Seite 1/21
Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
UMX™ ASK-21
2
EN
Age Recommendation: Not for children under 14 years. This is not a toy.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the
product before operating. Failure to operate the product correctly can result in damage to the product,
personal property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and
requires some basic mechanical ability. Failure to operate this product in a safe and responsible
manner could result in injury or damage to the product or other property. This product is not intended
for use by children without direct adult supervision. Do not attempt disassembly, use with incompatible
components or augment product in any way without the approval of Horizon Hobby, Inc. This manual
contains instructions for safety, operation and maintenance. It is essential to read and follow all the
instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly
and avoid damage or serious injury.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion
of Horizon Hobby, Inc. For up-to-date product literature, visit www.horizonhobby.com and click on the
support tab for this product.
Meaning of Special Language:
The following terms are used throughout the product literature to indicate various levels of potential
harm when operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND
little or no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage
AND a possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage,
collateral damage, and serious injury OR create a high probability of superfi cial injury.
3
EN
Thank you for purchasing the E-fl ite
® UMX™ ASK-21 scale RC sailplane. A fi rst of its kind in its size class
is a fully functional 4-channel aircraft capable of loops and rolls, as well as traditional thermal and slope
soaring. Lightweight and sleek, your new UMX ASK-21 is equipped with AS3X
® System technology specially
tuned for the many variations of fl ight conditions you’ll encounter, so that you get the smooth experience
similar to that of fl ying a giant-scale sailplane. And like the giant-scale sailplanes, this UMX ASK-21 is
tow hook equipped making it aerotow capable when paired with the powerful E-fl ite UMX Carbon Cub SS
(EFLU1180). Another strong benefi t of the AS3X
® is its outstanding ability to stabilize the glider while on a
tow line or Hi-start and help prevent common issues, such as heading loss, which can make smooth fl ight
diffi cult. Please be sure to read through this manual carefully so that you can successfully enjoy all the
benefi ts this outstanding ultra-micro model has to offer.
To register your product online, go to www.e-fl iterc.com
Table of Contents
Prefl ight Checklist .................................................4
Charging Warnings................................................4
Charging the Battery .............................................5
Wing Installation ...................................................6
Transmitter and Receiver Binding .........................7
Installing the Flight Battery ..................................7
Initializing AS3X ....................................................8
Control Centering ..................................................8
Settings for Control Horns .....................................8
Control Direction Test ............................................9
Dual Rates ............................................................9
Adjusting Center of Gravity (CG) ............................9
Hi-Start Hook Installation ....................................10
Hi-Start Launch ..................................................10
Towing ................................................................12
Tips for Towing ...................................................13
Tow Release Installation......................................13
Flying Tips and Repairs .......................................14
Additional Safety Precautions and Warnings ........15
Troubleshooting Guide ........................................15
Troubleshooting Guide (Continued) ......................16
Limited Warranty ................................................17
Warranty and Service Information .......................18
Compliance Information for the European Union ..18
Replacement Parts .............................................70
Optional Parts and Accessories ..........................71
Parts Contact Information ...................................71
Receiver: DSM2/DSMX 6Ch UM AS3X
Receiver ESC (EFLU1264)
Servos: (1) 2.3-Gram Performance Linear
Long Throw Servo (SPMSA2030L)
(2) 2.3-Gram Linear Long Throw
Offset Servo (SPMSA2030LO)
(2) (SPMSA2030L) on the board
Included
Battery: 150mAh 1S 25C Li-Po
(EFLB1501S25)
Battery Charger: 1S 3.7V Li-Po
(EFLC1000)
Additional Components:
4 AA Batteries
Tow Line (EFLU1257)
Tow Plate (EFLU1255)
Hi-Start and Stake (EFLU1258)
Hi-Start Hook and Screw
(EFLU1255)
Needed to Complete
Recommended Transmitter:
Spektrum™ Full range DSM2®/DSMX® with
dual-rates (DX4e and up)
Installed
17 in (432mm)
2.56 oz
(72.5 g)
33.9 in (860mm)

Produktspezifikationen

Marke: E-flite
Kategorie: Funkgesteuertes Spielzeug
Modell: EFLU1280
