Seite 1/2
©2023 TP-Link
7106510322 REV1.0.2
Power On
Quick Installation Guide
Range Extender
1
Next to
Solid Blue
Relocate
3
Set Up
1. Plug in the extender about between your router and the Wi-Fi dead halfway
zone. The location you choose must be within the range of your router.
2. Wait for about 2 minutes until the LED turns solid blue. If it doesn't,
relocate the extender closer to the router to achieve better signal quality.
Enjoy!
Connect your devices to the extender wirelessly, then enjoy the internet.
The password of your extended network is the same as your main router.
Router Devices
Halfway
Via the Tether App
1. Get the up-to-date Tether app from the
Apple App Store or Google Play, or simply
scan the QR code.
Via the Tether App
4. Follow app instructions to complete the setup.
The LED should turn solid on (blue or red)
for over 30 seconds, indicating successful
connection to your router.
Note: If the LED does not turn solid on, please refer to
FAQ > .Q2
2. Launch the Tether app and log in with your
TP-Link ID. If you don’t have an account,
create one first.
Welcome to Tether
Log In
TP-Link ID (Email)
Sign Up Forgot Password?
Password
3. Tap the button and select .Range Extender
Tether
Scan for Tether
or
Note: If you cannot find your device, please refer to
FAQ > .Q1
For more details, please refer to the user guide at
https://www.tp-link.com/support/download.
More Setup Methods
Via a Web Browser
1. Connect your computer or smartphone to
the extender’s network TP-Link_Extender.
2. Visit http://www.tplinkrepeater.net or
http://192.168.0.254 in a web browser.
Create a password to log in.
3. Follow web instructions to complete the setup.
2. Within 2 minutes, press the WPS button on
the extender for 1 second. The LED should
change from pulsing blue to solid blue,
indicating successful connection.
1. Press the WPS button on your router.
Via the WPS Button
3. If the extender connects to a dual band router,
repeat steps 1 and 2 to connect to the other
band.
Extended Network Names:
Router’s network name with
EXT
at the end
or
Same as your EasyMesh router
(See back for EasyMesh details)
Passwords:
Same as your router
2
* Images may differ from your actual product.
Plug the extender into a power outlet next to your router. Wait until
the LED turns solid blue.
Tip: To place the extender for optimal Wi-Fi performance, access extender settings
via the Tether app and go to Tools Location Assistant> , or simply scan the QR code
to visit https://www.tp-link.com/support/faq/3103/.
Mount
4
Method 1: Via 3M adhesives*
1. Tear off the protective paper from the 3M
adhesives on the back of the extender.
My Devices
No devices found.
Choose Your Device Type
Wireless Router
Gaming Router
Range Extender
Solid On
Solid Blue: Suitable location
Solid Red: Too far from router
Note: The back area of the extender is used for heat dissipation. It works best when the extender is mounted on a wall.
2. Adhere the extender vertically to a flat surface
that is out of children’s reach.
3M adhesives
Caution: Double-sided tape may
damage the wall or leave adhesive
residue on the wall when removed.
Method 2: Via mounting bracket
1. Mount the bracket on the wall in the correct
direction with the two provided screws.
2. Attach the extender on the bracket as shown below.
Tip: You can use the
included spirit level to
help install the bracket
horizontally.
The air bubble in the
level is centered.
Anchor
Screw
UP
UP
UP
Caution, Hot Surface
When the extender is working, the temperature on its
back is high. Do not touch the extender with bare
hands, and do not stick or directly mount it to
wallpaper, paper, wood, glass, non-heat-resistant
paint, foam board, flammable and explosive materials,
etc, to avoid burns, discoloration, breakage or other
accidental injury.
It is recommended to mount the extender to flat
and smooth painted walls, tile walls, and other
objects. Do not stick it on metal surfaces, so as not
to shield the wireless signal.
Notes:
1. Do not mount the extender until it is connected and relocated to a suitable location.
2. The extender can be powered by a USB Type-C PD fast charger.
3. For more information about LED statuses, see on the back page. LED Explanation
*Two extra 3M adhesives are provided
for future use.
The extender should be used within a temperature
range of 0°C-40°C.
Note: This equipment shall be
installed at a height of less than
2 meters.
Q1. What should I do if the Tether app cannot nd my device during
setup?
Try another method by following the steps below:
1. Connect your smartphone to the extender’s network .TP-Link_Extender
2. Launch the Tether app, and select your extender.
3. Follow app instructions to complete the setup.
If you are still having problems, contact our technical support.
Q2. What should I do if the LED doesn’t turn solid on after
completing setup via the Tether app or web browser?
You may have entered incorrect Wi-Fi password for your main router during the
conguration. Check the password and try again.
