Seite 1/3
Audi
2009 2012-
A4
2008 2010-
A8
2008 2012-
A5
2008 2012-
Q5
2009 2010-
A6
2007 2012-
Q7
2012 2012-
A7
BMW
2009 2012-
1 Series
2009 2012-
X5
2007 2012-
3 Series
2007 201- 1
X6
2005 201- 6
5 Series
2009 2012-
Z4
2004 201- 0
6 Series
Mercedes
2005 2009-
B-Class
2005 2009-
G-Class
2004 2007-
C-Class
2005 2009-
M-Class
2005 2008-
CL-Class
2005 2009-
R-Class
2005 2009-
CLK-Class
2005
S-Class
2004 2008-
CLS-Class
2005 200- 8
SL-Class
2003 2008-
E-Class
2006 2008-
SLK-Class
Porsche
2003 2009-
911
2003 2009-
Cayman
2003 2009-
Boxster
2003 2010-
Cayenne
1. On Audi, a factory CD-changer can be installed in addition to the AUX-ABMP1.
2. On BMW, Mercedes and Porsche, the existing factory CD-changer must be removed.
3. The AUX-ABPM1 emulates the external CD changer option, NOT compatible with 6-CD in-dash /
receiver radios.
Rev.0 61218
1
Vehicle selection (blue wire)
Installation for Audi MMI 3G
Remove MOST® connector from the rear of the
factory CD changer and connect the Interface according
to illustration. Follow the arrows on the MOST® connectors
as well as the order of components.
Connect black wire to ground and red wire to
constant +12V. Insulate blue wire*.
*NOTE: For installation on Audi, Mercedes or Porsche, blue wire is not connected and needs to be
insulated. For installation on BMW, connect blue wire to chassis ground (GND).
Installation for Porsche Cayenne PCM 2.1
Remove radio bezel, remove 4 torx screws
and pull out head-unit from the dash-board.
Remove MOST® connector from the rear of the
factory CD changer and connect the Interface according
to illustration. Follow the arrows on the MOST® connectors.
Connect black wire to ground and red wire to
constant +12V. Insulate blue wire.
Rev.0 61218
2 / 3
Black wire Red wire
GND +12V Constant
MOST Connector
The AUX-ABMP1 emulates a factory CD-changer and is recognized as such by the head-unit. The AUX-
input is activated by playing CD1 on the head-unit.
Note: On Audi with one factory CD-changer installed, the AUX-ABMP1 emulates a second factory
CD-changer. Play CD7 to activate AUX-input.
Legal disclaimer: Company names and trademarks, as well as product names/codes are registered trademarks® of their
corresponding legal owners.
3 / 3
