Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
®
®
2
EN
• Always keep a safe distance in all directions around your model to avoid colli-
sions or injury. This model is controlled by a radio signal subject to interference
from many sources outside your control. Interference can cause momentary loss
of control.
• Always operate your model in open spaces away from full-size vehicles, traffi c
and people.
• Always carefully follow the directions and warnings for this and any optional
support equipment (chargers, rechargeable battery packs, etc.).
• Always keep all chemicals, small parts and anything electrical out of the reach
of children.
• Always avoid water exposure to all equipment not specifi cally designed and
protected for this purpose. Moisture causes damage to electronics.
• Never place any portion of the model in your mouth as it could cause serious
injury or even death.
• Never operate your model with low transmitter batteries.
• Always keep aircraft in sight and under control.
• Always move the throttle fully down at rotor strike.
• Always use fully charged batteries.
• Always keep transmitter powered on while aircraft is powered.
• Always remove batteries before disassembly.
• Always keep moving parts clean.
• Always keep parts dry.
• Always let parts cool after use before touching.
• Always remove batteries after use.
• Never operate aircraft with damaged wiring.
• Never touch moving parts.
Age Recommendation: Not for children under 14 years. This is not a toy.
WARNING AGAINST COUNTERFEIT PRODUCTS: If you ever need to replace a Spektrum component found in a Horizon Hobby product, always purchase from
Horizon Hobby, LLC or a Horizon Hobby authorized dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and
warranty with regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM or Spektrum technology.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly
can result in damage to the product, personal property and cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this Product
in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct
adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual
contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup
or use, in order to operate correctly and avoid damage or serious injury.
The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury.
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high probability of
superfi cial injury.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit
horizonhobby.com and click on the support tab for this product.
Meaning of Special Language
Safety Precautions and Warnings
As of this printing, you are required to register with the FAA if you own this product. For up-to-date information on how to register with the FAA, please visit
https://registermyuas.faa.gov/. For additional assistance on regulations and guidance on UAS usage, visit knowbeforeyoufl y.org/.
3EN
Box Contents:
• Blade 360 CFX 3S
®
Table of Contents
First Flight Preparation ........................................................................................ 4
Flying Checklist .................................................................................................. 4
Low Voltage Cutoff (LVC) ...................................................................................... 4
Transmitter Setup ................................................................................................ 4
Installing the Flight Battery .................................................................................. 6
Transmitter and Receiver Binding ......................................................................... 6
Throttle Hold ........................................................................................................ 6
Control Tests ........................................................................................................ 7
Pre-Flight Checklist ............................................................................................. 8
Flying the Blade 360 CFX 3S ............................................................................... 8
Gyro Gain Adjustment .......................................................................................... 8
Blade Helicopter Belt Tension ............................................................................... 8
Post-Flight Inspections and Maintenance ............................................................. 9
Troubleshooting Guide ....................................................................................... 12
Limited Warranty ............................................................................................... 12
Warranty and Service Contact Information ......................................................... 13
Compliance Information for the European Union ................................................. 13
FCC Information ................................................................................................. 13
IC Information .................................................................................................... 13
Exploded Views .................................................................................................. 50
Parts List ........................................................................................................... 52
Optional Parts .................................................................................................... 53
Airframe Blade® 360 CFX 3S
Motor Brushless Outrunner, 3400 Kv
Receiver Spektrum™ AR636A AS3X®
ESC 45-Amp Brushless ESC
Swash Servos Digital Cyclic Servo 12 g Metal Gear
Tail Servo Digital Tail Servo 12 g Metal Gear
Length
26.4 in (670mm)
Height
8.5 in (215mm)
Main Rotor Diameter
31.89 in (810mm)
Tail Rotor Diameter
6.9 in (175mm)
Flying Weight
30 oz (850 g)
Specifi cations
Included Components Required Components
To receive product updates, special offers and more, register your product
at www.bladehelis.com
Battery 3000 mAh 3S 11.1V 30C LiPo (EFLB30003S30)
Charger Li-Po Balancing Charger
Transmitter Full Range DSM2®/DSMX® technology transmitter (DXe and up)
