FC96RGB

Type L13

1 6

2 3 4 5 8 9 10

13 14 15 16 18 19

2423 25

22 27 2826 29 30

3534 36

31 32

37 39

40 41 42

Thank you for purchasing this Group 1-2-3 car seat. If you require as-

sistance with this product, please contact our customer service de-

partment.

SAFETY INSTRUCTIONS

Please read these instructions carefully before use and keep them for

future reference. If you do not follow these instructions, your child safe-

ty may be at risk.

• The hard items and plastic parts of the car seat must be placed and

installed so as they may not, in normal use, become trapped under a

movable seat or in the vehicle door.

• Keep all the straps that x the car seat to the vehicle fully tightened

and adjust the straps used to hold the child. Make sure the straps are

not twisted.

• Ensure that the harness lap straps are positioned as low as possible, to

support your child’s pelvis.

• Replace the car seat if it has been subject to severe impact in an ac-

cident.

• It is dangerous to modify or add to the car seat in any way without

approval from the appropriate authority, or not to carefully follow the

instructions for installation provided by the child seat manufacturer.

• Keep the car seat out of direct sunlight so that the child does not get

burned.

• Do not leave a child unattended in a car seat.

• Ensure that luggage and other items that may injure the child in the

event of an accident are correctly stowed away.

• Do not use the car seat without its cover.

• Do not replace the car cover with a cover that has not been recom-

mended by the manufacturer, as it plays a direct role in ensuring that

the restraint system works eciently.

• If in doubt over the installation and correct use of your car seat, please

contact the manufacturer.

• Do not use weight-bearing anchorage points other than those speci-

ed in the instruction manual or indicated on the car seat.

• Always use the rear seat if possible, even if the Highway Code allows

the car seat to be placed on the front seat.

• Always ensure that the car seatbelt is properly fastened.

• Always check that there are no scraps of food or other debris in either

the harness buckle or the seatbelt buckle.

• In winter, make sure that the child is not wearing over-bulky clothes.

Your Group 1-2-3 car seat

This is a Group 1-2-3 car seat that is designed for children weighing

between 9 and 36 kg (approx. 9 months to 12 years). (1)

A. Adjustable headrest + cover

B. Diagonal belt guide (used only for Group 2/3)

C. Harness strap (x2 - used only for Group 1)

D. Reducer cushion (if tted on this model)

E. Harness buckle + crotch strap (used only for Group 1)

F. Harness adjustment strap (x2 - used only for Group 1)

G. ISOFIX/EASYFIX adjustment handle

H. Lifting armrest (x2)

I. ISOFIX/EASYFIX connector (x2)

J. Adjuster (x2 - used only for Group 1)

K. Safety pads (x2 - used only for Group 1)

L. Shell + cover

M. Top Tether strap (used only for Group 1)

N. ISOFIX/EASYFIX connector release button (x2)

Installing the car seat with the harness

Group 1, 9 to 18 kg (approx. 9 months to 4 years)

WARNING

• This is an SAFETY RESTRAINT DEVICE FOR CHILDREN. It is comISOFIX -

pliant with Regulation 44/04 for use in a vehicle tted with an ISOFIX

anchoring system.

• It may be used in vehicles tted with seats approved as universal ISO-

FIX positions (refer to your car manual), according to the category and

size of the child safety restraint.

• The mass group and the size class for which this product is ISOFIX

suitable are: / .B1 9-18 kg

If in doubt, please contact the car seat manufacturer or the retailer.

Adjusting the harness

Make sure that the harness of your car seat is adjusted to the height of

your child before installing it in your vehicle. The shoulder harnesses

can be adjusted to 3 dierent heights and must pass through the holes

closest to your child’s shoulders. If your child’s shoulders are between

two levels always use the higher of the two. To adjust the height of the

harnesses, remove the upper section of one of the straps by pivoting

the metal anchor located behind the headrest , and then pulling (2)

the end of the strap through the slots of the shell and the cover (3).

Feed the end of the harness strap through the same slots at the desired

height, both in the cover and the shell and reattach it behind the (4)

backrest (5). Make sure that the metal anchor is correctly positioned

and that the end of the strap is not twisted. Repeat the procedure with

the second strap.

Installing the car seat and placing the child in the

vehicle

This car seat must only be tted on the rear seat of a vehicle

equipped with ISOFIX fastenings and a Top Tether anchor (univer-

sal ISOFIX). Please refer to your car manual.

WARNING! Your ISOFIX Group 1 car seat MUST be tted using the Top

Tether strap provided! Your child’s safety cannot be guaranteed if you

install your ISOFIX Group 1 car seat without the Top Tether strap.

