DPR 522
User Manual
2
This equipment has been tested and found to comply with the following European and
international Standards for Electromagnetic Compatibility and Electrical Safety:
Radiated Emissions (EU): EN55013 (1990) Associated Equipment
RF Immunity (EU): EN50082/1 (1992) RF Immunity, Fast Transients ESD
Mains Disturbance (EU): EN61000/3/2 (1995)
Electrical Safety (EU): EN60065 (1993)
Radiated Emissions (USA): FCC part 15 Class B
Electrical Safety (USA): UL813/ETL (1996) Commercial Audio Equipment
Electrical Safety (CAN): UL813/ETLc (1996) Commercial Audio Equipment
IMPORTANT SAFETY INFORMATION
DO NOT REMOVE COVERS. NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL. THIS EQUIPMENT MUST BE EARTHED.
IT SHOULD NOT BE NECESSARY TO REMOVE ANY PROTECTIVE EARTH OR SIGNAL CABLE SHIELD
CONNECTIONS TO PREVENT GROUND LOOPS. ANY SUCH DISCONNECTIONS ARE OUTSIDE THE
RECOMMENDED PRACTISE OF BSS AUDIO AND WILL RENDER ANY EMC OR SAFETY CERTIFICATION
VOID.
For continued compliance with international EMC legislation ensure that all input and output cables are wired
with the cable screen connected to Pin 1 of the XLR connectors and/or the jack plug sleeve. The input XLR Pin
1 and the side-chain input jack socket sleeve are connected to the chassis via a low value capacitor, providing
high immunity from ground loops whilst ensuring good EMC performance.
V 1.0 JMK 11 June 1997
Please read
We have written this manual with the aim of helping installers, sound engineers and musicians alike to get the
most out of the DPR-522. We recommend that you read this manual, particularly the section on installation,
before attempting to operate the unit.
The manual is split into two main sections. The first deals with quick reference information, regarding the
functions and operation of the unit, while the second covers a more general background to use and application
of the DPR-522.
We welcome any comments or questions regarding the DPR-522 or other BSS products, and you may contact
us at the address or World Wide Web site given in the warranty section.
3
Contents
Contents
1.0 Mechanical installation 5
2.0 Mains Power Connection 6
2.1 Mains Power 6
3.0 Introduction 7
4.0 Unpacking 7
5.0 Audio Connections 10
5.1 Main Inputs 10
5.2 Main Outputs 10
5.3 Key returns 11
5.4 Key send 12
6.0 Control Operations 13
6.1 Channel In 13
6.2 Key filter 13
6.3 Width 13
6.4 Key listen 14
6.5 Ext key 14
6.6 Threshold 14
6.7 Key level meter 15
6.8 Range 15
6.9 Attack 16
6.10 ADE 16
6.11 Hold 17
6.12 Release 17
6.13 Open check 17
6.14 Duck mode 18
6.15 Stereo link 18
6.16 Gate open indicator 19
6.17 Key send connector 20
6.18 Key return connector 20
6.19 Control connector 20
