Seite 1/9
Rev.021918- 1 DR www.elitescreens.com
In-Ceiling Electric Motorized Front Projection Screen
Evanesce Series
Userâs Guide
Important Safety & Warning Precautions
Make sure to read this userâs guide and follow the procedure below.s
Caution: The screen materialâs Black Top Masking Border s already set to its maximum drop i level.
Beyond this, there is NO extra black masking on the roller at the top of the screen. Please be aware of this
as dropping the material off the roller will void your warranty with Elite Screens. Unapproved
alterations/modifications to this unit (except for splicing the power cord into hardwire installations) are
prohibited and will void your warranty. For more information, please contact our Technical Support also
Department at (877) 511- 1211 Ext. 604.
⢠Please retain this userâs guide for future reference.
⢠To avoid damaging the Evanesce screen, do not use it with any accessories not authorized by
the manufacturer.
⢠Handle the unit carefully during transportation to avoid any shipping screen damages.
⢠To ensure safe and reliable operation, a direct connection with a properly grounded power
source is advised.
⢠The power outlet supplying power to the Evanesce screen should be close to the unit and easily
accessible.
⢠Do not install the screen uneven or inclined into ceilings.
⢠To avoid an electric shock or a short circuit, do not expose the screen to dampness.
⢠Do not place any heavy objects on top power cord. of the
⢠Position the power cord in compliance with IEC/NEC electrical codes and local building codes.
⢠Never overload the power cord. Always make sure that the contact is firm to a suitable, constant
power source.
⢠The internal & external parts of the Evanesce screen are not to be modified or tampered with by
end users. Only an authorized technician should open the metal casing or attempt repairs.
⢠If there is a need to use an extension cord, make sure the cord has an equal rating. Consult NEC
guidelines for more information.
⢠Use properly insulated electricianâs clothing/equipment during any installation of electronics.
Do not handle the power plug your hands are wet or your feet are in contact with water. if
⢠When product reaches the end of its operational lifespan, properly dispose of this product in
accordance with the environmental regulations of your . local area
This Product is Designed for
Integrators
This user manual is written for the
comprehension of licensed
professional installers/integrators
experienced in building and electrical
wiring codes.
DIY âdo - -it yourselfâ enthusiasts
should consult a professional for
assistance
Rev.021918- 2 DR www.elitescreens.com
Do not use this unit under the following circumstances.
⢠If the product is in direct contact with water, soil, rain, weather, or moisture.
⢠Avoid direct sunlight on the product. UV radiation damages synthetic materials with prolonged
exposure.
⢠Keep away from fire and other sources and high temperature.
⢠Disconnect the power supply first before transporting or maintenance.
⢠To avoid possible injury and/or an electric shock, do not attempt to use this screen if there is any
indication that the product is damaged.
Installation Warning
T he instructions provided within this userâs guide are for reference only. Please consult a
professional for further installation and safety advice. The installer must insure that installer
proper mounting hardware is used to provide adequate strength suitable for the installation. Elite
Screens is not liable for any faulty installations. For limit adjustment instructions, please contact
our Technical Support Department at (877) 511-1211 Ext. 604
The Screenâs is already set tTop Black Drop o its maximum drop distance. There is NO extra top black
drop in the roller. Please be aware of this as it will void the limitation of your warranty.
Individual modifications to this product are prohibited and will void the warranty with the manufacturer.
Please contact Elite Screens Customer Service for any questions.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communicati ons.
However, there is no guarantee that the interference will not occur on a particular installation. If this
equipment causes harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures.
ďź Reorient or relocate the receiving antenna of the device which may be casing the
interference.
ďź Increase the separation between the screen and the deviceâs receiver.
ďź Connect the equipment into a different power outlet other than the device.
Pre- Installation
1. Carefully unpack the screen.
2. Always handle the screen in a leveled position on a clean surface.
3. In order to protect the screen from exposure to stains, keep the screen out of contact with foreign
particles such as dust, sawdust, and/or liquids.
NOTE
Regardless of the mounting method, the screen should be securely supported so that the vibration or
pulling on the viewing surface will not cause the casing to become loose or fall. The installer must insure
the fasteners that are used are of adequate strength and suitable for the installation location.
Rev.021918- 3 DR www.elitescreens.com
Evanesce Series| Controls and Accessories
A. IR Remote
B. RF Remote
C. Wall switch control box
D. 5- 12 volt trigger cable
E. IR extended âeyeâ receiver
F. Wireless 5-12v (3.5 mm)
mono trigger cable
G. AAA batteries
H. Bubble leveler
Screen operation
Electric Current: Depending upon region, your Elite Screen will operate on 100v, 110v, or 220v voltage.
1. After ensuring the power outlet & screen are compatible (voltage), plug the power cord into the power
outlet.
2. Once the screen has power, youâll be able to control it using any of the 6 methods described below.
6 ways to control your Evanesce
1. IR remote control ( ): The Infrared functions by direct line Item A, Fig 1
of sight contact with a beam range of 30 feet. Aim the IR remote at the
âeyeâ receiver once it has been connected to the control boxâs RJ45 port.
2. IR âEyeâ Receiver (Item E, Fig 2): The IR âEyeâ Receiver plugs
directly into the control boxâs RJ45 port to present a low profile line-of-
sight control option for your IR remote control even in a recessed ceiling
installation.
3. RF Remote Control (Item B): The radio waves eliminate the need for a
direct line of sight with a range of 100 feet.
4. 3-Way Wall Switch (Item C, Fig 3): -The 3 way wall switch is a wall
mount switch with an up/stop/down button and plugs directly into the
control boxâs RJ45 port.
Fig.3
UP
STOP
DOWN
Fig.1
IR/RF remote
IR âeyeâ receiver
Fig.2
3 Way Wall Switch
(does not have IR sensor)
Control box
Control box
