Seite 1/3
PARTS LIST IMAGES
TOOLS NEEDED FOR INSTALLATION
BR-2B65U
202
202
202
2022021+ F
1+ F
1+ F
1+ F1+ Ford Br
ord Br
ord Br
ord Brord Bronco, 2 Door
onco, 2 Door
onco, 2 Door
onco, 2 Door onco, 2 Door
6.5” Rear Speak
6.5” Rear Speak
6.5” Rear Speak
6.5” Rear Speak6.5” Rear Speaker-P
er-P
er-P
er-Per-Pod Add-
od Add-
od Add-
od Add-od Add-Ons
Ons
Ons
OnsOns
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against
defects in material or workmanship. All SSV Works Electronics are covered by a
limited 1 year warranty against defects in material or workmanship. All Kicker
Speakers are covered by a limited 1 year warranty against defects in material or
workmanship. All Kicker Amplifiers are covered by a limited warranty 2 year
against defects in material or workmanship. Labor for replacement of defective
components is not covered. Contact SSV Works for further warranty
information.
Please read and understand these
instructions completely before installation to
avoid possible injury, or damage to the
accessory or vehicle.
!
SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818- -1778 | Fax: 866- -991 293 6751
(x2) M6 x Screw
Passenger Rear Door Pod Bracket PackDriver Rear Door Pod
(x2) M6 Washer
•T25, T30 Torx Driver
•#1 Phillips Screwdriver
(x2) #1 Phillips Screw
BR-2B65U 2023 SSV Works, Oxnard, Ca 93030 BR- - -2BR65 Rev. A. 4 24 23
A. Remove the screw located at the bottom of the speaker
enclosure.
A
B. Removing the two screws securing the bracket to the
vehicle. Then remove the two screws securing the bracket to the
enclosure.
Note: These 4 factory screws will be re- .used for the SSV pods
*This image is of passenger side .
B
A. Secure the drivers side bracket to the driver side pod using
the factory two screws.
AB
CD
B. Hold the pod up near its mounting location and connect the
factory harness.
C. Snap the speaker pod harness cover onto the pod making sure
the harness exits the cover through one of the two reliefs.
D. Use the provided Philips screw to secure the cover in place.
E. Loosely assemble the bottom of the pod to the frame of the
vehicle using the provided M6 screw and washer.
BR-2B65U 2023 SSV Works, Oxnard, Ca 93030 BR- - -2BR65 Rev. A. 4 24 23
E. Loosely assemble the bottom of the pod to the frame of the
vehicle using the provided M6 screw and washer.
G. Fully tighten the bottom screw located at the bottom of the
pod.
EF
F -. Install the two factory bolts securing the pod to the vehicle.
Note:
Note:
Note:
Note: Note: Im
Im
Im
ImImage
age
age
age age is
is
is
is is of
of
of
of of pas
pas
pas
paspasseng
seng
seng
sengsenger s
er s
er s
er ser side.
ide.
ide.
ide.ide.
G
Repeat all steps for the opposite side.
BR-2B65U 2023 SSV Works, Oxnard, Ca 93030 BR- - -2BR65 Rev. A. 4 24 23
