Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
SAFE® Select Technology, Optional Flight Envelope Protection
UMX™ Ultrix™
2
EN
As the user of this product, you are solely responsible for operating in a manner that does not endanger yourself and others or
result in damage to the product or the property of others.
• Always keep a safe distance in all directions around
your model to avoid collisions or injury. This model is
controlled by a radio signal subject to interference from
many sources outside your control. Interference can
cause momentary loss of control.
• Always operate your model in open spaces away from
full-size vehicles, traffi c and people.
• Always carefully follow the directions and warnings
for this and any optional support equipment (chargers,
rechargeable battery packs, etc.).
• Always keep all chemicals, small parts and anything
electrical out of the reach of children.
• Always avoid water exposure to all equipment not
specifi cally designed and protected for this purpose.
Moisture causes damage to electronics.
• Never place any portion of the model in your mouth as it
could cause serious injury or even death.
• Never operate your model with low transmitter
batteries.
• Always keep aircraft in sight and under control.
• Always use fully charged batteries.
• Always keep transmitter powered on while aircraft is
powered.
• Always remove batteries before disassembly.
• Always keep moving parts clean.
• Always keep parts dry.
• Always let parts cool after use before touching.
• Always remove batteries after use.
• Always ensure failsafe is properly set before fl ying.
• Always engage throttle cut before approaching the
aircraft.
• Never operate aircraft with damaged wiring.
• Never touch moving parts.
WARNING AGAINST COUNTERFEIT PRODUCTS: If you ever need to replace your Spektrum receiver found in a
Horizon Hobby product, always purchase from Horizon Hobby, LLC or a Horizon Hobby authorized dealer to
ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards,
but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM
or Spektrum technology.
Age Recommendation: Not for children under 14 years. This is not a toy.
Safety Precautions and Warnings
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before
operating. Failure to operate the product correctly can result in damage to the product, personal property and
cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic
mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage
to the product or other property. This product is not intended for use by children without direct adult supervision. Do
not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon
Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow
all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid
damage or serious injury.
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby,
LLC. For up-to-date product literature, visit www.horizonhobby.com or www.towerhobbies.com and click on the support
or resources tab for this product.
The following terms are used throughout the product literature to indicate various levels of potential harm when
operating this product:
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage,
and serious injury OR create a high probability of superfi cial injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a
possibility of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no
possibility of injury.
NOTICE
Meaning of Special Language
3
EN
Table of Contents
Box Contents
Specifi cations Components
Needed to Complete
Installed
12.9 in (320mm)
13.5 in (342mm)
2.29oz
(65g)
Prefl ight Checklist ............................................................. 4
Transmitter Setup ............................................................. 4
Install the Vertical Stabilizers.............................................4
Adjusting the Center of Gravity (CG) .................................. 5
Transmitter and Receiver Binding .....................................5
Arming the ESC ................................................................6
Low Voltage Cutoff (LVC) ...................................................6
Control Centering .............................................................. 6
Settings for Control Horns ................................................. 6
Control Direction Test ........................................................ 7
SMART Technology Telemetry ...........................................7
SAFE® Technology ........................................................... 8
Flying Tips and Repairs .....................................................8
Post Flight Checklist ......................................................... 9
Service of Power Components .......................................... 9
Replacement Parts List ..................................................... 9
Recommended Parts List ................................................ 10
Optional Parts ................................................................. 10
AS3X Troubleshooting Guide ........................................... 10
Troubleshooting Guide .................................................... 11
Limited Warranty ............................................................ 12
Warranty and Service Contact Information ......................13
FCC Information .............................................................. 13
IC Information ................................................................. 13
Compliance Information for the European Union ..............14
Flying Weight
Motors EFLUM0805 0805 - 13,500kv
Receiver EFL DSMX® RX/ESC unit (EFLU6453)
Servo (2) 2.3-Gram Performance Linear
Long Throw Servo (SPMSA2030L)
Transmitter Spektrum™ DSM2
®/DSMX® with
dual-rates (DX4e and up)
Battery 500mAh 1S 25C Li-Po (EFLB5001S25)
Battery Charger 1S 3.7V Li-Po (SPMXC1040)

Produktspezifikationen

Marke: E-flite
Kategorie: Funkgesteuertes Spielzeug
Modell: UMX Ultrix
