Seite 1/37
Specications
Wingspan: 65 in (1653mm)
Length: 57 in (1448mm)
Wing Area: 743 sq in (47.9 sq dm)
Weight: 9.25–10.0 lb (4.2–4.5 kg)
Wing Loading: 29–31 oz per sq ft
Radio: 6-channel w/6–7 standard servos, 2 retract servos
Engine: .60–1.20 2-stroke; .91–1.25 4-stroke; E-Power 60–90
P-51 Mustang 60 ARF
Assembly Manual
2Hangar 9 P-51 Mustang 60 ARF Assembly Manual
Table of Contents
Contents of Kit and Parts Layout ...........................................2
Included Parts Listing ............................................................3
Using the Manual ...................................................................4
Before Starting Assembly ......................................................4
Important Information Regarding Warranty Information .......4
Transmitter Requirements......................................................4
Radio Equipment Requirements - 7-Channel Receiver ..........4
Radio Equipment Requirements - 9-Channel Receiver ..........4
Optional Accessories .............................................................4
Recommended Setup–2-Stroke Glow ....................................5
Recommended Setup–4-Stroke Glow ....................................5
Recommended Setup–4-Stroke Gas ......................................5
Recommended Setup–Power 60 (EP) ...................................5
Recommended Setup–Power 90 (EP) ...................................5
Field Equipment Required ......................................................5
Optional Field Equipment .......................................................5
Additional Required Tools ......................................................5
Additional Required Adhesives ..............................................5
FS One ...................................................................................5
Hinging the Control Surfaces .................................................6
Aileron Servo Installation .....................................................10
Retract Installation ...............................................................17
Flap Servo Installation .........................................................22
Receiver, Rudder Servo and Tail Wheel Installation .............27
Elevator/Stabilizer Installation ..............................................35
Engine Installation: 4-Stroke ................................................40
Saito FG-20 Ignition Component Installation .......................45
Engine Installation: 2-Stroke ................................................46
Fuel Tank Installation ...........................................................51
Electric Motor Installation ....................................................51
Cowling and Spinner Installation - Electric Version .............53
Cowling and Spinner Installation - Glow Version .................55
Scale Accessory Installation ................................................57
Wing and Belly Pan Installation ...........................................59
Cockpit Details and Installation ............................................62
Center of Gravity ..................................................................64
Control Throws ....................................................................64
Flight Preparations ...............................................................65
Flying Your P-51 Mustang ...................................................65
Maintaining Your Model .......................................................66
Safety Do’s and Don’ts for Pilots .........................................66
Daily Flight Checks ...............................................................67
Age Requirements ...............................................................67
Safety, Precautions and Warnings .......................................67
Warranty Information ...........................................................67
CE Compliance Information for the European Union ...........69
2009 Official Academy of Model Aeronautics Safety Code ..69
Engine Mounting Template ..................................................71
Replacement Parts
1. HAN24201 Fuselage with Hatch
2. HAN24203 Left Wing Panel
3. HAN24204 Right Wing Panel
4. HAN24205 Stabilizer with Tubes
5. HAN24206 Rudder
6. HAN24207 Canopy
7. HAN24208 Cowl
8. HAN24209 Spinner, 41/4-inch (107mm)
9. HAN242010 Wing Tube
10. HAN242011 Retract Landing Gear with Axle (2)
11. HAN242013 Tailwheel Assembly
12. HAN242014 Molded Plastic Parts Bag
13. HAN242015 Printed Instrument Panel
14. HAN242017 Pushrods
15. HAN242019 45mm EP Motor Mount Set
16. HAN242020 Wing Bolt Set
17. HAN242022 31/2-inch Wheel Set
18. HAN242023 Belly Scoop and EP Air Exit
19. HAN242024 Metal Engine Mount
20. HAN242025 Fuel Tank, 420cc (14 oz)
21. HAN242026 Decal Sheet, Cripes A’Mighty
22. HAN242027 Decal Sheet, Petie 2nd (not included,
available separately)
23. HAN242028 Decal Sheet, Excalibur (not included,
available separately)
Not Shown:
HAN242012 Retract Strut Assembly (2)
HAN242016 Metal Parts Bag
HAN242018 Small Plastic Parts Bag
HAN242021 Hatch and Cowl Screws
HAN242029 P-51 Mustang Covering Set
HAN242030 20mm EP spacers for Power 90
Contents of Kit and Parts Layout
Included Pa
1
2
3
4
4
5
6
7
8
10
17
18
12
19
20
21
22
23
11
13
14
12
15 16
9
The Spektrum trademark is used with permission
of Bachmann Industries, Inc.
