Connection
© 2023 TP-Link 7106510236 REV4.2.1
Installation Guide
5/6/16-Port Gigabit Desktop PoE Switch
LED Explanation
Note: For simplicity, we will take TL-SG1005P for example throughout this Guide.
Note:
1. PoE ports can also connect to non-PoE devices, but only transmit data.
2. TL-SG1005LP can supply up to 30 W for each PoE port and 40 W for all PoE ports.
3. TL-SG1005P can supply up to 30 W for each PoE port and 65 W for all PoE ports.
4. TL-SG1006PP can supply up to 60 W for port 1, 30W for other single PoE port, and 64 W
for all PoE ports.
5. TL-SG116P can supply up to 30 W for each PoE port and 120 W for all PoE ports.
DC Power Adapter
AC Power Cord
IP Camera AP IP Phone
Router
LAN Port WAN Port
Internet
Ethernet Ports (1-5)
PoE Ports (1-4)
Power
On: Power on
O: Power o
Power
Link/Act and PoE Status
On: Providing PoE power
Flashing: Current-overload/Short-circuit
O: Not providing PoE power
On (Green): Connected to a 1000 Mbps
device
On (Yellow): Connected to a 10/100
Mbps device
Flashing: Transmitting/receiving data
O: No device is connected to the
corresponding port.
PoE MAX
PoE Max
TL-SG1005LP
On: 33 W ≤ Total power supply < 40 W
Flashing: Total power supply ≥ 40 W
O: Total power supply < 33 W
TL-SG1005P
On: 58 W ≤ Total power supply < 65 W
Flashing: Total power supply ≥ 65 W
O: Total power supply < 58W
TL-SG116P
On: Total power supply ≥ 113 W
Flashing: Total power supply ≥ 113 W and
lasts for more than 2 minutes
O: Total power supply < 113W
PoE Devices
Switches Explanation
Priority (for TL-SG116P)
O: All the ports transmit data with the same priority.
On: The corresponding ports transmit data with a higher priority than other ports. When congestion
occurs, packets which are transmitted by the ports with a higher priority occupy the whole bandwidth.
Isolation (for TL-SG116P)
O: Ports can transmit data with each other.
On: The corresponding ports cannot transmit data with other downlink ports. They can transmit data
only with the uplink ports (ports 15-16 of TL-SG116P).
Extend (for TL-SG1005P/TL-SG1006PP/TL-SG116P)
O: The corresponding ports run at 10/100/1000 Mbps and support PoE power supply up to 100 m away.
On: The corresponding ports run at 10 Mbps and support PoE power supply up to 250 m away.
Recovery (for TL-SG1005P/TL-SG1006PP/TL-SG116P)
O: The PoE Auto Recovery function is disabled.
On: The switch will constantly detect the working status of a PoE powered device (PD). When the switch
nds that the PD works abnormally, the switch will reboot it.
Note: The numbers in brackets indicate the ports where the feature takes eect. For example, when Extend(1-4) is toggled to On, the Extend mode will be enabled for ports 1-4.
TL-SG1006PP
On: 57 W ≤ Total power supply < 64 W
Flashing: Total power supply ≥ 64 W
O: Total power supply < 57W
Frequently Asked Questions (FAQ)
The Power LED should be lit when the power system is working normally. If the Power LED is
not lit, please try the following:
A1:
Make sure the AC power cord is connected to the switch with power source properly.
A2:
Make sure the voltage of the power supply meets the requirements of the input voltage
of the switch.
A3: Make sure the power source is on.
Q1. Why is the Power LED not lit?
It is recommended that you check the following items:
A1: Make sure that the cable connectors are rmly plugged into the switch and the device.
A2: Make sure the connected device is turned on and works normally.
A3: The cable must be less than 100 meters long (328 feet). If Extend Mode is enabled, it
should be less than 250 meters (820 feet).
Q2. Why is the Link/Act LED not lit while a device is connected to
the corresponding port?
Q3. Why are PoE ports not supplying power for PoE devices?
