ZEON 12-S Platinum Winch
Ultimate Performance winch equipped with Spydura Pro
synthetic rope and a 12,000 lb. pulling capacity.
Warn Industries, Inc. 12900 S.E. Capps Road, Clackamas, OR USA 97015-8903 • www.warn.com
Now the world’s most technologically advanced winch—the ZEON Platinum™—comes in a 12,000
pound capacity version spooled with extra-strong SpydurPro synthetic rope. Already packed with
performance features, ZEON Platinum 12-S features the Advanced Wireless Remote that puts winch,
clutch and accessory control in the palm of your hand. And now, with the addition of Spydura Pro, you
can really see what it means to be winching’s top dog.
All-new high-speed motor, stronger gears, and heat-treated ring
gear deliver 20% faster line speed, best-in-class efficiency, and
our highest durability rating
The Advanced Wireless Remote gives you total control in the
palm of your hand, allowing you to control the winch and up to
two accessories. This sophisticated, advanced remote provides
operator feedback on vehicle battery charge and winch motor
temperature, controls operation of the winch clutch, and more.
Includes USB charging cable and car charger adapter
Remote Controlled Clutch is engaged and disengaged with the
Advanced Wireless Remote. The remote controls winch-in, winch-
out, and freespool operations. No more engaging a manual clutch,
with frozen fingers while standing in the mud
Durable aluminum structure with flat black powder-coated finish
and stainless steel fasteners delivers durability and maximum
corrosion resistance–exceeding 400 hours of salt-spray testing
Large diameter alloy winch drum with steel sleeve is strong, light
weight, reduces rope wear, and has an integrated rope anchor for
easy rope installation
Extreme waterproofing meets rigorous IP68 standards—the highest
rating in the WARN Truck/SUV winch lineup
Convertible control pack can be attached to the winch or remotely
mounted, allowing for various winch mounting options and looks
(Relocation kit required and sold separately). The new-style control
pack with contactor and advanced controls gives you extreme
reliability and weather resistance
Includes 80’ of 3/8” Spydura Pro synthetic rope and aluminum
hawse failead with powder-coat finish
Proprietary and strongest-in-class Spydura Pro synthetic rope is
found on many military vehicles. This rope features a urethane-
coated 12-strand braid, heat treated under tension. A 20 ft. Nomex
heat sleeve protects the rope on the layer nearest the drum
PN 95960
12V DC performance specs (first layer of drum)
Line Pull Line Speed Motor
Lbs. (Kg) Ft./min. (M/min.) Current
0 32.9 (10.02) 57 amps
2000 (910) 15.1 (4.6) 132 amps
4000 (1810) 9.9 (3.01) 200 amps
6000 (2720) 8.9 (2.71) 261 amps
8000 (3630) 7.8 (2.37) 321 amps
10000 (4536) 5.4 (1.64) 381 amps
12000 (5440) 4.5 (1.37) 446 amps
Customer Service (North America):
1-800-543-9276
International Sales Support:
+1 503 722 1200
www.warn.com
Warn Industries, Inc.
12900 S.E. Capps Road,
Clackamas, OR USA 97015-8903
®
Winch model: ZEON 12-S Platinum
Part numbers: 95960
Rated line pull: 12,000 lbs. (5443 kg) single-line
Motor: 12V DC, series wound
Electrical controls: Contactor
Remote Control: Advanced Wireless
Geartrain: 3-stage planetary
Gear ratio: 162:1
Clutch (freespooling): Rotating ring gear
Brake: Automatic mechanical cone
Drum diameter/Length: 3.15”/9.0” (80mm/229mm)
Rope: 3/8” x 80’ (9.52mm x 24.38m) Spydura Pro™ synthetic
Fairlead: Aluminum hawse with powder-coat finish
Recommended Battery: 650 CCA minimum for winching
Battery leads: 2 gauge, 72” (1.83m)
Finish: Satin-black powder coat
Warranty: Limited lifetime
SPECIFICATIONS
Winch dimensions:
Integrated configuration: 24.25” L x 7.15” D x 10.52” H
(615.9mm L x 181.6mm D x 267.1mm H)
Low-profile configuration: 24.25” L x 7.15” D x 7.84” H
(615.9mm L x 181.6mm D x 199.02mm H)
Mounting bolt pattern:
10.0" x 4.5" (254mm x 114.3mm)
ZEON PLATINUM. THE TOUGHEST, MOST TECHNOLOGICALLY-ADVANCED WINCH ON THE TRAIL TODAY.
HIGH P ERFORM AN CE PA CKAGE
All-new high-speed motor, stronger
gears, and heat-treated ring gear
deliver 20% faster line speed, best-
in-class efficiency, and our highest
durability rating*
T HE A DVANCED WIRELES S R EMOT E
Allows you to control the winch and up to two
accessories, plus it provides operator feedback
REMOT E CONT ROLLED
CLUT CH
Engage and disengage
with the Advanced
Wireless Remote. The
Remote controls winch-in,
winch-out, and freespool
operations. No more
engaging a manual clutch
while knee deep in mud.
EXT REME DURA BILIT Y
Our highest durability
rating—2X that of the
previous generation*.
4340 steel gears, durable
structure and finish
delivers maximum corrosion
resistance–exceeding 400
hours of salt-spray testing
EXT REME
WAT ERP RO OF ING
Meets rigorous IP68
standards—the highest
rating in the WARN Truck/
SUV winch lineup
AUT OM AT IC M ECHANICAL CONE BRA KE
High-strength brake with steel sleeve-in-drum
design is durable and holds the full rated load.
SYNT HET IC ROP E
80 ft. of severe-duty, industrial-
grade Spydura Pro synthetic rope
found on many military vehicles
*Performance
specs available at
warn.com
CONTACT OR A ND A DVAN CED CONT R OLS
Ratchets up the reliability factor. Controls are potted and
sealed for the ultimate in waterproof protection
LA RGE DIA MET ER DRUM
Zinc/aluminum alloy winch drum is strong, light
weight, reduces rope wear, and has an integrated
rope anchor for easy rope installation
HAWSE F AIR LEAD
Lightweight aluminum, with
powder-coat finish