Put the headrest of the car seat at its lowest position. Fold the Top Teth-

er strap over the back of the car seat so that it does not get trapped

during installation . Extend the ISOFIX/EASYFIX connectors from the (6)

car seat as far as possible .(7)

Position the car seat on the rear seat of the vehicle bring the ISOFIX/

EASYFIX connectors in line with the seat’s ISOFIX anchor points (8).

Click the ISOFIX/EASYFIX connectors into the anchor points; the indi-

cators on each connector should turn from red to green . Release (9)

the safety catch of the ISOFIX/EASYFIX system by pulling the red han-

dle attached to the base and gently pushing the car seat (10). With the

safety catch released, push the car seat by exerting equal pressure on

both sides until the rear of the car seat is pressed rmly against the

vehicle seat.

Bring the Top Tether strap over the vehicle seat and attach the clasp to

the vehicle’s Top Tether anchor point .(11)

Depending on the make of your car, the additional Top Tether anchor

point may be located:

• Behind the rear seat of the vehicle.

• On the oor to the rear of the vehicle.

• On the ceiling to the rear of the vehicle.

Please refer to your car user manual to locate the additional Top Tether

anchor point. Never attach the Top Tether to a point that is not recom-

mended by the vehicle manufacturer. Never alter the vehicle yourself in

order to try and fasten the Top Tether (for example by piercing, screw-

ing or attaching an anchor point yourself ).

Push the car seat against the back of the vehicle seat and pull on the

loose end of the Top Tether strap. When the belt is fully tightened, the

indicator on the Top Tether strap will turn from red to green .(12)

Open the buckle of the harness by pressing on the red button in the

centre of the buckle . Sit your child in the car seat. The lifting arm(13) -

rests make it easier for you to seat the child and to put on the harness.

To close the harness, join together both ends of the shoulder straps and

slide them into the buckle harness. You should hear it click .(14)

• Tightening the harness: Pull on the adjusting straps located on the

harness. You do not need to press on the adjuster buttons (15). IM-

PORTANT: A poorly tting harness can be dangerous. You should not

be able to slide more than two ngers between the shoulder strap and

the child’s chest.

• Loosening the harness: Press on the adjuster buttons located on the

upper part of the harness, while pulling at the same time on the lower

harness sections . Press on the red harness buckle button to free (16)

your child completely.

Some ISOFIX car seat models are tted with a buckle that sets o an au-

dible alarm (available as an option). This alarm warns the parents if the

child opens the buckle at an inopportune moment during the journey.

IMPORTANT: Before each journey, check that the armrests have been

lowered. A properly adjusted harness is essential to ensure maximum

protection for your child. There should not be more than two ngers

width between the harness and the child.

Installing the car seat without the har-

ness

Group 2-3, 15 to 36kg (approx. 3 to 12 years)

WARNING

• This is a ‘SEMI-UNIVERSAL’ SAFETY RESTRAINT DEVICE FOR CHIL-

DREN. It is compliant with Regulation 44/04 and may only be used in

vehicles specied in the adjoining list of approved vehicles.

• It can only be tted on vehicles with 3-point safety belts, whether xed

or inertia-reel, compliant with UN/ECE N°16 or an equivalent standard.

If in doubt, please contact the car seat manufacturer or the retailer.

Ensure that the harness and the Top Tether strap of your car seat

are removed before beginning installation in your vehicle.

Removing the harness and the Top Tether strap

Remove the Top Tether strap (17) and store it carefully for future use.

Press on the red harness button to undo the harness if necessary. Re-

peat steps and on each upper section of the harness. Take one (2) (3)

section of the harness and feed it to the back , attach the metal (18)

anchor of the harness to the back of the seat . The metal anchor (19)

must be positioned between the shell and the car seat cover. Repeat

the procedure on the second section of the harness. Check that the har-

ness connectors have also been passed behind the back rest. Remove

the crotch strap by twisting the metal keeper and by passing it through

the slots in the base and the cover . (20)

Installing the car seat and placing the child in the

vehicle

Your car seat is tted with an adjustable headrest that has been de-

signed to support your child throughout growth by providing maxi-

mum lateral protection.

IMPORTANT: When using the car seat without the harness, it must only

be installed with a 3-point safety belt . Never install the car seat (21)

within 2-point safety belt !(22)

Raise the adjustable headrest to its highest position. Extend the ISO-

FIX/EASYFIX connectors from the car seat as far as possible . Position (7)

the car seat on the rear seat of the vehicle bringing the ISOFIX connec-

tors in line with the seat’s ISOFIX anchor points . Click the ISOFIX (23)

connectors into the anchor points; the indicators on each connector

should turn from red to green . Ensure that the vehicle seat belt (24)

buckle remains accessible and that it has not been placed under the

car seat.

Release the safety catch of the ISOFIX/EASYFIX system by pulling the

red handle attached to the base and gently pushing the car seat (25).

