Seite 1/7
MRVBM-77Q
Backup Camera and Video Interface for
2017 and up BMW & Mini Vehicles with Evo2 iDrive5 Systems
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.1104201 of 7
- Adds front and rear aermarket camera inputs.
- Retains funcîžźonality of the OEM backup camera if present.
- Front camera automacally shows on the screen aer changing the gear from reverse to drive.
- Provides power and ground for the cameras.
- Adds 1 A/V Input.
- Adds 2 video and 1 audio outputs.
PRODUCT FEATURES:
PARTS INCLUDED:
MRVBM-77Q Module MRVBM-77Q Power Harness LVDS Cable
Push Buîž©on Switch I/O Cable Remote Control
IR Cable
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.1104202 of 7
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
MRVBM-77Q
Backup Camera and Video Interface for
2017 and up BMW & Mini Vehicles with Evo2 iDrive5 Systems
DIP SWITCH SETTINGS:
4 POSITION SWITCH
DIP STATUS FUNCTION
1
UP AV1 ON
DOWN AV1 OFF
2
UP Front Camera ON
DOWN Front Camera OFF
3
UP
Set to OFF
DOWN
Set all DIP switches DOWN
8 POSITION SWITCH
DIP DIP #4 DIP #5 FUNCTION
STATUS
UP UP 1440 x 540 (5, 7, X5 Series) (10.25” screen)
UP DOWN 1280 x 480 (8.8” screen)
DOWN DOWN 800 x 480 (6.5” screen)
DOWN 1280 x 480 (Mini with Touch)UP
DIP switches 1 to 3:
DIP switches 4 and 5:
DIP STATUS FUNCTION
6
UP 5, 7 Series
DOWN 1, 2, 3, 4, 6, X Series, Mini
7
UP Use OEM Backup Camera
DOWN Use Aermarket Backup Camera
8
UP CAN in/out mode
DOWN CAN bypass mode
DIP switches 6 to 8:
Please make sure to power cycle the interface (unplug power harness then plug back in) aer changing
the DIP switch seîž«ngs.
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.1104203 of 7
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
MRVBM-77Q
Backup Camera and Video Interface for
2017 and up BMW & Mini Vehicles with Evo2 iDrive5 Systems
ON SCREEN DISPLAY (OSD) SETTINGS:
KEY FUNCTION
POWER & PIP No Funcîžźon
MENU Acîžźvate OSD Menu
OK Make the selecîžźon / Change the image display
Move UP
Move DOWN
Move LEFT (Press for 2 seconds to Access Factory Mode)
Move RIGHT (Press for 2 seconds to Reset User Data)
REMOTE CONTROL:
PARK
UTIL1
UTIL2
INFO
H-POSITION
V-POSITION
Menu of FACTORY
MENU to Return SEL to Select/Save
H-POSITION : Move the image horizontally
V-POSITION : Move the image verîžźcally
H-SIZE(NAVI) : Adjust the size of navigaîžźon
image horizontally
Adjusîžźng Screen Seîž«ngs (Menu of NAVI)
Make sure the IR receiver is connected to the module and is in a clear view for the IR Remote to contact.
There are two menus on the interface. “Menu of Navi” and “Menu of FACTORY”. In order to access the Menus
you must be in the AV source. Tap the PURPLE wire (SAFE) to ground and use the OK buîž©on on the IR remote to
switch sources (same funcon as momentary switch included). Press the “MENU” buon on the remote control
to enter Menu of NAVI.
In this menu, user can set the image BRIGHTNESS, CONTRAST,
SHARPNESS and set a USER IMAGE.
To access the “Menu of FACTORY”, exit the Menu of NAVI, press and hold the le arrow for 3 seconds while in
the same AV source. Use the arrows to navigate the menu.
Seîž«ng the Rear View Camera (Menu of FACTORY)
