Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.0412221 of 4
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.0412224 of 4
SOHTL-20
Radio Replacement Interface for
LEXUS & TOYOTA Vehicles with JBL Systems
PRODUCT FEATURES:
- Retains factory features in select Lexus and Toyota vehicles with JBL Harman-Becker Digital-Synthesis
Amplier, including JBL (Pioneer-made) ampliers while funconing with an aermarket radio.
- Variable audio gain adjustment to level match the aermarket radio and factory amplier.
- Retains OEM 3.5mm Auxiliary Audio Input.
- Retains factory backup camera (if equipped).
- EIA color coded wiring for easy installaon.
PARTS INCLUDED:
SOHTL-20 Module TY-A Harness
(For Newer Models)
TY-B Harness
(For Older Models)
IMPORTANT INSTALLATION NOTES:
NOTES
NOTES:
1. Le-Right Balance Audio Control is supported. Front-Rear Audio Fading is not supported.
2. Please make sure the factory radio Balance and Fade opons are centered before removing the radio.
1. In some Lexus/Toyota vehicles 2006 and older, the mute circuit is located in the same pin loca-
on as the amplier turn-on on the OEM harness. If no audio is heard aer the installaon is
complete, disconnect the BLUE/WHITE wire on the SOHTL-20 t-harness from the aermarket radio
AMP Turn-on wire. Insulate with tape to avoid short circuits.
2. To retain the factory AUXILIARY INPUT opon in the vehicle, the aermarket radio must have an
Auxiliary Audio Input” feature. Please check your aermarket radio manual for details.
OEM Camera Retenon Harness 16 to 24 Pin Camera Adapter
RADIO REPLA CEME NT
SWC RE TENTIO N
+
R
INTERFACING SOLUTIONS
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.0412223 of 4
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.0412222 of 4
SOHTL-20
INSTALLATION DIAGRAM:
Use the gain adjustment to level match the aermarket radio audio output with the OE amplier input.
We recommend starng at 0 dB, turn the aermarket radio on and set the volume to 50%. Adjust the DIP
switches unl you hear clipping or sound distoron. Once distoron is heard, lower down the dB gain
one or two steps.
VEHICLE APPLICATIONS:
DIP SETTING dB Volts
OFF OFF OFF
OFF OFF ON
OFF ON OFF
OFF ON ON
ON OFF OFF
ON OFF ON
ON ON OFF
ON ON ON
0 dB
1.7 dB
3.5 dB
5.2 dB
7.2 dB
9.1 dB
11 db
12.9 dB
+7mV
+9mV
+10mV
+15mV
+18mV
+22mV
+27mV
1 2 3
ON
SOHT-20
MODULE
GAIN
ADJUSTMENT
LEXUS TOYOTA
2004-2006
2003-2005
2006
ES300
IS300
LS430
2003-2017
2005-2017
2007-2017
2004-2008
2009-2017
2007-2014
2008-2017
2005-2012
2004-2017
2004-2017
2005-2017
2004-2016
2005-2017
2004-2017
2009-2015
2008-2011
4 Runner
Avalon
Camry
Camry Solara
Corolla
FJ Cruiser
Highlander
Matrix
Prius
Rav4
Sequoia
Sienna
Tacoma
Tundra
Venza
Yaris
NOTE:
Does not retain Mark Levinson, Pioneer, Nakamichi or Harman Kardon ampliers.
AFTERMARKET
RADIO
+12V Constant Yellow
+12V ACC Red
Ground Black
Illumination Output Orange
Amp Turn-On Blue/ White
Antenna Turn On Blue
Vehicle Speed Sense Output Red/Black or Pink
Parking Brake Output Brown
Reverse Gear Output Red
Right Front + Gray
Right Front - Gray/Black
Left Front + White
Left Front - White/Black
Audio Input Red/White RCA
(Retains Factory AUX Input)
To SOHTL-20 Module
+12V Constant Yellow
+12V ACC Red
Ground Black
Illumination Output Orange
Amp Turn-On Blue/ White
Antenna Turn On Blue
Right Front + Gray
Right Front - Gray/Black
Left Front + White
Left Front - White/Black
Audio Input Red/White RCA
(Retains Factory AUX Input)
To SOHTL-20 Module
NOTE: Aftermarket radio rear speaker output leads
are not used on the TY-B harness. Insulate with tape.
AFTERMARKET
RADIO
TY-B
Harness
TY-A
Harness
SOHTL-20 OEM Camera
Retention Harness
Yellow RCA
(To Aftermarket Radio Camera Input)
To 24-Pin OEM
Camera Harness
OE Camera Power 6V
