Wimberley, Inc. - - - Phone: 1 434 529 8385
1750 Broadway St Toll Free: 1 2746 -888-665-(USA & Canada)
Charlottesville, VA
22902 USA www.tripodhead.com info@tripodhead.com
Dimensions (coiled-up): (L x W x H): in 9” x x 8” 1.5”
Maximum extended length: 23 inches
Weight: 7.9 oz (224g)
Extending the reach of your Plamp II
If you need more reach one option is to attach the Plamp II to an object other than your own
tripod. Another option is to extend the length of your Plamp by adding extra links to its arm.
We sell a long extension (part # PP 222). The trade off to adding extra length to your Plamp 12” - -
is that it becomes less rigid.
Package Contents: The Plamp II (Qty 1)
Tips and Tricks
PP- 222
12” Plamp II Extension ($8.00)
5 Year Warranty – See www.tripodhead.com/warranty.cfm for complete details
Reconnecting the ball and socket joints of your Plamp- -
If the articulating arm is bent forcefully beyond its normal range of motion, it is
possible for the segments to pop out of joint. Fixing this is simply a matter of
popping the segments back together. If you have a hard time reconnecting the
joints (we realize it takes quite a bit of force), you can warm the socket (female)
end in hot water (boiling or near boiling). This will cause the socket to expand -
and make it easier to pop the ball portion into place.
Camera Generated Vibrations
If your Plamp is secured to your cameras tripod, it is
possible for vibrations from mirror slap to travel through
the Plamp to your subject, negatively affecting image
sharpness. This issue is magnified when you add the
12” extension to the plamp.
We strongly advise using mirror lock-up
(if your camera has this feature)
Alternately, you can attach the Plamp II to an object not
connected to your camera such as our plamp stake
(part# PP 300) or a second tripod.-
These vibrations are not a concern when
Holding objects that are not in the picture
(e.g. reflectors & diffusers).
Wimberley, Inc. ©2017, All Rights Reserved
Recess
p cylindrical
ch as small
and branches.
Foam Jaw Inserts
Grip delicate objects without damage.
Thumbscrew Turn the thumbscrew to open or close the jaws of the clip.
Compared to typical spring activated clips, thumbscrew activated clip jaws allow -
for more finesse when holding delicate objects, as well as much higher maximum
clamping force when desired.
The Plamp Clip
Clip Body
The clip is custom designed to hold
anything from the most delicate plant stems
to heavy reflectors and diffusers. It is made of
nearly unbreakable ST Nylon
Jaw opening band
This elastomer band puts tension on the clamp s moving ’
jaw so that it opens when you loosen the thumbscrew. It
is made of weather/UV resistant EPDM
Special notches in the clip s jaws grab the steel rim on reflectors and ’
diffusers, providing a secure, slip free attachment (applies to typical cloth-
reflectors/diffusers with steel perimeter hoop). This new feature is a drastic
improvement over other clips currently on the market.
The firm grip allows you to make precise adjustments to the angle of a reflector.
You can even hold diffusers cantilevered straight out above your subject
Important Feature
Reflector/Diffuser Notches
PP- 210
Plamp Rod Extension ($19.00)
Fine control using the Plamp Rod Extension
For extra dexterity try using the Plamp Rod Extension in con-
junction with the Ground Plamp or a Plamp II connected to a
tripod leg or Plamp Stake.
Rod Extension
Plamp II
Ground Plamp
Move desirable background or
foreground elements
into the picture.
Move distracting back-
ground or foreground
elements out of the way
Made in USA
®
The Plamp II PP-200
Using Reflectors and Diffusers
The Plamp II will hold reflectors and diffusers in any position without problems. 12”
20” reflectors, which are generally held in a relatively vertical position and not fully
cantilevered out, can be held and positioned confidently with a single Plamp.
20” Diffusers can be cantilevered above your subject using one Plamp, however
it is pushing The limits of the Plamp s holding capacity. It might take some ’
Experimentation to find a position that will hold. Aggressively bending
the joints of the Plamp back and forth until they start making a louder
squeaking noise will temporarily increase the holding power of the Plamp.
For diffusers larger than in diameter we suggest using Two Plamps. 20”
(Two Ground Plamps or a Ground Plamp and a Plamp II
clamped to the Ground Plamp)
Please visit our site for more in depth information -
about the Plamp II including a video tutorial.
www.tripodhead.com/products/plamp main.cfm-
Video Available
30” Reflector
Ground Plamp
About the Plamp II
The Plamp II is an articulating arm used to hold macro subjects and other useful objects. The large black clamp on one
end attaches to your tripod leg, Plamp Stake, or any other suitable solid object. While the other end (with the small clip)
grasps the object you wish to hold.
12” Reflector
24” Reflector
Extension Tube
Ground Plamp
Steady wind blown -
plants for ambient light
photography
Move your subject into the
desired position for lighting
Hold reflectors, diffusers, small
lighting units or shades to prevent
lens flares
Change the orientation of your
subject to make an impossible
camera angle into an easy one
Move your subject to isolate it
from distracting background or
foreground elements
Move distracting background
or foreground elements out
of the way
Plamp Stake
Ground Plamp
