WEEE Number: 80133970
INSTALLATION INSTRUCTION
This marking indicates that this
product should not be disposed of
with other household wastes.
Caution, risk of electric
shock.
TECHNICAL DAT
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
2
YEARS
WARRANTY
*
WARNING!
1. Please make sure to turn off the power before starting the installation.
2. Proper grounding should be ensured throughout the installation.
3. Installation should only be done by a certified electrician.
Model IP
Rating Body Type Operation
Temperature
Dimension
(LxWxH) Input Power
VT-16011 IP20 Iron -20 to +40°c 615x55x50mm AC:200-240,50/60Hz
VT-12021 IP20 Iron -20 to +40°c 1225x55x50mm AC:200-240,50/60Hz
VT-15021 IP20 Iron -20 to +40°c 1520x55x50mm AC:200-240,50/60Hz
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best.
Please read these instructions carefully before starting the installation and keep
this manual handy for future reference. If you have any another query, please
contact our dealer or local vendor from whom you have purchased the product.
They are trained and ready to serve you at the best. The warranty is valid for 2
years from the date of purchase. The warranty does not apply to damage caused
by incorrect installation or abnormal wear and tear. The company gives no war-
ranty against damage to any surface due to incorrect removal and installation of
the product. The products are suitable for 10-12 Hours Daily operation. Usage of
product for 24 Hours a day would void the warranty. This product is warranted for
manufacturing defects only.
INSTALLATION DIAGRAM
1. Switch off the power
before starting the
installation
9. Switch on
the power to
test the light.
NOTE: Compatible with V-TAC LED Tubes - Single side power supply
8. Insert LED Tube
7. Fix the front cover of the
fitting.
2. Remove the front cover of the
fitting.
3. Fix the wire through the fitting.
5. Install the lamp holders as shown. 6. Connect the wires as indicated
on the fitting.
T8 BATTEN FITTING
EN
4. Install the fitting on the wall
(Accessories not included).
ATTENTION
• COUPER l’électricité avant de commencer!
• Une mise à terre appropriée doit être assurée au cours de l’installation.
• Installation par électricien certifié
INSTRUCTIONS D’INSTALLATION
1. Coupez l’électricité
avant de commencer
l’installation.
9. Branchez
l’alimentation
pour tester la
réglette.
NOTA: Compatible avec les tubes LED V-TAC - Alimentation sur un seul côté
8. Insérez le tube LED.
7. Fixez le couvercle avant du
corps.
2. Retirez le couvercle avant du corps.
3. Fixez le fil Ă travers le corps.
5. Installez les douilles de lampe
comme indiqué.
6. Raccordez les fils comme indiqué
sur le corps.
INTRODUCTION & GARANTIE
Merci d’avoir choisi et acheté un tube de à LED de V-TAC. V-TAC vous offrira le meilleur.
Veuillez lire attentivement ces instructions avant de commencer l’installation et conservez
ce manuel à portée de main pour référence ultérieure. Si vous avez d’autres questions,
veuillez contacter notre distributeur ou le fournisseur local auprès duquel vous avez
acheté le produit. Ils sont formés et prêts à vous servir au mieuxLa garantie est valable
pour une pĂ©riode de 2 ans Ă compter de la date d’achat. La garantie ne s’applique pas Ă
des dommages causés par une installation incorrecte ou une usure anormale. La société
ne donne aucune garantie pour des dommages causés à une surface en raison d’un
enlèvement et d’une installation incorrects du produit. Les produits sont convenables pour
une exploitation quotidienne de 10-12 heures. L’utilisation du produit pendant 24 heures
par jour annule la garantie. Ce produit est couvert par une garantie pour des défauts de
fabrication seulement.
T8 RÉGLETTE D’ÉCLAIRAGE
FR
4. Installez le corps sur le mur
(Accessoires non inclus).
