become loose
or fall. The installer must insure that the fasteners used are of adequate strength and suitable for
the installation location.
1. Carefully unpack the screen.
2. Always handle the screen in a leveled position on a clean surface.
Manual SRM Series
Manual Pull-down screen with built-in slow retract mechanism
User Guide
v.12
Pre-Installation
Back of end cap
Front view
Installation
- 2 -www.elitescreens.com info@elitescreens.com
1. Mark the location of where the screen is to be installed for the pre-drilled hole.
2. After marking the area and drilling the hole, insert the proper screw into the drilled hole and leave
about 1/8" of an inch from the wall to mount the screen.
3. Mount your screen from the keyhole located on back of screen’s left and right end cap.
Flush Mount to the Wall
1. You can also hang the screen on a ceiling by using a chain (not included) and hang it by the two loops
located on each end of the case.
Ceiling Mounting (additional hardware required)
Loops
1. Pull the screen down from the lanyard or from the handle only in a 90-degree angle. Do not attempt to
pull the screen down by the surface or touch the screen, as it will damage the screen and void the
warranty.
2. If you want to the screen to retract back, simply pull the screen down more than 2 inches and retract
the screen back by quickly and smoothly releasing it up gently. The screen is equipped with a SLOW
RETRACT MECHANISM (SRM) which allows the screen to slowly retract without the need to hold on
to the handle or lanyard. Simply release the handle and the screen will retract by itself.
Screen Operation & Maintenance
Note: Always pull the screen down or let it up in a 90-degree vertical angle. Do not allow the screen
to touch the screen case when the screen goes up or comes down to avoid damaging the screen mate-
rial.
Note: An internal auto-lock mechanism system will cause the screen to stop and lock on the position
at intervals.
Note: Always release at a 90-degree angle and do not let go until the screen is entirely inside the
case If ever the screen feels stuck, keep in mind that the screen’s mechanism is new and needs to be
run up/down a few times to loosen up. If this happens, carefully with a little force yank the screen
straight down to unlock the screen.
Clean matte white screen material with a soft cloth and mild soap with water.
When not in use, retract screen in its housing to keep the screen material surface clean.
Maintenance
- 3 -www.elitescreens.com info@elitescreens.com
Note: Improperly bringing the screen up/down will damage the screen material or rolling system.
Produktspezifikationen
| Marke: | Elite Screens |
| Kategorie: | Projektionsfläche |
| Modell: | Manual SRM 94" |
