- Acvates Reverse camera input.
- Adds three A/V Inputs.
- -screen display setup. On
- Switch the video sources via the OE buons.
MASERATI
2008 –Up
Gran Turismo
1 / 6
Rev.120116
Unplug OEM LVDS cable from the OEM monitor (which is connected to the Command box) and plug
it into the of the LVDS Controller box. LVDS INPUT
Connect the LVDS cable supplied in the kit to the of the RVCMT- and to the of LVDS OUT 69 LVDS IN
the LVDS Controller box.
Connect the LCD cable supplied in the kit to the of the LVDS controller box an into the LVDS OUT
OEM monitor.
Connecng the CAN Wires
1. Tap CAN HIGH (Brown/Green) from the Power harness to the CAN HIGH (Black/Pink) wire on the Command.
2. Tap CAN LOW(Green) from the Power harness to the CAN LOW (White/Pink) wire on the Command.
1
2
3
2 / 6
Rev.120116
DIP Switch Sengs
Disconnect power to the interface before seng the DIP switches.
Funcon
Selecon
RGB INPUT MUTE
ON : Skip RGB Mode
OFF : RGB Display
A/V 1 MUTE
ON : Skip A/V 1
OFF : A/V1 Display
A/V 2 MUTE
ON : Skip A/V 2
OFF : A/V2 Display
A/V 3 MUTE
ON : Skip A/V 3
OFF : A/V3 Display
Not Used
Not Used
Rear Mode
ON : Aermarket Rear Camera
OFF : OEM Rear Camera
Not Used
Remote Control Functions
Funcon
POWER & PIP
No Funcon
MENU
Acvate OSD menu
OK
Make a selecon, change image display
â–²
Move upward
â–¼
Move downward
â—€
Move le
(press this buon for more than 5 seconds to
access to the factory mode)
â–¶
Move right
(press this buon for more than 2 seconds to
reset all the data about user environment)
3 / 6
Rev.120116
