HondaTM 35CC LITE
Owner’s Manual
You MUST add crankcase oil to
your new Auger prior to your first use!
We recommend using the bottle of
StrikeMaster API rated SM (as a minimum)
OW-20 4-Cycle Synthetic Engine Oil included.
For longer life of the engine, continue to use the
required API rated SM (as a minimum) OW-20
4-Cycle Synthetic Engine Oil.
It is recommended that everyone
who uses this product should read
this StrikeMaster Owner’s Manual.
ATTENTION: PRIOR TO FIRST USE
For best performance, idle
engine for 1-2 minutes before
you start drilling.
SM13
!!
2
STRIKEMASTER
®
Ice Augers
THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH IF NOT FOLLOWED COULD ENDANGER
THE PERSONAL SAFETY AND/OR PROPERTY OF YOURSELF AND OTHERS. READ AND FOLLOW ALL INSTRUCTIONS
IN THIS MANUAL AND ANY PROVIDED WITH OR ON THE EQUIPMENT ON WHICH THIS ENGINE IS USED BEFORE
ATTEMPTING TO OPERATE YOUR STRIKEMASTER POWER ICE AUGER.
ATTENTION !!
!
Record the engine serial number, engine type and date purchased in the
space below. Also, please return the enclosed WARRANTY CARD or submit
your information at www.strikemaster.com to validate your limited warranty.
Model: Honda 35cc Lite
Engine Serial Number Engine Type __ __ __ __ -__ __ __ __ __ __ __ __ __ __ __
Date Purchased ______ / ______ / ______
Ice Fishing has become one of the fastest growing and most popular winter sports, allowing the ardent angler
the opportunity to enjoy their favorite outdoor activity year round.
When you purchase a StrikeMaster® power ice auger, you selected a product that has gained a reputation as
the quality leader since 1946. There is no doubt that this year’s model is the finest ever produced by StrikeMaster.
Your new StrikeMaster ice auger has all of the most wanted features in a power ice auger, to assure many years of
enjoyable ice fishing. Some of these features such as workmanship, engineering excellence, and dependability have
long been standards at StrikeMaster. Your new power ice auger boasts many new features while retaining the best
features developed in previous years to enhance your ice fishing experience and add to your
satisfaction in selecting StrikeMaster.
We know that you are anxious to go fishing and use your new power ice auger, but before you go fishing, it is
important and to your advantage to spend a few minutes getting acquainted with your new StrikeMaster power
ice auger. There is no better way to acquaint yourself with the product than to read the Owner’s Manual and
operating instructions. A few minutes spent studying this manual before your first ice fishing outing will be
time well spent.
!! IMPORTANT NOTICE
DO NOT REMOVE THE GREEN INTAKE GASKET.
See photo for location on engine. Not only will removing the
green intake gasket void the warranty, if removed the engine
will not work properly and could cause damage.
If removed, replacement of the green intake gasket is NOT
covered under Honda or StrikeMaster limited warranties.
For service contact your local authorized Honda Engine
Dealer or visit www.strikemaster.com for more information
by clicking the “Find Service Centers” button to search
service centers by zip code. For more information from
Honda click the “Visit Honda” button.
DO NOT REMOVE
Green Intake Gasket
CHECKING/ADDING GASOLINE & OIL !!
!!
  1. use this product for any purpose other than cutting ice fishing holes. Ice augers are precision cutting tools built DO NOT
for the ice fisherman, and must be properly maintained and handled with caution during both cutting and transporting.
When not in use, always store with blade guard attached.
2. use attachments other than those available from the manufacturer.DO NOT
3. alter this product in any manner; doing so is dangerous and voids all warranties.DO NOT
4. allow children or adults weighing under 100 lbs. to operate this equipment.DO NOT
5. DO NOT operate under the influence of drugs or alcohol.
6. DO NOT allow your body, loose clothing, drawstrings, scarves, hats or other materials to come in contact with the Powerhead,
Starter Assembly or Auger (Drill) unit at any time.
7. DO NOT operate if, upon pulling the starter rope or after drilling holes, the auger (drill) unit rotates or if the rope pulls hard.
Have the unit checked by a qualified mechanic.
8. allow the engine to run or operate while moving or transporting to another location.DO NOT
9. continue to use this product in the event of mechanical or electrical failure.DO NOT
10. This product produces considerable cutting force that is felt by the operator. Make sure your feet are firmly planted and that
the handles are held firmly while operating this product.
11. Always check the operation of the throttle system to ensure the carburetor control is completely returning to the
idle position when the throttle lever is released.
12. cutting blade screws and collar bolt before and after each use to make sure they are tight.CHECK
13. During operation, the auger unit could possibly stop. Be prepared at all times to release the throttle lever.
14. The cutting blades on the ice auger are razor sharp. Use extreme care when handling.
15. After use, the auger blades should be wiped dry and oiled to extend blade life.
It is recommended that everyone who uses this product should read this
StrikeMaster Owner’s Manual before operating.
IMPORTANT SAFEGUARDS
3
Fuel Tank
Cap
Oil
Gauge
The Honda (GX35 engine) is a non-application specific manual. Any further technical engine guidelines that are not covered in the StrikeMaster
Owner’s Manual, refer to the Honda Owner’s Manual. Unit shipment also includes correct amount of StrikeMaster API rated SM (as a minimum)
OW-20 4-cycle synthetic engine oil for initial fill (3.4 oz.). Honda GX35 engine crankcase capacity has a maximum oil capacity of 3.4 oz.
DO NOT OVERFILL.
Also, running the engine with a low oil level can cause engine damage. This type of damage is not covered by the Distributor’s Limited Warranty.
See Honda Owner’s Manual for other information such as air cleaner, spark plug, and fuel filter.
Your new 4-stroke auger engine does come filled with oil or gasoline. NOT
You will need to add StrikeMaster API rated SM (as a minimum)
OW-20 4-Cycle Synthetic Engine Oil to the crankcase reservoir and
unleaded gasoline to the fuel tank prior to your first use. Using a gas/oil
mixture will damage the motor.
Honda Motor Co. requires you use only API rated SM (as a minimum)
OW-20 4-Cycle Synthetic Engine Oil with the Honda 35cc Lite auger engine.
See included Honda Owner’s Manual for step by step instructions or go to:
http://engines.honda.com/pdf/manuals/00X37Z6J6100.pdf to download
a digital copy.
Suggested position to check oil
Add or check oil at bottom edge of hole, ( ), while in position Fig 1 right
as shown here or on page 9 of the Honda Owner’s Manual.
Use a 5-1/2" tall block for 8" auger
Use a 4-3/4" tall block for 10" auger
Fig 1
