Seite 1/6
- Retains factory features in select GM LAN 29 Bit vehicles while func oning with an rmarket  ae
radio.
- Pre-programmed to retain factory Steering Wheel Controls.
- Retains OnStar, factory Rear view camera and chime funcons.
- Adds Forced Rear view and Front view camera while in mo on using the factory side mirror controls.
- Su orts Bose, non-Bose a Y-91 audio systems. pp nd
- EIA color coded wiring for easy installa on.
1. The Front and Rear fading are not retained on Y- Bose System. 91
2. Chime includes: seat belt, check e ine, key in igni on, low fuel, low oil and lights on. ng
SOOGM-16W Mo le du
SOOGM-16W arness H
Video Harness
Antenna Adaptor
SWC Cable
SETTING THE AFTERMARKET R IO BRAND AD
With the key in the o pos on, set the DIP switches to the correspo ing a rmarket radio se ng. ff i nd e 
3.5 SWC CABLE MM
Plug in the 4-Pin SWC cable to the 4-pin c ector plug the module. onn on
NOTE: C or insulate the 3.5mm plug, the Blue/Yellow or Gr n wires if not being used.ap ee
SWC 3.5MM PLUG ADAPTER:
- Supports Rear Entertainment System with special order harness # A2444
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
1 of 6 rev.03282023
RSE Retention
Harness
If the vehicle is equipped with a Bose system, the SOOGM-16W has a
built-in Bose adaptor that allows the proper audio in t gain from pu
the a ermarket radio to the Bose ampli . To use this feature, plug  fier
in the male 8-pin co ec r on th harness to the GRAY female 8-pin nn to e
co ector on the SOOGM-16W mo le. The mo le is also labeled nn du du
“Bose” and “Non Bose” to avoid confusion. (see picture below)
If the vehicle is NOT equipped with a Bose system, pl in the male ug
8-pin co ector to the BLAnn CK female 8-pin on the SOOGM- W 16
module.
Co e on nn c
Non-BOSE
Co e on nn c
AFTERMARKET
RADIO
Reverse Gear Red/White
Parking Brake Yellow/Black
Illuminaon (+) Orange
+12V Constant Yellow
+12V ACC Red
Ground Black
Right Front (+) Gray
Right Front (-) Gray/Black
Le Front (+) White
Le Front (-) White/Black
Right Rear (+) Violet
Right Rear (-) Violet/Black
Le Rear (+) Green
Le Rear (-) Green/Black
TO FACTORY
HARNESS
24-Pin
Connector
8-Pin
Connector
BOSE NON
BOSE
10-Pin
Connector SWC DIP SWC CAM
1 2 3 4
ON
Video Out
Front Camera
Rear Camera
To OEM Camera
Harness
Gray 20-Pin
Connector VIDEO HARNESS
Chime Volume
Adjustment
1 2 3
ON VR Activation
for OnStar (set DIP#1 to ON)
44-PIN
CONNECTOR
Vehicle Speed Sense
(Green/White)
4-Pin
Connector
Cap or insulate if
not being used
3.5MM SWC CABLE
Plug in the 3.5MM SWC cable to the 4-pin port
on the module. See “DIP SWITCH SETTINGS” section.
LIN BUS (Green/Black)
JVC/Kenwood (Blue / Yellow) Insulate if not
being used
TROUBLESHOOTING
LED
LIGHT LED MODULE FEEDBACK
Solid blue
Flashing blue
Solid red Module providing 12V ACC
CAN not recognized
CAN recognized
12V ACC OFFRed off
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
2 of 6 rev.03282023
The SOOGM-16W has a pot ometer to adjust the chime vol e. en um
It is set at half way by default. To adjust the volume, simply use a
suitable screw driver and turn the potenometer clockwise to
increase the lume and covo unter-clockwise to decrease the vol e. um
To adjust the OnStar volu , turn on OnStar and adjust the volume using the Steering Wh l Control volume me ee
adjustment. Once it is set, the SOOGM-16W will memorize this level.
The SOOGM-16W includes a video harness that allows a front and rear view camera to be plugged in
and viewed on the aermarket radio screen. The video harness inc es a 20-pin brown co ector lud nn
that plugs into the OEM rear view camera harness to retain the use of the OEM rear view camera (if
equipped). The two female video RCAs are used to co ect ann n a ermarket front and rear view
camera (if vehicle is not equipped with an OEM rear view camera).
Chime
Volu me
Adjustment
AV INPUT
TO FACTORY
OVERHEAD
SCREEN
To AV
Input
To AV
Output
To Factory
20-Pin
Connector
AUDIO
MENU
SEEK
SEEK
RADIO
MEDIA
VOLUME
OPEN
CLOSE
1. Remove the OEM radio and plug the CRUX 2444A’s 20 pin connector to the vehicle’s 20 pin factory RSE
connector at the factory radio location. Use one of the Crux parts listed in the Note section.
2. To view videos from the aftermarket radio on the factory overhead screen, connect the RCA’s lebeled
“TO FACTORY OVERHEAD SCREEN” to the aftemarket radio AV output .
3. To retain the use of the factory rear panel AV inputs, plug the RCA’s labeled “AV INPUT” to the aftermarket
radio’s AV input (optional).
4 Test the audio & video on the overhead screen before installing the radio back into the dashboard
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
3 of 6 rev.03282023
Video Out
Front Camera
Rear Camera
To OEM Camera
Harness
Gray 20-Pin
Connector
To SOOGM-16W
Module (CAM)
1 2 3 4
ON
SWC DIP SWC CAM
