AMP-CH5
OEM Amplier Replacement Interface for
Chrysler, Dodge, Jeep & RAM Vehicles with Uconnect Systems
R
INTERFACING SOLUTIONS
- Retains U-Connect and navigaon prompts.
- Retains Bluetooth handsfree mode.
- Allows adjustments for Balancing/Fading, Bass, Mid and Treble frequencies.
- Retains OEM radio EQ controls.
- Adjustable bass frequency and level. Includes an under dash mount encoder/bass knob.
- Provides 4 channel Front/Rear outputs plus non-fading subwoofer output.
- Remote output to turn on aermarket amplier.
- Includes an OEM amplier Bypass harness. No cung of factory wires.
PRODUCT FEATURES:
PARTS INCLUDED:
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
1 of 4 rev.092519
PRODUCT OVERVIEW:
The AMP-CH5 allows for an improvement in audio quality in vehicles equipped with data-bus controlled amplied
sound systems by upgrading to an aermarket mul-channel amplier while retaining the factory radio. The
AMP-CH5 provides balance, fader, bass, mid and treble frequency adjustments as well as a non-fading subwoofer
output for opmum sound staging.
NOTE:
AMP-CH5 Module AMP-CH5 Harness
OEM Amp Bypass Harness AMP-CH5 Encoder/Bass Knob
Audio from the factory backup sensors is not retained.
1. Carefully remove the trim bezel
around the radio and instrument
cluster. Use a plasc pry tool and go all
the way around the trim to pop up the
clips.
2. Remove the 4 screws holding
the screen.
3. Unplug the 52-pin connector
behind the screen.
6. Find a suitable locaon to mount
the aermarket amplier(s). You
will need to run the following to the
aermarket amplier:
1) Power wires from the baery
2) An amp turn-on wire and RCA
cables from the AMP-CH5 module.
3) Speaker wires from the OEM
amplier locaon. OEM amplier
locaon can vary by vehicle. On
sedans and trucks, it is usually
located on the le boom side of
the dashboard. On SUVs in the cargo
area. Make sure you have enough
length wires and RCA cables.
4. Plug the 52-pin connector to the
mang connector on the AMP-CH5
T-harness.
5. Plug the other end of the
AMP-CH5 T-harness to the OEM
screen.
7. On a 2017 Dodge Charger, the OEM
amplier is at the le boom side
of the dashboard. Remove the panel
above the pedals by removing the
panel clips.
8. Locate the OEM amplier and
unplug the connectors.
9. Connect the speakers wires from
the aermarket amplier to the Amp
Bypass harness included in the kit.
Mate the connectors into the OEM
amplier harness connectors.
R
INTERFACING SOLUTIONS
AMP-CH5
OEM Amplier Replacement Interface for
Chrysler, Dodge, Jeep & RAM Vehicles with Uconnect Systems
INSTALLATION INSTRUCTIONS:
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
2 of 4 rev.092519
R
INTERFACING SOLUTIONS
AMP-CH5
OEM Amplier Replacement Interface for
Chrysler, Dodge, Jeep & RAM Vehicles with Uconnect Systems
10. Plug the RCAs to the AMP-CH5
module.
11. Plug the 20-pin AMP-CH5
T-harness connector and the RJ11
encoder/bass knob connector to
the AMP-CH5 module.
12. Complete the connecons on the
aermarket amplier and mount the
amplier.
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
3 of 4 rev.092519
14. Encoder/Bass Knob Funcons:
- Press to turn ON/OFF Loudness funcon
- Turn to adjust subwoofer level
- Press and hold to enter programming mode
15. For vehicle specic wiring connecons of the OEM
Amp Bypass Harness, please visit
hps://www.cruxinterfacing.com/lisngs/amp-ch5/ or
scan the QR code:
13. Mount the encoder/bass knob to
the desired locaon.
R
INT ERFACIN G S OLUT ION S
Gold Series
To Vehicle
Harness
To Headunit
Aftermarket Amplier
22 Pin White
16 Pin Black
10 Pin Gray
To
OEM
Amplier
Harness
Encoder /
Bass Knob
Visit www.cruxinterfacing.com/????
for vehicle specic wiring instructions
of the OEM Amplier Bypass Harness
Front
Rear
Sub
Amp Turn On
(use to prevent turn on pop)
INSTALLATION DIAGRAM:
