Installation Guide
112
SoundwebTM
Regulatory Information
An example of this equipment has been tested and found to comply with the following European
and international Standards for Electromagnetic Compatibility (only when used with a metal
wallbox).
Radiated Emissions (EU): EN55022 (1990) Associated Equip.
Immunity (EU): EN50082/1 (1992) RF Immunity, Fast
Transients ESD
Radiated Emissions (USA): FCC part 15 Class A
v1.0 PW/JMK 21st March 1999
Important safety information - read and follow
It should not be necessary to remove any protective earth or signal cable shield
connections to prevent ground loops. Any such disconnections are outside the
recommended practice of BSS Audio, and will render the EMC certificate void.
We have written this guide with the aim of helping installers and sound engineers alike to
get the most out of the 9010. We recommend that you read this manual, particularly the
section on installation, before attempting to operate the unit.
We welcome any comments or questions regarding the 9010 or other BSS products, and
you may contact us at the address or World Wide Web site given in the warranty section.
Mechanical Installation
The 9010 is designed to fit into a standard 3-gang US wallbox. Screws are provided to fix
the unit in place. An optional bezel is available to ‘dress’ the edges of the panel if
required.
Dimensions of the unit are shown below. BSS recommend the use of a metal wall box to
ensure that the installation meets necessary EMC standards. If you require suitable
wallboxes, contact your distributor
for part Z-010-BOX.
113
SoundwebTM
•Connect a 24v DC power supply to the
Power/Mic/Logic screw terminal block. Up to three
more 9010’s may be powered via network cabling
from the Net Out of the 9010 which has the power
supply connected (depending on cable length). Refer
to diagrams on page 7 for more details.
•If it is inconvenient to cable a DC feed into the wallbox for the 9010, power may be
applied via the network cable (on the Net In side), by using the Soundweb 9011 Power
Interface to inject 24v DC from the power supply. Up to three more 9010’s may be
powered via network cabling from the Net Out of the 9010 which has the power supply
connected (depending on cable length).
To assist calculating the maximum cable lengths between 9010s, refer to the spreadsheet
9010pwr.xls, which may be found in the soundweb designer installation, or on our
website.
Front panel LED functions
Activity (yellow)Activity (yellow)Activity (yellow)Activity (yellow)Activity (yellow)
Irregular Flashing - This LED indicates data transfer
Sync (green)Sync (green)Sync (green)Sync (green)Sync (green)
Steady - This indicates the presence of one or more valid network connections.
Flashing - There is a problem with the incoming network signal - possibly the maximum
cable length has been exceeded.
Master (yellow)Master (yellow)Master (yellow)Master (yellow)Master (yellow)
Flashing - The network is initialising. If it continues to flash for more than a few seconds,
there is a cabling fault - either a double ring error or a problem with one of the cable
connectors.
Steady - This unit has become the clock master for the network.
Off - This unit is to the master’s clock.clienting
Power
The 9010 requires 24v DC to be supplied
externall . There are twoy
ways of getting power into the unit:
