UMX™ Habu 180 DF
Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
2
EN
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the
product before operating. Failure to operate the product correctly can result in damage to the product,
personal property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires
some basic mechanical ability. Failure to operate this product in a safe and responsible manner could
result in injury or damage to the product or other property. This product is not intended for use by
children without direct adult supervision. Do not use with incompatible components or alter this product
in any way outside of the instructions provided by Horizon Hobby, Inc. This manual contains instructions
for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings
in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or
serious injury.
Meaning of Special Language:
The following terms are used throughout the product literature to indicate various levels of potential
harm when operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND
little or no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage
AND a possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage,
collateral damage, and serious injury OR create a high probability of superfi cial injury.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion
of Horizon Hobby, Inc. For up-to-date product literature, visit www.horizonhobby.com and click on the
support tab for this product.
Age Recommendation: Not for children under
14 years. This is not a toy.
Safety Precautions and Warnings
• Always keep a safe distance in all directions
around your model to avoid collisions or injury.
This model is controlled by a radio signal subject
to interference from many sources outside your
control. Interference can cause momentary loss
of control.
• Always operate your model in open spaces away
from full-size vehicles, traffi c and people.
• Always carefully follow the directions and
warnings for this and any optional support equip-
ment (chargers, rechargeable battery packs, etc.).
• Always keep all chemicals, small parts and
anything electrical out of the reach of children.
• Always avoid water exposure to all equipment
not specifi cally designed and protected for this
purpose. Moisture causes damage to electronics.
• Never place any portion of the model in your
mouth as it could cause serious injury or
even death.
• Never operate your model with low transmitter
batteries.
• Always keep aircraft in sight and under control.
• Always use fully charged batteries.
• Always keep the transmitter powered on while
aircraft is powered.
• Always remove batteries before disassembly.
• Always keep moving parts clean.
• Always keep parts dry.
• Always let parts cool after use before touching.
• Always remove batteries after use.
• Always ensure failsafe is properly set
before fl ying.
• Never operate aircraft with damaged wiring.
• Never touch moving parts.
3
EN
T
hank you for purchasing the E-fl ite
® UMX™ Habu 180 DF Bind-N-Fly® aircraft. Modeled after the popular
EDF sport jet design, you get exhilarating performance, plus handling that’s been custom engineered
to meet the specifi c needs of the RC sport pilot. With the UMX Habu 180 DF, you can expect impressive
maneuverability and agility at a variety of speeds and the stability to hold almost any attitude. Breakthrough
ultra micro electric ducted fan technology features fi nely tuned inlet and exhaust ducting expressly
engineered to harness the incredible thrust potential of its 28mm Delta-V
® 180m brushless EDF system. The
best part about your new UMX Habu 180 DF is the astounding AS3X
® system and performance linear servos,
which provide smooth, natural feeling control and amazing stability, plus it battles many of the bumps
caused by wind and turbulence so you don’t have to work hard to enjoy rock-solid fl ight performance.
The exceptional capabilities of the UMX Habu 180 DF require a little more fi rst-fl ight preparation than
you may be used to with other Bind-N-Fly ultra micro aircraft. Please be sure to read through this manual
carefully so that you are equipped to successfully enjoy all the benefi ts this outstanding ultra-micro model
has to offer.
To register your product online, go to www.e-fl iterc.com
Installed
Motor: BL180m Ducted Fan Motor,
11750Kv (EFLM30180mDFB)
Ducted Fan Unit: Delta-V 180m
28mm EDF Unit (EFLDF180m)
Receiver: Spektrum™ DSMX®
6Ch AS3X® Receiver w/BL ESC
(SPMAS6410NBL)
Servo: (4) 2.3-Gram Performance
Linear Long Throw Servo
(SPMSA2030L)
Needed to Complete
Battery: 200mAh 2S 25C Li-Po
(EFLB2002S25)
Recommended Battery Charger:
2S 7.4V Li-Po (EFLUC10007)
Recommended Transmitter:
Spektrum™
DSM2 ®/DSMX® full range with
dual-rates (DX4e and up)
17.5 in (444mm)
14.6 in (372mm)
2.65oz
(75.5 g)
Prefl ight Checklist .................................................4
AS3X Stabilization Delivers Breakthrough
Performance .........................................................4
Low Voltage Cutoff (LVC) .......................................4
Transmitter and Receiver Binding ..........................5
ESC/Receiver Arming, Battery Installation and
Center of Gravity ...................................................6
Control Centering .................................................7
Factory Control Horn Settings................................7
Control Direction Test ............................................7
Dual Rates and Expos ...........................................8
DX4e and DX5e Expo Activation and Deactivation .8
Landing Gear Removal ..........................................9
Post Flight Checklist .............................................9
Flying Tips and Repairs .......................................10
Power Components Service ................................11
Troubleshooting Guide ........................................12
Troubleshooting Guide (Continued) ......................13
Limited Warranty ................................................13
Warranty and Service Contact Information ..........15
FCC Information ..................................................15
Compliance Information for the European Union ..15
Replacement Parts ..................................................
Optional Parts and Accessories ...............................
Table of Contents
Specifi cations