Make sure the extender is close to your router, preferably within 16 feet, and away
from large electrical appliances.
If you have enabled wireless MAC ltering, wireless access control, or access
control list (ACL) on your router, disable them rst, then follow any method on the
front page to complete the conguration.
Try setting it up via the WPS button.
Reset the extender and go through the conguration again.
If you are still having problems, contact our technical support.
Tip: If you have connected to the extender’s Wi-Fi but still cannot nd your device, try turning o
your cellular data.
You can experience strong, stable, and seamless wireless connections throughout your home with EasyMesh, a whole home mesh standard that works across dierent
access points for ultimate îž°exibility.
EasyMesh-Compatible
One-Click Settings
Within 2 minutes, press the WPS button on the main router and the extender, then the
EasyMesh network is all set up. TP-Link extenders in factory settings can be connected to
form an EasyMesh network directly without any redundant setup.
Seamless Roaming
Connects mobile devices to your routers or extenders that provide the best coverage. Devices
compatible with EasyMesh also share a single Wi-Fi name so you stay connected in every room.
Flexible Scalability
Flexibly scale your home networking with dierent vendors,* dierent topologies, dierent
Protocols and dierent product categories.
*Failure may occur due to rmware conicts of dierent vendors. A better network connection can
be established between all APs from TP-Link.
For more information, visit
https://www.tp-link.com/easymesh/.
IN T ER N E T
SAME
Network Name & Password
for seamless roaming
Method 1: Via the Tether App
1. Connect your smartphone to the extender‘s or router’s network.
2. Launch the Tether app, select your extender, and log in.
3. View or change extender settings as needed.
Access Extender Settings
After setup, you can access extender settings via any of the methods below.
You can reselect main network, change extended network settings and more.
Note: If your extender and router use the same network name, is recommended.Method 1
Wi-Fi
Wi-Fi
TP-Link_Extender
CHOOSE A NETWORK...
< Settings
My Devices
Local Device
RExxx
XX-XX-XX-XX-XX-XX
Q3. How do I reset the extender?
With the extender powered on, use a pin (provided) to press the button for RESET
5 seconds to reset the extender to its factory default settings.
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011 /65/EU and (EU) 2015/863.
The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of the Radio Equipment Regulations 2017.
The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca
For technical support, replacement services, user manuals and other information,
please visit https://www.tp-link.com/support, or simply scan the QR code.
To communicate with TP-Link users or engineers, please join the TP-Link Community
at https://community.tp-link.com.
Safety Information
• Keep the device away from water, re, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
• Do not use the device where wireless devices are not allowed.
• Do not use damaged charger or USB cable to charge the device.
• Do not use any other chargers than those recommended.
• Adapter shall be installed near the equipment and shall be easily accessible.
Please read and follow the above safety information when operating the device. We cannot
guarantee that no accidents or damage will occur due to improper use of the device. Please use this
product with care and operate at your own risk.
If you need more setup help, please visit
https://www.tp-link.com/support/faq/3074/, or simply scan the QR code.
AX3000 Wi-Fi 6 Air Range Extender Archer Air E5Model:
Tether
Method 2: Via a Web Browser
1. Connect your computer or smartphone to the extender’s network
.
If you are
using a computer, unplug the Ethernet cable if any.
2. Launch a web browser, enter http://www.tplinkrepeater.net in the address
bar, and log in.
3. View or change extender settings as needed.
http://www.tplinkrepeater.net
http://www.tplinkrepeater.net
LED Explanation
LED Status Indication
The extender is connected with a weak signal. Try
relocating it closer to your router.
Solid red
The extender is connected to the router’s wireless network
and is in a suitable location.
Solid blue
The extender is not powered or not powered by a standard
power source.
O
WPS Connection is in progress
Scan for Setup Video
Slowly
pulsing blue
Slowly
pulsing red
The extender is not connected to the router’s wireless
network.
The system is starting up or rmware upgrade is in progress.
Quickly
pulsing blue
Quickly
pulsing red
WPS connection failed. The extender will return to
unconnected status in one minute.
