WARNINGS
During installaīon take care to adhere to workplace health and safety laws:
ā¢ Aī©ach the bracket to a rated load-bearing structure. NEVER MOUNT CAGE OR
BRACKET DIRECTLY TO A FALSE CEILING!
ā¢ Do not cut or drill any parts above head height. This should all be done using the
correct safety equipment at ī
oor level.
ā¢ Avoid overstretching which might result in the ladder īpping over.
ā¢ SWL (safe working load): 7kg
If you are unsure about the load-bearing capacity of the structure you are aī©aching the
bracket to, we recommend tesīng it with your body weight by hanging oī« it gently. If
you are uncomfortable doing this, it is probably not safe.
This product is a theī
deterrent and does not guarantee the security of your projector.
Alarm baī©eries should be tested at īme of installaīon and annually. Visionās liability is
limited to the terms set out in the warranty.
Vision is a partner in the TĆV SĆD product cerīī®caīon system. All applicable cerīī®caīon is
provided by TĆV. All products are designed and imported into the EU by āVisionā who is wholly
owned by Azlan Logisīcs Ltd, Registered in England Nr. 04625566 at āLion House, Pioneer Business
Park, Cliī
on Moor, York, YO30 4GHā
WEE/AB0047SY
PROJECTOR TM-CAGE TECHMOUNT
OWNERS MANUAL
Congratulaīons on your choice of the
Vision TM-CAGE TECHMOUNT. In order
to obtain the best performance please be
sure to read this ownerās manual and use
your product only in accordance with the
instrucīons. An electronic version of this
manual and further informaīon can be
found on www.visionaudiovisual.com
ENGLISH
1
CONTENTS
8 x Side Panels (Sold separately)
ī
1 x Top Plate
1 x Boī©om Plate
2 x Access Prevenīon Collars
2 x Disc Locks
2 x Keys
1 x Lock Hex Key
16 x Foam Blocks
2
ENGLISH
INSTALLATION INSTRUCTIONS
Note: For the most secure ī®t the cage should conform as closely as possible to the size
of projector.
1. Set boī©om plate on level, non-scratch surface. It doesnāt maī©er which way up it is.
2. Set four foam blocks on each corner of the boī©om plate.
3. Carefully put projector onto the foam blocks upside-down.
Note 1: Locate the foam blocks
so they ARE NOT pushing
funcīon buī©ons on the top
surface of the projector.
Note 2: The foam blocks come
in four thicknesses to allow for
projectors which do not have
a ī
at top surface. Adjust to
ensure the projector is level.
ENGLISH
3
4. Add side panels to LONG SIDES of boī©om plate.
Step 1:
Liī
boī©om plate and hook the side panel in the notch at the centre.
Step 2:
Slide panel towards a corner unīl it stops.
Step 3:
Repeat unīl two side panels are installed on each long side.
Note: If the projector lens
prevents all eight from being
installed then provided
the cage is a close ī®t it
should sīll be secure even
if only seven side panels are
installed. This is only true
if the projector cannot be
manoeuvred inside the cage.
4
ENGLISH
5. Fit top plate.
Step 1:
Locate the top plate over the projector and hook to the side panels already in place
one side at a īme. No force should be required.
Step 2:
Slide the side panels towards the centre unīl they stop.
ENGLISH
5
7. Aī©ach projector ceiling or wall mount.
8. Route cables down the projector bracket and plug in to projector.
9. Turn the projector on. Adjust the pitch and roll of the projector and īghten
adjustment bolts.
10. Fit access prevenīon collars
Gently locate in the notch at each end of the long side, then slide into place. The
8mm hole on the top surface should be directly over the 8mm hole in the top plate.
Note: This step is done
with the projector bracket
already in place in the
ceiling.
Vision brackets aī©ach to the
TM-CAGE top plate with the
pin-hex security bolts which
come with Vision brackets.
ENGLISH
7
