Seite 1/3
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
INSTRUCTION MANUAL
MULTIFUNCTIONAL HEADLIGHT
INTRODUCTION & WARRANTY
TECHNICAL DATA
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 1 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
MODEL VT-9901
SKU 23340
LED TYPE 3W SMD+5W COB
LUMINOUS FLUX 120Lm+350Lm
BEAM ANGLE 230° Wide
CRI ≥80
LIFE SPAN 20,000 Hours
ON/OFF CYCLE 15,000 Times
NET WEIGHT 86.5g (Battery Included)
DIMENSION 605x46x27mm
BATTERY CHARGING
TIME WORKING TIME
650 mAh (1Pc)
Li-ion Polymer
Battery (Included)
2.5 Hours
SMD - 120Lm - 5.0 Hr
COB in White - 260 Lm - 3.5 Hr
SMD+COB in White - 350 Lm - 2.5 Hr
COB in Yelloiw - 300Lm - 2.0 hr
On/O Button, IR Sensor On/O
3 W SMD
USB-C Connector cover
IR Sensor
COB in White
COB in Yellow
PRODUCT STRUCTURE
PACKAGE CONTENTS
LED Head
Lamp Type-C Cable
(50cm) Instruction
WARNING
1. Please make sure to turn o the power
before starting the installation.
2. The light source of this luminaire is not
replaceable, when the light source reaches
its end of life the whole luminaire should be
replaced.
COB in Red
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
1. Keep pressing button 1 on the top of headlight by 3 seconds turns on the IR sensor.
2. The lamp will turn on once the IR sensor is activated.
3. Moving your hand in front of the spotlight will turn on the lamp.
4. Keep pressing button 1 on the top of headlight by 3 seconds turns o the IR sensor.
1. Turn on the torch.
2. Choose the lighting mode that suits you best.
3. The quick switch-o function automatically activates if the torch remains in the same
lighting mode for 10 seconds.
4. Aerwards, another press of the button automatically turns the torch o (skips the
other lighting modes).
Pressing button 1 on the top of the headlight turns on 3W SMD / both COB in white / both
COB in white + 3W SMD / both COB in yellow / both COB in red / both COB flash / O.
long press the switch to turn on/o sensing, all gears can be sensed
XPE high
COB warm light COB red light COB red flashing
COB white light XPE+COB white light
This function will make switching o a torch with multiple lighting modes much easier.
Simply use whichever lighting mode you need and then turn o the torch when you’re done
with a single button press - no need to go through all the remaining lighting modes to turn
the torch o.
A product with this function features protective circuits that prevent both overcharging and
excessive discharging of the accumulator that could lead to high temperatures, sparking or
explosion that would irreversibly damage or destroy the product.
TURNING ON THE HEADLIGHT
6 WORKING MODES
TURNING ON FLASH IN RED
QUICK SWITCH-OFF FUNCTION
RECHARGEABLE BATTERY PROTECTION
