Seite 1/21
BASEBAND PROCESSOR UNIT
BPU4500A
NETWORKED MEDIA INTERFACE KIT
SKC-IP45AF
ST 2110 INTERFACE KIT
SKC-4001
OPERATION MANUAL [English]
1st Edition (Revised 2)
2
Table of Contents
Overview.................................................................... 3
System Configuration ......................................................4
Name and Function of Parts .................................. 10
Front Panel ....................................................................10
Rear Panel ....................................................................11
SKC-IP45AF Networked Media Interface Kit
(Option) ......................................................................12
SKC-4001 ST 2110 Interface Kit (Option) .....................13
Connection and Setup............................................ 14
4K System Connection ..................................................14
Extension Mode Connection .........................................15
HD CUTOUT Video System ..........................................16
HFR Video System ........................................................18
HDR Video System .......................................................21
Relationship Between Operation Mode and Output
Format .......................................................................22
Paint Functions in HDR MODE and BT.2020 COLOR
MODE ........................................................................26
PWS-100NM1 Connection Settings ..............................30
Status Display ......................................................... 31
Displaying the Status Screen ........................................31
Status Display Screen ...................................................31
Menu Settings ......................................................... 31
Changing Settings using the Menu ...............................31
Menu Tree .....................................................................33
Menu List .......................................................................37
Appendix ................................................................. 52
Precautions ...................................................................52
Error Messages .............................................................52
Specifications ......................................................... 53
BPU4500A ....................................................................53
SKC-IP45AF (Option) ....................................................54
SKC-4001 (Option) ........................................................54
3
Overview
The BPU4500A Baseband Processor Unit connects to a
CA4000 Camera System Adaptor, mounted on a PMW-F55
Solid-state Memory Camcorder1) or an F65 Digital Motion
Picture Camera2), or to an HDC4300 Color Camera or
HDC-P43 Multi Purpose Camera via an optical fiber cable. It
processes video signals from the camera and provides an
interface with external devices.
It can also connect to an HDCU3000-series,
HDCU2000-series, or HDCU1000-series
3) Camera Control
Unit (hereinafter referred to as the “CCU”)4) to form a 4K video
multi-camera system, supplying power to the camera and
transferring various signals (intercom, tally, prompter, audio,
etc.).
The unit can output video signals and audio signals not just as
SDI but also as IP.5)
1) Requires PMW-F55 software version 2.10 or later.
2) Requires the SKC-4065 F65 Adaptor.
3) If using a HDCU1000-series unit, please contact your Sony
representative.
4) To connect to SMPTE ST 2110 standard compatible devices using
the SKC-4001 ST 2110 Interface Kit, connect with an HDCU3100
which has HKCU-SFP30 installed or with an HDCU3500/
HDCU5000 which has HKCU-SFP50 installed.
5) Requires the SKC-IP45AF Networked Media Interface Kit and an
SFP+ module to use IP output.
For system camera operation, first check that the software and
ROM version of this unit, PMW-F55, F65, F65 Adaptor,
CA4000, HDC4300, and HDC-P43 support this function.
Note