Produktspezifikationen
| Marke: | TP-Link |
| Kategorie: | WLAN-Repeater |
| Modell: | Archer Air E5 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit TP-Link Archer Air E5 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung WLAN-Repeater TP-Link
11 September 2024
1 September 2024
24 August 2024
23 August 2024
21 Juli 2024
20 Juni 2024
15 Juni 2024
17 Februar 2024
17 Februar 2024
17 Februar 2024
Bedienungsanleitung WLAN-Repeater
- WLAN-Repeater Asus
- WLAN-Repeater Gembird
- WLAN-Repeater Hama
- WLAN-Repeater LogiLink
- WLAN-Repeater Manhattan
- WLAN-Repeater Maxxter
- WLAN-Repeater Medion
- WLAN-Repeater Nedis
- WLAN-Repeater SilverCrest
- WLAN-Repeater ZyXEL
- WLAN-Repeater Buffalo
- WLAN-Repeater Essentiel B
- WLAN-Repeater Allnet
- WLAN-Repeater CSL
- WLAN-Repeater Devolo
- WLAN-Repeater Eminent
- WLAN-Repeater Linksys
- WLAN-Repeater Maginon
- WLAN-Repeater Netgear
- WLAN-Repeater Conrad
- WLAN-Repeater Renkforce
- WLAN-Repeater Aukey
- WLAN-Repeater Topcom
- WLAN-Repeater Xiaomi
- WLAN-Repeater Abus
- WLAN-Repeater Strong
- WLAN-Repeater Lindy
- WLAN-Repeater TOA
- WLAN-Repeater Tripp Lite
- WLAN-Repeater Mercusys
- WLAN-Repeater Audio Pro
- WLAN-Repeater Marmitek
- WLAN-Repeater TRENDnet
- WLAN-Repeater Western Digital
- WLAN-Repeater AVM
- WLAN-Repeater DJI
- WLAN-Repeater EnVivo
- WLAN-Repeater Tiptel
- WLAN-Repeater Black Box
- WLAN-Repeater Techly
- WLAN-Repeater Vision
- WLAN-Repeater Monacor
- WLAN-Repeater Huawei
- WLAN-Repeater Edimax
- WLAN-Repeater Optex
- WLAN-Repeater Totolink
- WLAN-Repeater D-Link
- WLAN-Repeater Quintezz
- WLAN-Repeater Davis
- WLAN-Repeater Vodafone
- WLAN-Repeater Digitus
- WLAN-Repeater LevelOne
- WLAN-Repeater Cisco
- WLAN-Repeater Elektrobock
- WLAN-Repeater Tenda
- WLAN-Repeater Ubiquiti Networks
- WLAN-Repeater Kramer
- WLAN-Repeater Intellinet
- WLAN-Repeater Fluke
- WLAN-Repeater Hikvision
- WLAN-Repeater EnerGenie
- WLAN-Repeater Nexxt
- WLAN-Repeater Planet
- WLAN-Repeater EnGenius
- WLAN-Repeater Mikrotik
- WLAN-Repeater Google
- WLAN-Repeater Comtrend
- WLAN-Repeater Digi
- WLAN-Repeater Funkwerk
- WLAN-Repeater Sitecom
- WLAN-Repeater Steren
- WLAN-Repeater Universal Remote Control
- WLAN-Repeater Wolfgang
- WLAN-Repeater Cudy
- WLAN-Repeater Siig
- WLAN-Repeater Atto
- WLAN-Repeater Paxton
- WLAN-Repeater Moxa
- WLAN-Repeater Iogear
- WLAN-Repeater StarTech.com
- WLAN-Repeater Smart-AVI
- WLAN-Repeater Dahua Technology
- WLAN-Repeater Speco Technologies
- WLAN-Repeater Gefen
- WLAN-Repeater Heatit
- WLAN-Repeater Arris
- WLAN-Repeater ATen
- WLAN-Repeater SilverNet
- WLAN-Repeater Axing
- WLAN-Repeater KanexPro
- WLAN-Repeater Verint
- WLAN-Repeater SmartAVI
- WLAN-Repeater Axis
- WLAN-Repeater Juniper
- WLAN-Repeater Crestron
- WLAN-Repeater Extron
- WLAN-Repeater Eero
- WLAN-Repeater Atlona
- WLAN-Repeater DSC
- WLAN-Repeater Tycon Systems
- WLAN-Repeater Silex
- WLAN-Repeater Gewiss
- WLAN-Repeater EXSYS
- WLAN-Repeater Barox
- WLAN-Repeater Altronix
- WLAN-Repeater Netcomm
- WLAN-Repeater Seco-Larm
- WLAN-Repeater ALC
- WLAN-Repeater Hawking Technologies
- WLAN-Repeater IDIS
- WLAN-Repeater Sabrent
- WLAN-Repeater Nitek
- WLAN-Repeater DTRONIC
- WLAN-Repeater 7inova
- WLAN-Repeater HELGI
- WLAN-Repeater Multi-link
- WLAN-Repeater Amped Wireless
- WLAN-Repeater Ruckus Wireless
- WLAN-Repeater Heden
Neueste Bedienungsanleitung für -Kategorien-
10 Oktober 2024
3 Oktober 2024
30 September 2024
30 September 2024
29 September 2024
29 September 2024
28 September 2024
28 September 2024
23 September 2024
Ubiquiti Networks PrismStation AC PS-5AC Bedienungsanleitung
20 September 2024
