Seite 1/3
119
SoundwebTM
SoundwebSoundweb
SoundwebSoundweb
SoundwebTMTM
TMTMTM 9012 9012
9012 9012
9012
Installation Guide
120
SoundwebTM
v1.0 MR/JMK 4th November 1999
Useful Information
We have written this guide with the aim of helping installers and sound engineers alike to
get the most out of the 9012. We recommend that you read this manual, particularly the
section on mechanical installation, before attempting to operate the unit.
We welcome any comments or questions regarding the 9012 or other BSS products, and
you may contact us at the address or World Wide Web site given below.
BSS Audio:
Cranbourne House,
Cranbourne Industrial Estate,
Potters Bar,
Hertfordshire,
EN6 3JN.
http://www.bss.co.uk/
Tel: +44 (0)1707 660667 Fax: +44 (0)1707 660755
Installation
The 9012 is a wall mounted controller which, with the rotary switch, can be used to
control a source selector or parameter preset bar in the main system, and with the rotary
level control alter the level of the gain object, for example.
A sticker sheet is provided with the unit, which should cover most locational
requirements. The sheet covers 4 languages: English, French, German and Spanish.
The unit is mounted into a standard UK light switch wall box; and dimensions of the unit
are shown below. The pitch between the fixing hole centres is 60mm. Mounting screws
are provided.
Wiring
Wiring follows the standard control input wiring for a 9088, shown below. The printing on
the PCB also shows the correct wiring convention. The cable used should be regular
audio cable, or any quality shielded twin-core cable.
121
SoundwebTM
through wall to
Soundweb units
Example setup
Shown below is a typical Soundweb setup for use with the 9012 wall panel.
Parts for the 9012 are also available as spares, should you wish to design your own
control panels.
BSS Part numbers are:
Source switch: DH10007
Level pot: DM10018
Please contact BSS sales for more details.
