FC08GR1

Group 1 Car Seat

for children from 9 to 18 kg (9 months to 4 years approx.)

Thank you for purchasing this Group 1 car

seat. If you require assistance with this

product or if you wish to change an acces-

sory, please contact our customer service

department.

SAFETY INSTRUCTIONS

WARNING: Please read these instructions

carefully before using the seat and keep

this guide in a safe place for future refer-

ence. If you do not comply with these in-

structions, the safety of your child could be

compromised. Only install your group 1 car

seat on a forward facing seat that has a

3-point seat belt in compliance with stand-

ard R 16 or other equivalent standards. Al-

ways give preference to rear seats, even if

the highway code allows installation at the

front.

Do not use on side facing or rear facing ve-

hicle seats. Never use this child seat with-

out fastening the child’s harness correctly,

and never attempt to use it without fasten-

ing it into the car as described in these in-

structions. It is important that the car seat

belts are perfectly tightened. Ensure that

the belt straps are not kinked or twisted.

The child seat must be pressed against the

vehicle seat upholstery as tightly as pos-

sible to ensure maximum protection: the

recommended method is shown in these

instructions. Do not add to or modify the

seat in any way. It is recommended that

this car seat should be changed when it

has been subjected to violent stresses in an

accident or has become badly worn. Peri-

odically inspect the harness for wear, pay-

ing particular attention to the attachment

points, stitching and adjusting devices. Do

not leave your child unattended in the seat

at any time. Ensure that no part of the seat

is trapped in a door or folding seat. If your

car has a folding rear seat, ensure that it

is correctly latched in the upright position.

Car interiors can become very hot when in

direct sunlight: it is therefore recommended

that the child seat is covered when not in

use. This prevents components, particularly

those attached to the child’s seat, becom-

ing hot and burning the child. Do not use

the child seat without its seat cover, which

should not be replaced with any other than

the one recommended by the manufactur-

er. In case of an emergency it is important

that the child can be released quickly: this

means that the buckle is not fully tamper-

proof, so your child must be taught never

to play with the buckle. Luggage and other

heavy or sharp objects should be secured

in the car: loose objects are liable to cause

injury in the event of an accident.

Your Group 1 car seat (1)

This seat is classiﬁed as group 1 for chil-

dren weighing from 9 to 18 kg (from 9

months to 4 years approx.) in a forward

facing position.

A. Shell + cover

B. Harness + shoulder pad (x2)

C. Adjuster (x2)

D. Adjustment strap (x2)

E. Harness buckle

F. Base

G. Infant support cushion (some models

only)

H. Head support cushion (some models

only)

I. Red belt lock-off (x2 - for diagonal belt

(forward facing use only)

J. Lap belt guides (x2 - for forward facing

use only)

K. Seat reclining lever

Adjusting the harnesses

Make sure that the harness straps of

your car seat are adapted to the height

of your child before starting to install the

seat in your car. The harness straps can

be adjusted to different heights and must

be positioned at, or just above the height of

your child’s shoulders.

To adjust the height of the harnesses, re-

move the upper section of one of the har-

ness straps by pivoting the metal plate lo-

cated behind the back of the seat shell and

then pushing it through the slots of the shell

and cover .(2)

Reﬁt the harness strap through the desired

slots in the cover and seat shell making

sure that the metal plate is secure and ﬂat

against the back surface of the seat shell

(3). Make sure there are no kinks or twists

in the harness strap.

Repeat the operation on the upper section

of the second strap.

The correct type of safety belt

to use with your car seat

Your car seat must ONLY be installed on a

passenger seat ﬁtted with a 3-point safety

belt. install your car seat on a pas-NEVER

senger seat ﬁtted with a 2-point safety belt!

(i - 9-18kg)

Fitting your chid seat into

your car

Fully recline the seat. Pull lap and diagonal

sections of the car seat belt until fully ex-

tended and feed both through the space

between the shell and the base. Fasten the

seat belt .(4)

Thread the lap section through the guides

located below the red lock-off clips. Open

the red lock-off clip , next to the buckle

then route the diagonal section of the belt

through the open lock-off clip . (5) It is im-

portant that you DO NOT route the di-

agonal section of the belt through the red

lock-off clip on the other side of the seat.

Push the child seat right down into the

car seat, and tighten both sections of the

seat belt by pulling the belt in the direction

shown .(6)

Close the lock-off across the diagonal belt

(7). Check that there are no kinks or twists

in the seat belt.

Harness buckle

To fasten the harness, bring the two shoul-

der straps together and insert them into (8)

the buckle ; you should hear a (9) “click”

(10). To release the harness, press the

buckle’s red button.

Fitting the harness

• To tighten the harness: Pull on the ad-

justing straps positioned on the harness.

You do not need to press on the adjuster

buttons . (11) IMPORTANT: A correctly ad-

justed harness is essential for your child’s

protection. There should not be more than

a ﬁnger’s width between the harness and

your child.

• To loosen the harness: Press on the ad-

juster buttons positioned on the upper sec-

tion of the harness straps, grasp the lower

section and pull simultaneously .(12)

Reclining your child seat

Squeeze and lift the adjustment lever lo-

cated under the front of the seat upwards,

then pull or push the base towards or away

from you .(13)

Storage of the instruction

manual

Store this instruction manual, depending on

the model of your seat, either in the pouch

provided, or by slipping it into between the

shell and the seat cover.

Maintenance advice

All the material parts can be removed.

Slight stains can be removed using a damp

sponge soaked in soapy water or it can be

washed by hand at 30° in soapy water. Do

not use bleach, do not iron, do not machine

wash, and do not tumble dry.

WARNING

• This car seat is a “Universal” child re-

straint system. It has been approved in ac-

cordance with regulation N°44/04, and is

suitable for general use in vehicles and is

compatible with the majority (some excep-

tions) of vehicle seats.

• It is more likely that the seat is perfectly

compatible if the vehicle manufacturer

states that its vehicles are suitable for tak-

ing “Universal” child restraint systems.

• This restraint system is classiﬁed as “Uni-

versal” in accordance with the strictest ap-

proval criteria, whereas earlier models do

not correspond to these new provisions.

• It can only be adapted to vehicles with

3-point safety belts that are either ﬁxed

or have a roller mechanism and that have

been approved compliant with the UN/ ECE

N° 16 or other equivalent standards.

• If in doubt, contact the manufacturer or

retailer of the restraint system.

2 3 54

9-18 kg

76 98

10 11 12 13

Z.I. de Montbertrand

Rue du Claret

38230 Charvieu

FRANCE

www.nania.com
