Seite 1/7

Thank you very much

for purchasing KOCOM

Doorphone.

Please read this manual

thoroughly to ensure

correct usage,

before operating.

DOOR PHONE

KDP-601AM & KDP-601DM

Manual for Operation and Installation

Gentle chime sound.

KDP-601AM : AC 220V(only) or 110V(only)

KDP-601DM : Used DC 6V(4 Piece of 1.5V batteries)

: Used DC 12V / 300mA(External Power Source)

 Communication range: 0.65 mm wire, 300m line

Can be combined with door opener.

Easily mounted on wall, desk



Features

KDP-601AM & KDP-601DM

DS-2D

This manual is based on the date as shown in the right and specications

are subject to change without notice for quality improvement.

Door Phone 06.09

MS-2D

PRODUCT

MODEL

DATE PURCHASED

WARRANTY PERIOD

AGENCY

AGENCY ADDRESS

◉

◉KOCOM Warranties the original purchaser of this product as follows.

1) This product is produced under strict quality control and inspection procedures.

2) If this product breaks down during proper use as a result of product defect,

KOCOM will repair it within one year from date of purchase free of charge.

3) The following cases will be subject to charge, even during warranty period :

a. Breakdown during transport, or through careless treatment, by consumer.

b. Breakdown caused by unauthorized repair, or system modication.

c. Breakdown caused by natural disaster or power disorder.

To receive after sales service, have the following ready

when you contact our branches.

1. Name of the product.

2. Model number of the product.

3. The area of problem.

4. Phone number and address at which you can be contacted.

Warranty

Warranty Card

DOOR PHONE

KDP-601AM & KDP-601DM

Do not throw used-up battery into fire places, which may cause fire and explosion.

Cautions for installation

The relevant law obliges users to have a qualified electrician carry out wiring work for power supply. Work by disqualified

persons may cause fire and electric shock.

Wiring work for communication cables needs techniques and experiences. For this type of wiring work, please consult to your

local sales agent.

According to the standard for electric work and other relevant regulations, install communication cables at the place away

from power cables. The failure to install cables separately may cause fire, electric shock and communication troubles.

Do not install the product on rolling table or sloping place.

Dropping or falling may cause damage on your product.

In installation, avoid the place exposed to tremor or shocks, which may cause damages on your product.

Even if your product is waterproof, do not install it slanted place of water leakage, which may cause a short circuit.

For the product of wall-mounting type with fixing pegs, keep it safely.

Fixing pegs may cause injury of user.

Install the product of wall-mounting type carefully not to drop from the wall. Dropping due to earthquake or tremors may

cause injury of user.

When installing the product on the wall, consider the thickness and material of the wall.

Dropping in use may cause injury of user.

Cautions for Use

Do not put heavy thing on the product. Dropping or falling due to heavy things on it may cause injury of user.

Cautions for Repairs and Maintenance

Clean the dust inside the product regularly. Failure to clean the dust for long time may cause fire. For inspection and cleaning

of the inside of product, please contact your local sales agent.

When putting your hands into the inside of equipment, be sure that plug is already detached form an outlet or circuit-breaker is

turned off.

Be careful not to expose the product to benzene, thinner or hot water.

Do not expose detergent directly to the product in a way of spaying, etc.

Moving equipment, be sure that the plug is detached from an outlet.

For equipment whose cables are connected to terminals, please contact your local sales agent or qualified electrician.

When replacing old fuse with new one, do not directly touch it with bare hands.

Use insulated tools or contact A/S center.

Cautions

�

Warnings for disposal

�Read this cautions carefully and keep it within easy reach of you.

�For right installation, read this cautions thoroughly. Please install the product according to its specifications.

�This Cautions for Safety may include items that are not contained in specifications of the product that consumer

purchases.

�Reading this cautions, use the product in a right manner. For further information, please contact our A/S center.

About Symbol

A variety of symbols are used in this Cautions for Safety and your products to guide you to use products in a right

and safe manner and to prevent possible risks for users and other persons and damages to their property. The meaning

of each symbol is as follows. After fully aware of meaning of each symbol, read the following cautions.

This symbol means that wrong handling or ignorance of matters that this symbol indicates

may cause serious injury or even death of user.

This symbol means that wrong handling or ignorance of matters that this symbol indicates

may cause serious injury or property damage of user.

This symbol means the matter that user should not do at nay event.

This symbol means that user should follow the instructions.

Symbols on Drawing

This symbol means that contents (high voltage, electric shock, warnings, etc.) to which user

should pay attention are included.

This symbols means that a certain action is not permitted. Specific points not permitted are

depicted around this symbol (for example, in the left drawing, disassembly is not permitted.).

This symbol means instructions or is used to force user to do a certain action. Specific

instructions are depicted on the drawing

(for example, the left drawing instructs user to detach power plug from an outlet).

Cautions for Safety

Warnings

Cautions

For safe use, please stick to the following cautions.

Warnings