4 Hangar 9 P-51 Mustang 60 ARF Assembly Manual
Recommended Setup–2-Stroke Glow Field EquipmeUsing the Manual
This manual is divided into sections to help make assembly
easier to understand, and to provide breaks between each
major section. In addition, check boxes have been placed
next to each step to keep track of each step completed.
Steps with a single box ( ) are performed once, while steps 
with two boxes ( ) indicate that the step will require 
repeating, such as for a right or left wing panel, two servos,
etc. Remember to take your time and follow the directions.
Before Starting Assembly
Before beginning the assembly of your model, remove
each part from its bag for inspection. Closely inspect the
fuselage, wing panels, rudder and stabilizer for damage. If
you find any damaged or missing parts, contact the place of
purchase.
If you find any wrinkles in the covering, use a heat gun or
covering iron to remove them. Use caution while working
around areas where the colors overlap to prevent separating
the colors.
HAN100 – Heat Gun
HAN150 – Covering Glove
HAN101 – Sealing Iron
HAN141 – Sealing Iron Sock
Your model is covered in a printed version of UltraCote
developed specifically for your P-51 Mustang. It has all the
same properties as the glossy versions of UltraCote. All the
instructions provided with our original UltraCote apply to this
new and exciting product.
Important Information
Regarding Warranty Information
Please read our Warranty and Liability Limitations section on
Page 67 before building this product. If you as the purchaser
or user are not prepared to accept the liability associated
with the use of this Product, you are advised to return this
Product immediately in new and unused condition to the
place of purchase.
Transmitter Requirements
The P-51 Mustang requires a minimum of a 7-channel radio
to operate all the functions of your aircraft. We suggest the
following radio systems available through Horizon Hobby or
your local hobby distributor.
Spektrum DX7 SPM2710
JR Systems X9303 2.4GHz JRP2915
JR Systems 12X 2.4GHz JRP1200
Radio Equipment Requirements -
7-Channel Receiver
The following items are recommended when installing the
7-Channel AR7000 receiver (SPM6070) in your aircraft:
DS821 Digital Sport Servo (6) JRPS821
(Note: Only 6 servos required for EP version)
DS821 Digital Sport Servo Reverse (Flap) JRPS821R
RT88 Retract Servo (2) JSP20080
3-inch Servo Extension (2) JSP98100
6-inch Servo Extension (2) JSP98110
12-inch Servo Extension (2) JSP98030
Y-Harness (2) JSP98020
JR Switch, Chargeswitch JRPA004
Receiver battery, 6-volt, 2700mAh JRPB5008
Flaps: DS821 Servo and DS821 Servo/Reverse
• Y-harness (plugged into receiver)
Retracts: RT88 Servo (2)
• 3-inch Extension (plugged into receiver) (2)
• 6-inch Extension (connected to servo) (2)
Ailerons: DS821 Servo (2)
• Y-harness (plugged into receiver)
• 12-inch Extension (connected to servo) (2)
Rudder: DS821 Servo
Elevator: DS821 Servo
Throttle: DS821 Servo
Radio Equipment Requirements -
9-Channel Receiver
The following items are recommended when installing the
9-Channel AR9000 receiver (SPM9000) in your aircraft:
DS821 Digital Sport Servo (7) JRPS821
(Note: Only 6 servos required for EP version)
RT88 Retract Servo (2) JSP20080
3-inch Servo Extension (6) JSP98100
6-inch Servo Extension (2) JSP98110
12-inch Servo Extension (2) JSP98030
JR Switch, Chargeswitch JRPA004
Receiver battery, 6-volt, 2700mAh JRPB5008
Flaps: DS821 Servo (2)
• 3-inch Extension (plugged into receiver) (2)
Retracts: RT88 Retract Servo (2)
• 3-inch Extension (plugged into receiver) (2)
• 6-inch Extension (connected to servo) (2)
Ailerons: DS821 Servo (2)
• 3-inch Extension (plugged into receiver) (2)
• 12-inch Extension (connected to servo) (2)
Rudder: DS821 Servo
Elevator: DS821 Servo
Throttle: DS821 Servo
Optional Accessories
• 1/6 US WWII Pilot (HAN8297)
• Decal Sheet, Petie 2nd,
P-51 60 Blue Nose ARF HAN24227
• Decal Sheet, Excalibur,
P-51 60 Blue Nose ARF HAN24228
