FDS 355
User Manual
2
V 2.0 JMK 13th October 1997
Software version 1.10 and above
We have written this manual with the aim of helping installers and sound engineers to get to grips with the
FDS-355 and obtain its maximum capability. If you are new to BSS products, we recommend that you begin at
the start of the manual.
We welcome any comments or questions regarding the FDS-355 or other BSS products, and you may contact us
at the address or World Wide Web site given in the warranty section.
This equipment has been tested and found to comply with the following European and international Standards
for Electromagnetic Compatibility and Electrical Safety:
Radiated Emissions (EU): EN55013 (1990) Associated Equipment
RF Immunity (EU): EN50082/1 (1992) RF Immunity, Fast Transients ESD
Mains Disturbance (EU): EN61000/3/2 (1995)
Electrical Safety (EU): EN60065 (1993)
Radiated Emissions (USA): FCC part 15 Class B
Electrical Safety (USA): UL813/ETL (1996) Commercial Audio Equipment
Electrical Safety (CAN): UL813/ETLc (1996) Commercial Audio Equipment
IMPORTANT SAFETY INFORMATION
DO NOT REMOVE COVERS. NO USER SERVICABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL. THIS EQUIPMENT MUST BE EARTHED.
IT SHOULD NOT BE NECESSARY TO REMOVE ANY PROTECTIVE EARTH OR SIGNAL CABLE SHIELD
CONNECTIONS TO PREVENT GROUND LOOPS. ANY SUCH DISCONNECTIONS ARE OUTSIDE THE
RECOMMENDED PRACTISE OF BSS AUDIO AND WILL RENDER ANY EMC OR SAFETY CERTIFICATION
VOID.
For continued compliance with international EMC legislation ensure that all input and output cables are wired
with the cable screen connected to Pin 1 of the XLR connectors. The input XLR Pin 1 is connected to the
chassis via a low value capacitor, providing high immunity from ground loops whilst ensuring good EMC
performance.
3
Quick Start - Reference 5
FDS-355 Omnidrive 5
1.0 Introduction 8
1.1 OMNIDRIVETM Compact
Loudspeaker Management System 8
1.2 Other features 8
1.3 Voltage setting 9
1.4 AC Power fusing 9
2.0 Unpacking 9
3.0 Mechanical Installation 10
4.0 Mains Power Connection 11
4.1 Mains power 11
5.0 Controls 12
5.1 Input section 12
5.2 Output section 14
5.3 Rear panel 15
Screen Layout 16
6.0 Default Screen 20
7.0 Utilities Menu 21
8.0 Inputs Menu 25
9.0 Outputs Menu 26
10.0 EQ Screens 30
11.0 Store and Recall 32
11.1 Storing 32
11.2 Recalling 33
12.0 System Headroom Management 34
Contents
Contents
