UMX™ BEAST® 3D
2
EN
Age Recommendation: Not for children under 14 years. This is not a toy.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product
before operating. Failure to operate the product correctly can result in damage to the product, personal
property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and
requires some basic mechanical ability. Failure to operate this product in a safe and responsible
manner could result in injury or damage to the product or other property. This product is not intended
for use by children without direct adult supervision. Do not attempt disassembly, use with incompatible
components or augment product in any way without the approval of Horizon Hobby, Inc. This manual
contains instructions for safety, operation and maintenance. It is essential to read and follow all the
instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly
and avoid damage or serious injury.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion
of Horizon Hobby, Inc. For up-to-date product literature, visit www.horizonhobby.com and click on the
support tab for this product.
Meaning of Special Language
The following terms are used throughout the product literature to indicate various levels of potential
harm when operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND
little or no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage
AND a possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage,
collateral damage, and serious injury OR create a high probability of superfi cial injury.
3
EN
Designed by aerobatic world champion Quique Somenzini, the Ultra Micro extreme (UMX) Beast
® 3D BNF
Basic is a thrilling small-scale recreation of one of the most awe-inspiring airplanes ever created. At its
heart is the revolutionary AS3X
™ System built in to help provide you with a true 3D experience, the ability
to fl y indoors, and handle windy conditions outdoors. The added punch of its stronger 2500Kv, 180BL
outrunner motor delivers an outstanding thrust to weight ratio. But beyond the capability to better perform
all-out 3D, you will fi nd that the Beast 3D with AS3X gives you unmatched precision in its size-class and
remarkably stable handling. Surprisingly, all of the performance possible from the UMX
™ Beast 3D BNF
Basic only requires basic radio programming. And even though your new model is fully assembled, please
read and follow this manual completely to be sure you’re ready to take full advantage of what this awesome
RC aircraft has to offer.
To register your product online, go to www.e-fliterc.com
Table of Contents
Specifi cations .......................................................3
Prefl ight Checklist .................................................4
AS3X™ Stabilization ..............................................4
Low Voltage Cutoff (LVC) .......................................4
Transmitter and Receiver Binding ..........................5
Installing the Flight Battery ...................................5
Arming the ESC ....................................................6
Control Direction Test ............................................6
Control Centering .................................................6
Settings for Control Horns .....................................7
Dual Rates ............................................................7
Adjusting Center of Gravity (CG) ............................7
Flying Tips and Repairs .........................................8
Additional Safety Precautions and Warnings ..........9
Service of Power Components ............................10
Troubleshooting Guide ........................................11
Troubleshooting Guide (Continued) ......................12
Warranty and Repair Policy .................................13
Warranty and Service Information .......................14
Compliance Information for the European Union ..14
Parts Contact Information ...................................54
Replacement Parts ..............................................54
Optional Replacement Parts ................................55
EFLU4864 DSM2 6Ch Ultra Micro
AS3X Receiver BL-ESC
BL180 Brushless Outrunner
Motor, 2500Kv
(4) 2.3 g Performance Linear Long
Throw Servo
Battery: 180mAh 2S 20C Li-Po
Battery Charger: 2S 7.4V Li-Po
Recommended Transmitter:
Spektrum™ DSM2™
/DSMX ® full range
with dual-rates (DX4e and up)
Needed to Complete
Installed
15.7 in (400mm)
14.7 in (372mm)
2.0 oz (58 g)
Specifi cations

Produktspezifikationen
