Festa Smart Switch

LED Explanation

PWR On/O: Power on/o

SYS

On (Green): Running at 1000 Mbps

On (Yellow): Running at 10/100 Mbps

Blinking: Transmitting/receiving data

O: No connected device

PoE Status

(For Port 1-4 of Festa FS308GP

/Port 1-8 of Festa FS310GP)

On: Providing PoE power

Blinking: Current-overload/Short-circuit/Connected to a

non-standard PD/Power exceeded the user-dened value

O: Not providing PoE Power

PoE Max

(For Festa FS308GP/

Festa FS310GP)

On: Remaining power supply ≤ 7 W

Blinking: Remaining power supply keeps ≤ 7 W for more than

2 minuites

O: Remaining power supply keeps ＞ 7 W

Blinking: System running normally

On/O: System running abnormally

Speed

SFP1/SFP2

(For Festa FS310GP only)

Green/Yellow On: Running at 1000/100 Mbps

Blinking: Transmitting/receiving data

O: No connected device

For simplicity, we will take Festa FS310GP for example throughout the Guide. For simplicity, we will take Festa FS308G for example throughout the Guide.

Note:

1. The PoE ports can also connect to non-PoE devices, but only transmit data.

2. The PoE ports shall not be used to charge lithium batteries or devices supplied

by lithium batteries.

3. Maximum PoE power is 30 W for each PoE port, and total PoE budget is 62 W

(for Festa FS308GP) / 61 W (for Festa FS310GP) respectively.

4. PoE budget calculations are based on laboratory testing. Actual PoE power

budget is not guaranteed and will vary as a result of client limitations and

environmental factors.

Note:

1. Port 8 is a PD (Powered Device) port. When powered through port 8, the

switch can only be powered by power supplies that comply with the 802.3af/at

standard and Power Source Class 2 (PS2) or Limited Power Source (LPS)

defined in the standard of IEC 62368-1.

2. The DC power input takes precedence over the PD port. If the DC input fails,

the PoE input on the PD port willl supply power instead.

Connection for Non-PoE Switch

Connection for PoE Switch

DC Power dapterA

AC Power Cord

PoE+ Ports (1-8)

SFP Slots

Router

LAN Port WAN Port

Internet

IP Camera AP IP Phone

Powered Device (PD)

Router

LAN Port WAN Port

Internet

7106510914 REV1.0.0

Switch

Router

Festa Cloud

Clients

APAP AP AP

https://festa.tplinkcloud.com

1. Make sure that your devices can access the internet.

2. Launch a web browser and enter https://festa.tplinkcloud.com in the address

bar. Log in with your TP-Link ID.

3. + Add ControllerClick , then you will see you have successfully registered for a

Cloud-Based Controller and the controller has been added to the controller list.

Configuration

Some models featured in this guide may be unavailable in your country or region. For local

sales information, visit https://www.tp-link.com.

Safety Information

EU declaration of conformity

For technical support, the User Guide and other information, please visit

https://www.tp-link.com/support, or simply scan the QR code.

To ask questions, find answers, and communicate with TP-Link users or

engineers, please visit https://community.tp-link.com to join TP-Link Community.

UK declaration of conformity

TP-Link hereby declares that the device is in compliance with the essential requirements

and other relevant provisions of the Electromagnetic Compatibility Regulations 2016 and

Electrical Equipment (Safety) Regulations 2016.

The original UK declaration of conformity may be found at

https://www.tp-link.com/support/ukca/

TP-Link hereby declares that the device is in compliance with the essential requirements

and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and

(EU)2015/863.

The original EU declaration of conformity may be found at

https://www.tp-link.com/en/support/ce/

Keep the device away from water, fire, humidity or hot environments.

Do not attempt to disassemble, repair, or modify the device. If you need service, please

Do not use damaged charger or USB cable to charge the device.

Do not use any other chargers than those recommended.

Adapter shall be installed near the equipment and shall be easily accessible.

Plug the product into the wall outlets with earthing connection through the power supply

cord.

The working temperature for the device shall be within 0-40 ℃.

Place the device with its bottom surface downward.

The plug on the power supply cord is used as the disconnect device, the socket-outlet

shall be easily accessible. (Not for Festa FS308G)

The socket-outlet shall be installed near the equipment and shall be easily accessible. (Not

for Festa FS308G)

Option 1: Via a Web Browser

You can easily configure and manage Festa Smart Switches via the Festa

Cloud-Based Controller.

4. Set Up Now Config New SetupClick , click and follow the step-by-step

instructions to complete the configuration wizard of the controller.

5. On the controller’s management page, go to Devices + Add Devices, and click

and follow the step-by-step instructions to adopt your devices.

Now you can configure and manage your devices on the controller.

Note:

• Before you start, be sure to power up and connect your devices according to

the topology figure.

• A DHCP server (typically a router with DHCP function enabled) is required to

assign IP addresses to the devices and clients in your local network.

Option 2: Via Festa App

1. Download and install the Festa App from App Store or Google Play.

2. Launch the Festa App and log in with your TP-Link ID.

3. Tap + on the upper right corner, then you will see you have successfully

registered for a Cloud-Based Controller and the controller has been added to

the controller list.

4. Tap , tap Confirm Let’s Get Started and follow the step-by-step instructions to

complete the configuration wizard of the controller.

5. On the controller’s management page, go to Devices +, and click on the upper

right corner, and follow the step-by-step instructions to adopt your devices.

Now you can configure and manage your devices via the Festa App.

For detailed configurations, refer to the User Guide of the controller. The guide can be found on the download center of our official website: https://www.tp-link.com/support/download/.

Scan for Festa App Festa App