When the total power consumption of connected PoE devices exceeds the maximum, the
PoE port with a smaller port number has higher priority. The system will cut o power to the
ports with larger port numbers to ensure supplying to other ports.
Take TL-SG1005P as an example. If port 1, 2 and 4 are consuming 15.4 W respectively, and
an additional PoE device with 19 W is connected to port 3, the system will cut o the power
of port 4 to compensate for the overload.
TP-Link hereby declares that the device is in compliance with the essential requirements
and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and
(EU)2015/863.
The original EU declaration of conformity may be found at
https://www.tp-link.com/en/support/ce/
EU declaration of conformity
UK declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements
and other relevant provisions of the Electromagnetic Compatibility Regulations 2016 and
Electrical Equipment (Safety) Regulations 2016.
The original UK declaration of conformity may be found at
https://www.tp-link.com/support/ukca
IEEE802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3x,IEEE802.3af,
IEEE802.3at, IEEE802.3bt (for TL-SG1006PP only), IEEE802.1p
For TL-SG1005LP/TL-SG1005P:
5 10/100/1000 Mbps RJ45 Ports
Auto-Negotiation MDI/MDIX
PoE Ports: Port 1-Port 4
For TL-SG1006PP:
6 10/100/1000 Mbps RJ45 Ports
Auto-Negotiation MDI/MDIX
PoE Ports: Port 1-Port 4
For TL-SG116P:
16 10/100/1000 Mbps RJ45 Ports
Auto-Negotiation MDI/MDIX
PoE Ports: Port 1-Port 16
Total Power Supply:
40 W (TL-SG1005LP)/65 W (TL-SG1005P)/64W (TL-SG1006PP)/
120 W (TL-SG116P)
10BASE-T: UTP category 3, 4, 5 cable (maximum 100 m);
EIA/TIA-568 100Ω STP (maximum 100 m)
100BASE-TX: UTP category 5, 5e cable (maximum 100 m);
EIA/TIA-568 100Ω STP (maximum 100 m)
1000BASE-T: UTP category 5e cable or above (maximum 100 m);
EIA/TIA-568 100Ω STP (maximum 100 m)
10 Gbps (TL-SG1005LP/TL-SG1005P)/12Gbps (TL-SG1006PP)/
32 Gbps (TL-SG116P)
Store-and-Forward
Automatically learning, automatically aging
External Power Adapter
Input: 100-240 VAC, 50/60 Hz
Output:
53.5 VDC /0.81 A (TL-SG1005LP)
53.5 VDC /1.31 A (TL-SG1005P/TL-SG1006PP)
53.5 VDC /2.43 A (TL-SG116P)
Yes
39 mm (TL-SG1005LP/TL-SG1005P)/94mm (TL-SG1006PP)/
200 mm (TL-SG116P)
Standard
General Specications
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
0 C to 40 C (32 F to 104 Ëš Ëš Ëš ËšF)
-40 C to 70 C (-40 F to 158 Ëš Ëš Ëš ËšF)
10% to 90%RH non-condensing
5% to 90%RH non-condensing
Environmental and Physical Specications
Specications
For technical support and other information, please visit
https://www.tp-link.com/support, or simply scan the QR code.
To ask questions, find answers, and communicate with TP-Link
users or engineers, please visit https://community.tp-link.com
to join TP-Link Community.
Interface
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service, please
contact us.
Place the device with its bottom surface downward.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Adapter shall be installed near the equipment and shall be easily accessible.
Wall Mountable
Distance Between
Mounting Holes
Network Media (Cable)
Switching Capacity
Power Supply
Transfer Method
MAC Address Learning
The plug on the power supply cord is used as the disconnect device, the
socket-outlet shall be easily accessible.
A1: Before upgrading a connected PoE powered device (PD), disable PoE Auto Recovery to
avoid the PD’s damage.
A2: When a PD does not send data packets to the switch for a long period in certain
scenarios (e.g. an IPC in sleep mode), disable PoE Auto Recovery to avoid the PD
repeatedly rebooting.
Q4. What should I notice before using the PoE Auto Recovery
feature?
