Seite 1/2
Rev. 110216-DR info@elitescreens.com www.elitescreens.com
Back of end cap
Front view
Manual SRM Series
Manual Pull-Down Projection Screen
USER’S GUIDE
Pre-Installation
1. Carefully unpack the screen.
2. Always handle the screen in a leveled position on a clean surface.
NOTE:
Regardless of mounting method, the screen should be securely supported so that vibration or even abusive
pulling on the viewing surface will not cause the case to work loose or fall. The installer must insure that the
fasteners used are of adequate strength and suitable for the mounting surface chosen.
INSTALLATION
Flush Wall Mounting
1. Mark the location of where the screen is to be
installed for the pre-drilled hole.
2. After marking the area and drilling the hole,
insert the proper screw into the drilled hole and leave about
1/8” of an inch from the wall to mount the screen.
3. Mount your screen from the keyhole located on back of
screen’s left and right end cap.
Ceiling Mounting
(additional hardware required)
Optional installation using a chain to hang the screen from the
ceiling.
1. You can also hang the screen on a ceiling by using a
chain (not included) and hang it by the two loops
located on each end of the case.
Rev. 110216-DR info@elitescreens.com www.elitescreens.com
SCREEN OPERATION
Note: pull the screen down or let it up in a 90-degree vertical angle. Do not allow the screen to touch Always
the screen case when the screen goes up or comes down to avoid damaging the screen material.
1. Pull the screen down from the lanyard or from the handle only in a 90-degree angle. Do not attempt to pull
the screen down by the surface or touch the screen, as it will damage the screen and void the warranty.
Note: An internal auto-lock mechanism system will cause the screen to stop and lock on the position at
intervals.
2. If you want to the screen to retract back, simply pull the
screen down more than 2 inches and retract the screen back by
quickly and smoothly releasing it up gently. The screen is
equipped with a SLOW RETRACT MECHANISM (SRM) which
allows the screen to slowly retract without the need to hold on to the
handle or lanyard. Simply release the handle and the screen will
retract by itself.
Note: Always release at a 90-degree angle and do not let go until
the screen is entirely inside the case
If ever the screen feels stuck, keep in mind that the screen’s
mechanism is new and needs to be run up/down a few times to
loosen up. If this happens, carefully with a little force yank the
screen straight down to unlock the screen.
Note: Improperly bringing the screen up/down will damage the screen material or rolling system.
RETRACTION TIP: If you are not able to pull the screen down two inches when attempting to
retract it, give the screen a quick yank downwards with a little bit of force. Please be sure to
not stand directly under the housing of the unit when yanking down on the screen.
MAINTENANCE
Clean matte white screen material with a soft cloth and mild soap with water.
When not in use, retract screen in its housing to keep the screen material surface clean.
For more information, technical support or your local
Elite Screens contact, please visit
www.elitescreens.com