With the safety catch released, push the car seat by exerting equal pres-

sure on both sides until the rear of the car seat is pressed rmly against

the vehicle seat and then feed the diagonal strap of the belt through

the headrest guide . (26)

Sit your child in the car seat. The lifting armrests make it easier for you

to seat the child and put on the harness. Make sure that the child’s back

is fully in contact with the back of the car seat. Pull and fasten the ve-

hicle seat belt. Pass the diagonal strap of the belt under the armrest

opposite the belt guide used. The waist strap of the belt passes under

both armrests . Lower the adjustable headrest and adjust it to the (27)

height of your child . It should be positioned so that it surrounds (28)

your child’s head, providing maximum lateral protection, whilst guid-

ing the diagonal belt over the child’s shoulder so that there is no con-

tact with the child’s neck . Tighten the vehicle seat belt.(29) (30)

Ensure that the belt is properly tightened, that it is not twisted and that

it is not at the level of your child’s neck.

To remove your child from the car seat, simply unbuckle the seatbelt

and place it at the side of the car seat. The belt will remain suspended

from the headrest belt guide. IMPORTANT: Before each journey, check

that the armrests have been lowered. Secure your car seat with the ve-

hicle seat belt at all times, even when your child is not in the car seat. An

unsecured car seat can cause injuries in the event of a collision.

Removing the car seat

Step 1 (Group 1): Loosen the Top Tether strap , then release the (31)

strap from its anchor point and bring it towards you .(32)

Step 1 (Group 2/3): Remove the diagonal strap of the seatbelt from the

belt guide of the adjustable headrest .(33)

Step 2 (all groups): Pull the car seat using the red handle on the ISO-

FIX base . On either side of the seat, release the ISOFIX connectors (34)

from their anchor points by pulling the release buttons towards you.

The indicators will turn from green to red . The car seat can (35) (36)

now be removed .(37)

Returning to the original conﬁguration

of the car seat

Follow the instructions below if you wish to return to the harness con-

guration.

Re-install the crotch strap, making sure that the metal keeper is correct-

ly in place under the seat Via the front of the backrest, between (38).

the cover and the shell, grasp and twist the metal anchor of one of the

two other sections of the harness, simultaneously pulling the section

through from the back . Re-install it via the front of the backrest (39)

at the desired height . Make sure the metal anchor of the harness (40)

section is correctly in place behind the backrest . Repeat the proce(41) -

dure with the second section of the harness. Make sure the harnesses

are not twisted.

Re-install the Top Tether strap, passing it between the backrest and the

car seat cover. Make sure that the metal anchor is correctly in place be-

hind the backrest . (42)

Storing the instruction manual

(43)

Cleaning

All the fabric parts are removable. Minor stains can be removed using

a sponge and soapy water or hand-washed at 30°C in soapy water. Do

not use bleach, do not iron, do not machine wash or tumble dry.

Reclining your child seat with the tilt hatch

Please engage the tilt panel of your car seat before connecting it to

the Isox anchorage points of your vehicle. Pull the tilt panel down

and push the locking ap at the center of the panel until both ends (44)

of the locking ap are housed in the notches of the seat base above

(45). Ensure that the tilt hatch is locked and secure.

Simply reverse this procedure to return to the non-reclined con-

guration.

Z.I. de Montbertrand

Rue du Claret 38230 Charvieu FRANCE

www.groupeteamtex.com

43 44 45

Click

Produktspezifikationen

Marke:	Cuggl
Kategorie:	Nicht kategorisiert
Modell:	Linnet

Brauchst du Hilfe?

Wenn Sie Hilfe mit Cuggl Linnet benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Nicht kategorisiert Cuggl

Cuggl Dream Bedienungsanleitung

31 August 2024

Cuggl Owl Spin Bedienungsanleitung

31 August 2024

Cuggl Brambling Bedienungsanleitung

31 August 2024

Cuggl Linnet Bedienungsanleitung

31 August 2024

Cuggl Partridge Bedienungsanleitung

31 August 2024

Cuggl Laurel Bedienungsanleitung

2 Mai 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-

DAS Audio AX-112-5 Bedienungsanleitung

16 Oktober 2024

Ferplast Ergocomfort Freetime Bedienungsanleitung

16 Oktober 2024

AEG MECK52 Bedienungsanleitung

16 Oktober 2024

Makita UR012G Bedienungsanleitung

16 Oktober 2024

Stihl HT 70 Bedienungsanleitung

16 Oktober 2024

Ernesto H14270 Bedienungsanleitung

16 Oktober 2024

IFM AC901S Bedienungsanleitung

16 Oktober 2024

Nedis RFPOM120FBK Bedienungsanleitung

16 Oktober 2024

AEG E9KLCS01 Bedienungsanleitung

16 Oktober 2024

ART ProChannel II Bedienungsanleitung

16 Oktober 2024
