4K/HDR PROCESSOR BOARD
HKCU2040
INSTALLATION GUIDE
1st Edition
2016.11 08
© 2016 Sony Corporation Printed in Japan
English
4-694-144-11 (2)
Before operating the unit, please read this manual thoroughly
and retain it for future reference.
For the customers in the U.S.A.
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own
expense.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority to
operate this equipment.
All interface cables used to connect peripherals must be
shielded in order to comply with the limits for a digital device
pursuant to Subpart B of part 15 of FCC Rules.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
For the customers in Canada
CAN ICES-3 (A)/NMB-3(A)
For the customers in Europe
This product is intended for use in the following
Electromagnetic Environment: E4 (controlled EMC
environment, ex. TV studio).
This apparatus shall not be used in the residential area.
For the customers in Europe, Australia and
New Zealand
WARNING
This equipment is compliant with Class A of CISPR 32. In a
residential environment this equipment may cause radio
interference.
For the customers in the U.S.A.
SONY LIMITED WARRANTY - Please visit
http://www.sony.com/psa/warranty for important information
and complete terms and conditions of Sony’s limited
warranty applicable to this product.
For the customers in Canada
SONY LIMITED WARRANTY - Please visit http://
www.sonybiz.ca/pro/lang/en/ca/article/resources-warranty-
product-registration for important information and complete
terms and conditions of Sony’s limited warranty applicable to
this product.
Precautions
Notes on use
Before operating the unit, thoroughly read the WARNING and
CAUTION sections in the OPERATION GUIDE supplied with
the HD Camera Control Unit.
• If the unit is suddenly taken from a cold to a warm location,
or if ambient temperature suddenly rises, moisture may form
on the outer surface of the unit and/or inside of the unit. This
is known as condensation. If condensation occurs, turn off
the unit and wait until the condensation clears before
operating the unit. Operating the unit while condensation is
present may damage the unit.
• If this product is installed incorrectly, personal injury or
damage to peripheral items may occur due to fire, shock, or
other accidental circumstances. To avoid such risks,
installation should be performed by trained service
technicians.
• The fan is a consumable part that will need periodic
replacement.
When operating at room temperature, a normal replacement
cycle will be about 5 years.
However, this replacement cycle represents only a general
guideline and does not imply that the life expectancy of this
part is guaranteed. For details on parts replacement,
contact your dealer.
To the technician installing this product
For installation instructions, please refer to the maintenance
manual for the HD camera control unit (HDCU2000/2500) (not
supplied) as well as this INSTALLATION GUIDE.
Turn off the POWER switch on the HD Camera Control Unit
(HDCU2000/2500) before installing this product.
Specifications
General
Power consumption
23.5 W
Operating temperature
–10 °C to +40 °C (+14 °F to +104 °F)
Storage temperature
–20 °C to +60 °C (–4 °F to +140 °F)
Dimensions (w/h/d)
DPR board: Approx. 19 × 110 × 226 mm
(3/4 × 4 3/8 × 9 inches)
DIF board: Approx. 19 × 98 × 159 mm
(3/4 × 3 7/8 × 6 3/8 inches)
HIF board: Approx. 19 × 98 × 159 mm
(3/4 × 3 7/8 × 6 3/8 inches)
Mass DPR board: Approx. 0.35 kg (12 oz.)
DIF board: Approx. 0.15 kg (5.3 oz.)
HIF board: Approx. 0.09 kg (3.2 oz.)
Output connectors
DIF board: SDI OUT
BNC-type (4)
3G-SDI: SMPTE ST424/ST425-1, 0.8 Vp-p,
75 ohms, 2.970 Gbps/2.967 Gbps
HD-SDI: SMPTE ST292-1, 0.8 Vp-p, 75 ohms,
1.485 Gbps/1.4835 Gbps
3G-SDI/HD-SDI selectable
HIF board: SDI OUT
BNC-type (4)
3G-SDI: SMPTE ST424/ST425-1, 0.8 Vp-p,
75 ohms, 2.970 Gbps/2.967 Gbps
HD-SDI: SMPTE ST292-1, 0.8 Vp-p, 75 ohms,
1.485 Gbps/1.4835 Gbps
3G-SDI/HD-SDI selectable
Character ON/OFF selectable (connectors 3/4)
Supplied accessories
Installation Guide (1)
Design and specifications are subject to change without
notice.
For the customers in Europe
Sony Professional Solutions Europe - Standard Warranty
and Exceptions on Standard Warranty.
Please visit http://www.pro.sony.eu/warranty for important
information and complete terms and conditions.
For the customers in Korea
SONY LIMITED WARRANTY - Please visit
http://bpeng.sony.co.kr/handler/BPAS-Start for important
information and complete terms and conditions of Sony’s
limited warranty applicable to this product.
Note
Notes
• Always verify that the unit is operating properly before use.
SONY WILL NOT BE LIABLE FOR DAMAGES OF ANY KIND
INCLUDING, BUT NOT LIMITED TO, COMPENSATION OR
REIMBURSEMENT ON ACCOUNT OF THE LOSS OF
PRESENT OR PROSPECTIVE PROFITS DUE TO FAILURE
OF THIS UNIT, EITHER DURING THE WARRANTY PERIOD
OR AFTER EXPIRATION OF THE WARRANTY, OR FOR
ANY OTHER REASON WHATSOEVER.
• SONY WILL NOT BE LIABLE FOR CLAIMS OF ANY KIND
MADE BY USERS OF THIS UNIT OR MADE BY THIRD
PARTIES.
• SONY WILL NOT BE LIABLE FOR THE TERMINATION
OR DISCONTINUATION OF ANY SERVICES RELATED
TO THIS UNIT THAT MAY RESULT DUE TO
CIRCUMSTANCES OF ANY KIND.
