BR-B65
2021+ Ford Bronco
6.5” Rear Speaker-Pod Add-Ons
SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
!
Please read and understand these
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects
in material or workmanship. All SSV Works Electronics are covered by a limited 1 year
warranty against defects in material or workmanship. All SSV Works Speakers are
covered by a limited 1 year warranty against defects in material or workmanship. Labor
for replacement of defective components is not covered. Contact SSV Works for further
warranty information.
1. BR-B65U Enclosures (1 pair)
2. T-25 Torx Screws x 4
(Factory Screws)
TOOLS NEEDED FOR INSTALLATION PARTS LIST
PARTS LIST IMAGES
3. Phillips Screw x 2
4. M6 Screws
and Washers x 2
2. T-25 Torx Screws p1-x4
(Factory Provided)
1. BR-B65-U Enclosures
(1 pair)
3. Phillips Screw x 2 4. M6 Screws and
Washers x 2
- #1 Phillips Screwdriver - T-25 Torx bit
- T-30 Torx bit
B. Remove the 3rd screw located at the bottom of the speaker
pod bolting the pod to the frame.
BR-B65
B
© 2022 SSV Works, Oxnard, CA 93030 BR-B65 Rev. A 12-02-22
A. Remove the two screws securing the top mounting bracket
to the factory speaker pod. These are hard to remove with a
hardtop we recommend using an angle driver.
Note: These two screws will be re-used for the SSV pods.
A
DISASSEMBLY
C. Use the provided Philips screw to secure the cover in place. D. Loosely assemble the bottom of the pod to the frame of the
vehicle using the provided M6 screw and washer.
B. Snap the speaker pod harness cover onto the pod making
sure the harness exits the cover through one of the two reliefs.
C D
B
A. Hold the pod up near its mounting location and connect the
pod to the factory harness.
A
INSTALLATION
BR-B65 © 2022 SSV Works, Oxnard, CA 93030 BR-B65 Rev. A 12-02-22
E. Use the factory screws that were removed in Step A to secure the
top of the enclosure.
F. Go back and tighten the bottom M6 screw.
E F
G. Repeat these steps on the driver side.
Produktspezifikationen
| Marke: | SSV Works |
| Kategorie: | Speaker |
| Modell: | BR-B65 |
