Seite 1/5
Rear-View Integ tion Interface with Front & Rear Viewra
Camera Input for BENTLEY BENTAYGA with 4G Systems
RVCBN-70K
Sightline
REAR-VIEW INTEGRATION
Product Features
Activates Reverse camera input in Bentley Bentayga with 4G system.
Rear view and Front view camera input.
With OE type Dynamic Parking Guide Lines.
On-Screen display setup.
Vehicle Applications
2017 Bentley Bentayga with 8” screen
Parts Included
RVCBN-70K MODULE LVDS Cable A/V Cable OSD Board
Power Harness RGB NAVI Cable Touch Cable
RVCBN-70K
Front & Rear View Integration
for BENTLEY BENTAYGA
Rear Camera
Connect to the GRAY connector
DO NOT connect to BLUE or GREEN
DO NOT use Yellow CAN-B-L
Connect to 12 Volts ACC
REAR_PWR
REAR-DET
CAN-B-H
CAN-OUT-L
CAN-OUT-H
CAN-IN-L
CAN-IN-H
MMI
Connect to GND
MONITOR
Wiring Diagram
RVCBN-70K
Front & Rear View Integration
for BENTLEY BENTAYGA
Crux Interfacing Solutions
www.cruxinterfacing.com
tel. #: (818) 609-9299
fax #: (818) 996-8188
1 / 5 rev.030117
LCD Cable supplied with kit
OEM LCD Cable
HEADUNIT
LCD In
LCD Out
2 Video Inputs
Rear-View Integration Interface with Front & Rear View
Camera Input for BENTLEY BENTAYGA with 4G Systems
RVCBN-70K
Sightline
REAR-VIEW INTEGRATION
Crux Interfacing Solutions
www.cruxinterfacing.com
tel. #: (818) 609-9299
fax #: (818) 996-8188
Installation Instructions
Pull Out
OEM GRAY
Connector
Check to make
sure the connector
is plugged in
correctly
Check these!
* ON DOWN , O UP : FF :
PIN FUNCTION DIP S/W Selection
1 NAVI ON : Disable
O :FF Enable
2 AV1
ON : Skip Video
O : DisplayFF
3
AV2
ON : Skip Video
O : DisplayFF
4
N/A
5
CAR type SEL
6
7
8
DIP Switch Settings
ON
OFF
2 / 5 rev.030117
Rear-View Integration Interface with Front & Rear View
Camera Input for BENTLEY BENTAYGA with 4G Systems
RVCBN-70K
Sightline
REAR-VIEW INTEGRATION
Crux Interfacing Solutions
www.cruxinterfacing.com
tel. #: (818) 609-9299
fax #: (818) 996-8188
MENU Push -> OSD menu On/Off
S Item S ction, Value S ction EL ele ele
UP Item up
Increase s cted value ele
DOWN Item down
Decrease s cted value ele
Mode State
Fi t Menu rs Second Menu Third Menu
O Control BoardSD
M U SEL UP D N EN OW
OSD Settings
Use the OSD Control Board to change the settings.
First Menu Second Menu Third Menu Action
Option
RearCam-T e yp OEM
ExtD ce Use aftermarket Rear camera evi
RearCam-Power
ON Rear mera power = + V onstinuously ON ca 12 c
A O Rear mera + V when r rse gear UT ca power = 12 in eve
O Shut the pow su ly FF off er pp
FrontCam-T e yp OEM O Camera EM
ExtD ce et ont camera evi Aftermark Fr
FrontCam-Power
ON
A O UT
O Shut the pow su ly. FF off er pp
RearCam-RcvOpt ON Show ontcam sec after rFr for 25 everse gear
OFF Default
Reset Excute Option Menu all Reset
O Camera EM
Front mera power = + Vca 12 constinuously ON
Front mera + V whenca power = 12 in parking process
- Horizontal
- Vertical
- Scaler X Up
- Scaler X Down
- Scaler Y Up
- Scaler Y Down
Display Settings
3 / 5 rev.030117
