Seite 1/7
ezCinema Plus Series
Portable Floor Pull-Up Screen
USER’S GUIDE
Rev062510- JA
www.elitescreens.com info@elitescreens.com
1
Precautions:
Warning! Screen damage can result from operational errors if the enclosed
precautions are not followed.
In accordance with practicing home fire safety and avoiding screen
damage, do not place the screen near or beside a fireplace or high
temperature objects such as a gas stove, BBQ or heater.
Place the screen beyond the reach of children.
Parts Identification
*Note: The Flex Bar is a feature designed to evenly distribute the tension of the screen out to
the sides. The Flex Bar is designed to bow” out from the Top Support Bar. It may bow out
a few inches depending on the size of the screen. (Fig.3)
Fig. 1
Fig. 2
Fig. 3
Flex Bar*
Top Support Bar
Box Cover
(Lid)
Base
Feet
Box
(casing)
Black Screen
Material
2
Sett g up the Screenin
Installation
The screen should be installed in an area free of very strong wind and away from any fire activity
such as a heater, BBQ grill or fireworks display.
1. Extend base feet:
Locate the base feet on the bottom of the box at each end and rotate them until they form right
angles.
2. Open the box cover:
Unlatch the buckles at both ends of the box and open the box cover.
3. Pulling up the screen:
Carefully lift the screen by its handle and stop at the desired height position. The screen’s “scissor
back” spring configuration will support it.
Note: The screen will only stop shortly after the bottom black rise has been exposed.
Pull
