Seite 1/10
SOLO
Owners Manual
This engine is equipped with a
decompression valve for
easier starting. Press the button
in before every start to reduce
cylinder pressure.
Solo® Germany The registered Solo® trademark is licensed for use in the U.S. to the German company Solo Kleinmotoren Gmbh by the U.S. aliate, Solo incorporated.
It is recommended that everyone
who uses this product should read
the StrikeMaster owner’s manual.
ATTENTION: PRIOR TO FIRST USE
For best performance idle
engine for 1-2 minutes before
you start drilling.
SM13
!!
Ice Fishing has become one of the fastest growing and most popular winter sports, allowing the ardent
angler the opportunity to enjoy his or her favorite outdoor activity.
When you purchased a StrikeMaster® power ice auger, you selected a product that has gained a
reputation as the quality leader since 1946. There is no doubt that this year’s model is the finest ever pro-
duced by StrikeMaster Corporation.
Your new StrikeMaster ice auger has all of the most wanted features in a power ice auger, to assure many
years of enjoyable ice fishing. Some of these features such as workmanship, engineering excellence, and
dependability have long been standards at StrikeMaster. Your new power ice auger boasts many new
features while retaining the best features developed in previous years to enhance your ice fishing
experience and add to your satisfaction in selecting StrikeMaster.
We know that you are anxious to go fishing and use your new power ice auger, but before you go fishing,
it is important and to your advantage to spend a few minutes getting acquainted with your new
StrikeMaster power ice auger. There is no better way to acquaint yourself with the product than to read
the Owners Manual and operating instructions. A few minutes spent studying this manual before your
first ice fishing outing will be time well spent.
Record the engine serial number, engine type and date purchased in the space below.
Also, please return the enclosed WARRANTY CARD or submit your information at
www.strikemaster.com to validate your limited warranty.
Model: Pro Lazer, Lazer Mag & Magnum
Serial Number Engine Type
Spec # CC DOM
Date Purchased ______ / ______ / ______
Important Safeguards/Component & Control Locations 3
Assembly Instructions 4
Operation Instructions 4
Fueling: Oil/Fuel Instructions 5
Engine Start Preparations 6
Engine Start Instructions 6
Stop Engine 6
Maintenance 7
Storage 7
SOLO® Engines Limited Warranty 9-10
STRIKEMASTER Limited Warranty (back cover)
STRIKEMASTER
®
Ice Augers
THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH IF NOT FOLLOWED COULD ENDANGER
THE PERSONAL SAFETY AND/OR PROPERTY OF YOURSELF AND OTHERS. READ AND FOLLOW ALL INSTRUCTIONS
IN THIS MANUAL AND ANY PROVIDED WITH OR ON THE EQUIPMENT ON WHICH THIS ENGINE IS USED BEFORE
ATTEMPTING TO OPERATE YOUR STRIKEMASTER POWER ICE AUGER.
ATTENTION !!
!
............................................................................
..............................................................................................................................................
..............................................................................................................................................
.................................................................................................................................................................
.......................................................................................................................................
.................................................................................................................................
................................................................................................................................................................
...........................................................................................................................................................................
..................................................................................................................
................................................................................................
........................................................................................................................................
TABLE OF CONTENTS
SERIAL
NUMBER
ENGINE TYPE
CC SPEC #
DOM (DATE OF MFG.)
Please keep the original packaging in order to protect the equipment against damage in case you ever need to ship or
transport the auger. If the packaging materials are no longer required then they must be disposed of properly in accordance
with applicable local regulations. Cardboard packaging materials are raw materials which can be recycled or reused. At the end
of the equipments service life, please make sure that you dispose of it properly, in accordance with the ocial directives and
regulations that apply in your area.
!!
 1. use this product for any purpose other than cutting ice fishing holes. Ice augers are precision cutting DO NOT
tools built for the ice fisherman, and must be properly maintained and handled with caution during both cutting
and transporting. When not in use, always store with blade guard attached.
 2. DO NOT use attachments other than those available from the manufacturer.
 3. DO NOT alter this product in any manner; doing so is dangerous and voids all warranties.
 4. DO NOT allow children or adults weighing under 100 lbs. to operate this equipment.
 5. operate under the influence of drugs or alcohol. DO NOT
 6. allow your body, loose clothing, drawstrings, scarves, hats or other materials to come in contact with DO NOT
the Powerhead, Starter Assembly or Auger (Drill) unit at any time.
 7. operate if, upon pulling the starter rope or after drilling holes, the auger (drill) rotates or if the rope DO NOT
pulls hard. Have the unit checked by a qualified mechanic.
 8. DO NOT allow the engine to run or operate while moving or transporting to another location.
 9. DO NOT continue to use this product in the event of mechanical or electrical failure.
10. This product produces considerable cutting force that is felt by the operator. Make sure your feet are firmly
planted and that the handles are held firmly while operating this product.
11. Always check the operation of the throttle system to ensure the carburetor control is completely returning to
the idle position when the throttle lever is released.
12. Check cutting blades and auger shaft screws before and after each use to make sure they are tight.
13. During operation, the auger unit could possibly stop. Be prepared at all times to release the throttle lever.
14. The cutting blades on the ice auger are razor sharp. Use extreme care when handling.
It is recommended that everyone who uses this product should read this
StrikeMaster Owner’s Manual before operating.
IMPORTANT SAFEGUARDS
3
1. Recoil (starter) Handle
2. Fuel Cap
3. Fuel Tank
4. Fuel (FULL) Level
5. Decompression Valve
6. Throttle Lever
7. Air Filter Cover
8. Throttle Rod
13. Recoil
14. Muer Guard
15. Muer
16. Handle Assembly
9. Choke Lever
10. Transmission
11. Start/Stop Switch
12. Spark Plug Cover
COMPONENT & CONTROL LOCATIONS
10
11
13
15
14
16
12
89
4
5
7
1
2
3
6
PACKAGING & DISPOSAL
! !
