AH-64 Apache™
Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
RTF
2
EN
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before
operating. Failure to operate the product correctly can result in damage to the product, personal property and
cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic
mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage
to the product or other property. This product is not intended for use by children without direct adult supervision. Do
not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon
Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow
all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid
damage or serious injury.
• Always keep a safe distance in all directions around
your model to avoid collisions or injury. This model is
controlled by a radio signal subject to interference from
many sources outside your control. Interference can
cause momentary loss of control.
• Always operate your model in open spaces away from
full-size vehicles, traffi c and people.
• Always carefully follow the directions and warnings for
this and any optional support equipment
(chargers, rechargeable battery packs, etc.).
• Always keep all chemicals, small parts and anything
electrical out of the reach of children.
• Always avoid water exposure to all equipment not
specifi cally designed and protected for this purpose.
Moisture causes damage to electronics.
• Never place any portion of the model in your mouth as it
could cause serious injury or even death.
• Never operate your model with low transmitter
batteries.
• Always keep aircraft in sight and under control.
• Always move the throttle fully down at rotor strike.
• Always use fully charged batteries.
• Always keep transmitter powered on while aircraft is
powered.
• Always remove batteries before disassembly.
• Always keep moving parts clean.
• Always keep parts dry.
• Always let parts cool after use before touching.
• Always remove batteries after use.
• Never operate aircraft with damaged wiring.
• Never touch moving parts.
NOTICE
Meaning of Special Language
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon
Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product.
The following terms are used throughout the product literature to indicate various levels of potential harm when
operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or
no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a
possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage,
and serious injury OR create a high probability of superfi cial injury.
Safety Precautions and Warnings
Age Recommendation: Not for children under 14 years. This is not a toy.
WARNING AGAINST COUNTERFEIT PRODUCTS: If you ever need to replace your Spektrum receiver found in
a Horizon Hobby product, always purchase from Horizon Hobby, LLC or a Horizon Hobby authorized dealer to
ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards,
but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with
DSM or Spektrum.
3EN
Box Contents
• Blade® AH-64 Apache
• Spektrum™ DXe Transmitter (RTF Only)
• 400mAh 2S 7.4V 30 C Li-Po Battery
• E-fl ite® 2-3 Cell LiPo Balancing Charger, 0.65A with AC
to 12VDC Power Supply
• 4 AA Batteries (RTF Only)
Table of Contents
Length 14.76 in (375mm)
Height 3.74 in (95mm)
Main Rotor Diameter 12.51 in (318mm)
Tail Rotor Diameter 2.56 in (65mm)
Flying Weight 6.70 oz (190 g)
Specifications
Components RTF BNF
Airframe Blade® AH-64 Apache Included Included
Main Motor 6000kv Brushless Outrunner Installed Installed
Tail Motor 4800k Brushless Outrunner Installed Installed
Receiver Spektrum AR6335 Installed Installed
ESC Dual Brushless Installed Installed
Battery 400mAh 2S 7.4V 30 C Li-Po Battery Included Included
Charger 2-3 Cell LiPo Balancing Charger, 0.65A Included Included
Transmitter DSM2®/DSMX® Compatible Transmitter DXe Included Required
To register your product online,visit www.bladehelis.com
Safety Precautions and Warnings ......................................2
Table of Contents ..............................................................3
Box Contents .................................................................... 3
First Flight Preparation ...................................................... 4
Flying Checklist ................................................................4
Charging Warnings............................................................4
Battery Charging ............................................................... 4
Installing the DXe Transmitter Batteries (RTF) .................... 5
DXe Transmitter Control (RTF) ........................................... 5
Transmitter Setup Table (BNF) ........................................... 6
Installing the Flight Battery ............................................... 8
Transmitter and Receiver Binding ...................................... 8
SAFE® Technology ............................................................ 9
Flight Mode and Rate Selection ......................................... 9
Panic Recovery ................................................................. 9
Throttle Hold ................................................................... 10
Control Tests ................................................................... 10
Understanding the Primary Flight Controls ...................... 11
Flying the AH-64 Apache ................................................. 12
Advanced Settings .......................................................... 12
Servo Adjustment ...........................................................14
Trim Flight ......................................................................15
Post-Flight Inspection and Maintenance Checklist ........... 16
Troubleshooting Guide .................................................... 16
Exploded View ................................................................ 18
Parts Listings ..................................................................18
Optional Parts ................................................................. 18
Limited Warranty ............................................................ 19
Warranty and Service Contact Information ...................... 20
FCC Information .............................................................. 20
IC Information ................................................................. 20
Compliance Information for the European Union .............. 21
