1 947704
ISSUE 3
VIP-9890-CB
Vandal Resistant IP DoorPhone/Intercom
INTRODUCTION
The VIP-9890-CB IP Talkback Doorphone /
Intercom allows communication to Valcom
FXS units (VIP-811, -812, -814) and SIP-enabled
telephone systems via an IP network. The
VIP-9890-CB combines a rugged; weather-
resistant talkback paging horn with a vandal-
resistant enclosure, which is ideally suited for
high-noise, exposed environments.
SPECIFICATIONS
Access Methods
PBX, FXO Port w/VIP-811
POTS telephone set w/VIP-811
Valcom M Cast Page Group
SIP – enabled telephone system
Features
RJ-45 for network connection
1 Form C contact
LED Status Indicator
Network activity LEDs
Power over Ethernet (PoE) 802.3af
compatible
Door Opening Contact Provided
Dimensions/Weight
Intercom Unit:
10.0” H x 12.5" W x 4" D
(25.4cm H x 31.75cm W x 10.2cm D)
Weight: 10.75lbs. (4.1 kg)
Network Interface:
2.0” H x 4.63" W x 9.13" D
(5.1cm H x 11.8cm W x 23.2cm D)
Weight: 0.80lbs. (0.36 kg)
Nominal Specifications
Input Impedance: 600 Ohms
Input Level: -10dBm
Output Impedance: 600 Ohms
Output Level: -10dBm nominal
Relay Current: 1AMP @ 24VDC
Nominal Power Requirements
Via 802.3af (PoE) Ethernet Switch Class 3
Environment
VIP-9890-CB Network Interface
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
VIP-9890-CB Intercom Unit:
Suitable for indoor or outdoor installation
Packing List
Qty Item
1 VIP-9890-CB Network Interface
1 VIP-9890-CB Intercom Unit
1 VSP Document
4 Tamper Hardware (Intercom unit only)
1 VIP172-RLY Relay Block
4 Wood Screws
2 947704
CAUTION: To reduce the risk of electric shock,
Do not remove cover.
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
Precautionary Designations
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses and can radiate
radio frequency energy and if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area may cause
harmful interference in which case the user
will be required to correct the interference at
his own expense.
INSTALLATION
Operation:
The VIP-9890-CB provides intercom access via
network connection to customer telephone
system or stand alone telephone set. Interface to
customer telephone system can be via SIP
registration to a Voice over IP (VoIP) telephone
system, or FXO port (when used with a VIP-811).
Pressing the call button on the intercom unit
initiates a call to a user-specified telephone
number, and the call assurance LED behind the
intercom unit face plate begins to flash. When
the call is answered, a hands-free
communications path is established to the
intercom unit, and the call assurance LED behind
the face plate remains lit. The form C relay
included with the VIP-9890-CB may be activated
by pressing the # key on the answering
telephone, with the relay typically being used to
activate door entry equipment.
Mounting
For enhanced protection against static
electrical discharge, it is recommended the
intercom unit shipped with the VIP-9890-CB
be installed onto a grounded electrical box, If
surface mounted, ground box to local ground.
The VIP-9890-CB Intercom unit is designed for
double gang FD electrical box mounting and must
be within 300 meters of the VIP-9890-CB
Network Interface. See NEMA OS 3-2002
sec.1.2.3.5 for FD box specifications.
The VIP-9890-CB Network Interface is designed
for wall mounting and must be within 100 meters
of the network switch. Using the wood screws
provided, secure the VIP-9890-CB Network
Interface to the wall. Remove the Intercom unit
from the packing container. Using a Phillips
screwdriver, remove the two screws securing the
front grille to the enclosure. Pre-drilled 13/64”
mounting holes in the back of the enclosure are
designed to fit a single gang, double gang or
octagon outlet box. If not attaching to an outlet
box, use the enclosure as a template. Hold the
enclosure in the desired position on the wall and
mark the location of mounting holes. Depending
on wall construction type, prepare the mounting
hole locations on the wall to securely attach the
enclosure.
Wiring may be inserted through the large hole in
the back of the enclosure, or through the
knockout hole in the top of the enclosure. Insert
wiring for signal connections and relay
connections (if used) through desired hole. Use
mounting hardware (not included) appropriate for
the wall type to securely mount the enclosure to
the wall.
After making signal connections, align the
grille/speaker assembly with the enclosure.
Install the four supplied tamper-resistant screws
through the grille into the enclosure. Use a 1/8”
security hex bit (not included) to tighten the
screws securely.
Power Connections
The only method of powering a VIP-9890-CB
Network Interface is via a Power over Ethernet
(PoE) switch or power injector meeting the
802.3af specification.
Make all required signal connections before
connecting to Ethernet switch or power injector
meeting the 802.3af specification.
3 947704
Network Connection
The VIP-9890-CB Network Interface has one
RJ-45 NETWORK connector and one RJ-45
DOOR connector.
Use a standard Ethernet patch cable to connect
the NETWORK connector of the VIP-9890-CB
Network Interface to an Ethernet switch.
Signal Connections
Use standard Category 5 UTP cable to connect
the VIP-9890-CB Network Interface to the
Intercom unit. Connect the RJ-45 jack (labeled
Door) on the Network Interface to the RJ-45 jack
on the back of the Intercom unit speaker
assembly using a standard Ethernet patch cable.
Door Relay Connections
Access to the form C relay is provided via a three
pin screw terminal block on the VIP-9890-CB
Intercom unit. The common contact is the middle
terminal. The Normally Open contact is on the
side closest to the RJ-45 connector, the Normally
Closed contact is on the side furthest from the
RJ-45 connector. Please refer to Figure 1.
For higher security, the included VIP172L-RLY
connection block can be used. Please refer the
Quick Start Installation guide packaged with the
VIP172-RLY for installation details.
Aux Input
Aux input on the VIP-9890-CB Network Interface
accepts line level audio such as background
music and broadcasts it through the Intercom unit
speaker. When the call button is pressed, the aux
input is muted and remains muted until the call is
terminated.
Status Indicator Lights
The VIP-9890-CB Intercom unit is equipped with
a status indicator LED. LED flashes when the call
button is pressed and steady when the call is
connected.
The VIP-9890-CB Network Interface has 3 status
indication lights on the side panel:
STATUS: Flashes during normal operation, and
solid during system startup..
LINK: Indicates 100 Mbit Ethernet connection
when illuminated. No activity indicates 10 Mbit
connection.
ACT: Indicator flashes to indicate network
activity.
Setup
Information specific to your application will need
to be programmed into the VIP-9890-CB using a
computer. The PC used for programming should
be connected to the same subnet as the
VIP-9890-CB.
Setup will be done using the IP Solutions Setup
Tool. Download the latest version of the free IP
Solutions Setup Tool from the Valcom web site at
www.valcom.com/vipsetuptool.
TECHNICAL ASSISTANCE
Assistance in troubleshooting is available from
the factory. Call (540) 563-2000 and press 1 for
Technical Support or via email at
support@valcom.com.
When requesting assistance, you should include
all available information. Information and trouble-
shooting procedures are available on the Valcom
website at www.valcom.com.
Valcom equipment is not field repairable.
Valcom, Inc. maintains service facilities in
Roanoke, VA. Should repairs be necessary,
attach a tag to the unit clearly stating your
company name, address, phone number, contact
person and the nature of the problem. Send the
unit to:
Valcom, Inc.
Repair & Return Dept.
5614 Hollins Road
Roanoke, Va. 24019-5056
