Disassembly, Wire and
Amplier Plate Installation
Glovebox Subwoofer
Installation
pg 2
pg 6
RZ3-1KRC
RZR XP1000 & 2015+ RZR900
with Ride Command
SSV Works Subwoofer Audio Kit
2
RZR XP1000 & 2015+ RZR900
Amp Tray and Wiring Installation
!
Please read and understand these
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in
material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty
against defects in material or workmanship. All Kicker Speakers are covered by a limited 1
year warranty against defects in material or workmanship. All Kicker Ampliers are covered by
a limited 2 year warranty against defects in material or workmanship. Labor for replacement
of defective components is not covered. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- T30 & T40 Torx Socket
- 10mm and 5.5mm Socket
& Rachet or Wrench
- 4mm & 5mm Allen Wrench
- #2 & #3 Phillips Screwdriver
PARTS LIST IMAGES
3. M6 x 1.0 Screws x 1
6. Battery Terminal Cable
4. M6 Washer x 1
7. Zip Ties x 5
1. Amp Power Wire 2. Direct-t Amp Plate with
pre-tuned Amp with Ride
Command harness
5. Fuse Holder with 40A Fuse
- Drill with 1/8”, 1/4” & 1/2”
Drill bits
- Panel removal tool
- Wire Crimpers
- Wire Strippers
- Scribe or Marker
- Utility Knife
3
A
PANELS AND DASH DISASSEMBLY
C
E
B
DD
F
A. Remove all seats by releasing the handle behind each seat,
push forward slightly while lifting up.
C. Remove hood by turning locking pins and lifting up.
E. Disconnect all harness connectors attached to the center dash panel.
B. Disconect the negative battery cable from the battery.
D. Remove center dash by unscrewing the (2) T-40 Torx screws and push center
dash forward to unclip.
F. Un-pin and pull to remove the passenger side safely handle.
