VRX 35 AND 35-S WINCH
All-new winch, all-new levels of performance
and reliability
Warn Industri
VRX 35 includes 50’ of durable 7/32”
steel rope, roller fairlead, and zinc-
plated hook
VRX 35-S includes 50’ of lightweight,
easy-to-handle 3/16” synthetic rope,
hawse fairlead, and zinc-plated hook
Complete IP68 waterproof sealing
keeps all the elements out
• Hard-working 3,500 lb. capacity
Semi-gloss black powder-coated
finish and stainless steel fasteners
for corrosion resistance
New clutch design based on
legendary WARN 4WD hub lock
know-how
Load-holding mechanical brake for
great control
The WARN VRX35 and VRX 35-S oer premium features and outstanding value. Theyre perfect for
both larger ATVs as well as sport Side x Sides. Features include all-metal, IP68 waterproof construction,
an all-metal gear train, and a new clutch design based on WARN 4WD hub lock know-how. Whether on
the trail or on the farm or ranch, the VRX 35 and VRX 35-S will let riders get more done.
• Durable all-metal construction
Smooth and reliable all-metal
three-stage planetary gear train
Handlebar-mounted rocker switch
Limited lifetime warranty
(mechanical), 3 year warranty
(electrical)
VRX 35, PN 101035
Winch model: VRX 35 or VRX 35-S
Part numbers: 101035 (VRX 35), 101030 (VRX 35-S)
Rated line pull: 3500 Lbs. (1588 kg) single-line
Motor: 12V DC permanent magnet
Sealing: IP68 waterproof
Geartrain: 3-stage planetary
Fasteners: All stainless steel
Rope: VRX 35: 50’ x 7/32”(15m x 5.5mm) steel,
VRX 35-S: 50’ x 3/16” (15m x 4.8mm) synthetic
Hook: Zinc Plated
Fairlead: VRX 35: Roller, VRX 35-S: Cast aluminum hawse
Primary Control: Handlebar-mounted rocker switch
Remote Control: Sold Separately
Brake: Mechanical brake
Mechanical Warranty: Limited lifetime
Electrical Warranty: 3 year
S P E C I F I C A T I O N S
D
E
F
A
B
C
13.2” (335.3mm)
3.07” (78 mm) 3.5” (88.9mm)
4.74” (120.5mm)
B
C
3.94” (100.2mm)
D
3.30” (83.9mm)
E
F
A
Mounting bolt pattern: 3.0x 4.87” (76mm x 124mm)
Line Pull Line Speed Motor Pull by layer:
Lbs. (Kg) Ft./min.
(M/min.)
Current layer/Lbs. (kg)
0 15.8 (4.8) 20 amps 1/3500 (1588)
500 (227) 13.4 (4.1) 41 amps 2/2934 (1331)
1000 (454) 11.2 (3.4) 60 amps 3/2525 (1145)
1500 (680) 79 amps 4/2216 (1005)9.3 (2.8)
2000 (907) 7.6 (2.3) 100 amps 5/1975 (896)
2500 (1134) 6.2 (1.9) 124 amps
3000 (1361) 5.0 (1.5) 155 amps
3500 (1588) 4.0 (2.1) 192 amps
WARN® VRX POWERSPORTS WINCHES
PREMIUM FEATURES WITHOUT THE PREMIUM PRICE
CORROSION
RESISTANT FINISH
POWERFUL,
HIGH-EFFICIENCY
MO T OR
3 STAGE
PLANETARY
GEAR T RAIN
MECHANICAL
BRAKE
LIMIT ED
LIFETIME
WARRANT Y
SYNT HET IC OR
ST EEL ROPE
ALL METAL,
WAT ERPROOF
CO NST RU CT ION
Customer Service (North America): 1-800-543-9276 International Sales Support: +1 503 722 1200
WARN INDUSTRIES, INC.
12900 S.E. Capps Road, Clackamas, OR USA 97015-8903
®
warn.com
HUB-ST YLE
CLUT CH DIAL
HANDLEBAR-MOUNT ED
ROCKER SWIT CH
