Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
2
EN
WARNING AGAINST COUNTERFEIT PRODUCTS: If you ever need to replace a Spektrum
™ component found in a
Horizon Hobby product, always purchase from Horizon Hobby, LLC or a Horizon Hobby authorized dealer to ensure
authentic high-quality Spektrum
™ product. Horizon Hobby, LLC disclaims all support and warranty with regards, but not
limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM
® or Spektrum™
technology.
As the user of this product, you are solely responsible for operating in a manner that does not endanger yourself and
others or result in damage to the product or the property of others.
• Always keep a safe distance in all directions around
your model to avoid collisions or injury. This model is
controlled by a radio signal subject to interference from
many sources outside your control. Interference can
cause momentary loss of control.
• Always operate your model in open spaces away from
full-size vehicles, traffic and people.
• Always carefully follow the directions and warnings
for this and any optional support equipment (chargers,
rechargeable battery packs, etc.).
• Always keep all chemicals, small parts and anything
electrical out of the reach of children.
• Always avoid water exposure to all equipment not
specifically designed and protected for this purpose.
Moisture causes damage to electronics.
• Always engage throttle hold before approaching the
aircraft.
• Never place any portion of the model in your mouth as it
could cause serious injury or even death.
• Never operate your model with low transmitter batteries.
• Always keep aircraft in sight and under control.
• Always move the throttle fully down at rotor strike.
• Always use fully charged batteries.
• Always keep transmitter powered on while aircraft is
powered.
• Always remove batteries before disassembly.
• Always keep moving parts clean.
• Always keep parts dry.
• Always let parts cool after use before touching.
• Always remove batteries after use.
• Never operate aircraft with damaged wiring.
• Never touch moving parts.
Age Recommendation: Not for children under 14 years. This is not a toy.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before
operating. Failure to operate the product correctly can result in damage to the product, personal property and
cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic
mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage
to the product or other property. This product is not intended for use by children without direct adult supervision. Do
not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon
Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow
all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid
damage or serious injury.
The following terms are used throughout the product literature to indicate various levels of potential harm when
operating this product:
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage,
and serious injury OR create a high probability of superficial injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a
possibility of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no
possibility of injury.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon
Hobby, LLC. For up-to-date product literature, visit horizonhobby.com or towerhobbies.com and click on the support or
resources tab for this product.
Meaning of Special Language
Safety Precautions and Warnings
3EN
Table of Contents
Length 14.4 in (366mm)
Height 5 in (127 mm)
Main Rotor Diameter 14.2in (360 mm)
Tail Rotor Diameter 2.5 in (64mm)
Flying Weight 7.1oz (200 g)
Specifications
Components BNF- Basic
(BLH54500)
Airframe Blade 150 S Smart Included
Main Motor 1310-5800Kv Brushless (BLH3417) Installed
Tail Motor Brushless (BLH9311) Installed
Receiver Blade 150 S AS3X®/ SAFE® receiver (SPMAR6250MHXC) Installed
ESC Dual Brushless ESC (SPMXAE2020) Installed
First Flight Preparation 4 ......................................................
Flying Checklist 4 ................................................................
Transmitter Setup Table .................................................... 4
Installing the Flight Battery 5 ...............................................
Transmitter and Receiver Binding 6 ......................................
SAFE Technology .............................................................. 7
Flight Mode and Rate Selection 7 .........................................
Panic Recovery 7 .................................................................
Throttle Hold 8 ....................................................................
Control Tests .................................................................... 8
Understanding the Primary Flight Controls 9 ........................
Flying the 150 S Smart 10 ...................................................
Advanced Tuning (Forward Programming) 11 .......................
Advanced Tuning (Non-Forward Programming)................ 12
Servo Adjustment .......................................................... 13
Trim Flight 14 ......................................................................
Calibration Procedure 15 .....................................................
Post-Flight Inspection and Maintenance Checklist 16 ...........
Troubleshooting Guide 16 ....................................................
Exploded View ................................................................ 18
Parts List 18 ........................................................................
Recommended Parts List 18 ................................................
Optional Parts List 19 ...........................................................
Limited Warranty ............................................................ 19
Warranty and Service Contact Information 20 ......................
FCC Information 20 ..............................................................
IC Information 21 .................................................................
Compliance Information for the European Union 21 ..............
Box Contents
• Blade®
150 S Smart (BLH54500)
Required Items
• DSM2 / DSMX compatible transmitter
• 450-500mAh 3S 11.1V 50C Li-Po Battery IC2
• 3S Li-Po compatible battery charger
