www.segway.com

Original instructions

CE.04.00.1025.00-A

XXXX

Ninebot eKickScooter

Product Manual

Manuel du produit

Produkthandbuch

Manuale del prodotto

Manual del producto

Instrukcja obsługi

Producthandleiding

Manual do produto

Raccolta Carta

The manufacturer reserves the right to make changes to the product, release rmware updates, and update this manual at any time. Visit www.segway.com or

check the Segway-Ninebot app to download the latest user materials. You must install the app, activate your KickScooter, and obtain the latest updates and

safety instructions.

Le fabricant se réserve le droit d'apporter des modications au produit, de publier des mises à jour du rmware et de mettre à jour ce manuel à tout moment.

Visitez www.segway.com ou consultez l'application Segway-Ninebot pour télécharger les derniers contenus destinés à l'utilisateur. Vous devez installer

l'application, activer votre Kickscooter et obtenir les dernières mises à jour et consignes de sécurité.

Der Hersteller behält sich das Recht vor, jederzeit Änderungen am Produkt vorzunehmen, Firmware-Updates zu veröentlichen und dieses Handbuch zu

aktualisieren. Besuchen Sie www.segway.com oder schauen Sie in der Segway-Ninebot-App nach, um die neuesten Benutzermaterialien herunterzuladen. Sie

müssen die App installieren, Ihren KickScooter aktivieren und die neuesten Aktualisierungen und Sicherheitsanweisungen erhalten.

Il produttore si riserva il diritto di apportare modiche al prodotto, rilasciare aggiornamenti del rmware e aggiornare il presente manuale in qualsiasi

momento. Visitare il sito www.segway.com o controllare l'app Segway-Ninebot per scaricare i materiali più recenti rivolti agli utenti. È necessario installare

l'app, attivare il KickScooter e ottenere gli ultimi aggiornamenti e le istruzioni di sicurezza.

El fabricante se reserva el derecho de realizar cambios en el producto, fabricar actualizaciones de sus piezas y actualizar este manual en cualquier momento.

Visite www.segway.com o consulte la aplicación Segway-Ninebot para descargar los materiales más recientes para el usuario. Debe instalar la aplicación,

activar el KickScooter y obtener las últimas actualizaciones e instrucciones de seguridad.

Producent zastrzega sobie prawo do wprowadzania zmian w produkcie, aktualizacji oprogramowania wbudowanego oraz aktualizacji niniejszej instrukcji w

dowolnym momencie. Odwiedź witrynę www.segway.com lub otwórz aplikację Segway-Ninebot, aby pobrać najnowsze materiały dla użytkownika. Musisz

zainstalować aplikację, aktywować hulajnogę KickScooter, a także uzyskać najnowsze aktualizacje i instrukcje dotyczące bezpieczeństwa.

De fabrikant behoudt zich het recht voor om op elk moment wijzigingen aan het product aan te brengen, rmware-updates uit te brengen en deze

handleiding bij te werken. Ga naar www.segway.com of bekijk de Segway-Ninebot-app om het nieuwste gebruikersmateriaal te downloaden. U moet de app

installeren, uw KickScooter activeren en de nieuwste updates en veiligheidsinstructies verkrijgen.

O fabricante reserva-se o direito de fazer alterações no produto, lançar atualizações de rmware e atualizar este manual a qualquer momento. Visite

www.segway.com ou verique a aplicação Segway-Ninebot para descarregar os materiais de utilizador mais recentes. Deve instalar a aplicação, ativar a sua

KickScooter e obter as últimas atualizações e instruções de segurança.

E N

F R

D E

I T

E S

P L

N L

P T

EN The pictures shown are for illustration purposes only. The actual product may vary.

FR Les images sont présentées à titre indicatif uniquement. Le produit réel peut varier.

DE Die gezeigten Abbildungen dienen nur zur Veranschaulichung. Das tatsächliche Produkt kann davon abweichen.

IT Le immagini mostrate sono solo a scopo illustrativo. Il prodotto eettivo può subire variazioni.

ES Las imágenes que se muestran son solo para nes ilustrativos. El producto real puede variar.

P L Przedstawione obrazy służą wyłącznie do celów ilustracyjnych. Faktyczny produkt może wyglądać inaczej.

N L De getoonde foto's zijn alleen ter illustratie. Het werkelijke product kan variëren.

PT As imagens apresentadas são meramente ilustrativas. O produto real pode variar.

印刷

Power Button: Press the button to power on the scooter; press and hold the button for 2 seconds to power it o. When the scooter is on, press the

button to turn on/o the headlight and the tail light, and press twice to switch between the speed modes.

Speedometer: It displays the current speed of the scooter, as well as error codes.

Walk Mode: The headlight and tail light are always on and can't be turned o.

Speed Mode: There are 3 modes available. The top speed is as follows:

* Ranges of Speed Modes: Tested while riding with a full battery, 75 ± 5 kg (165 ± 11 lbs) load, 25 ±5°C (77 ± 41 °F), at the max. speed of each speed

mode on average on pavement.

Left Directioin Indicator: When this icon blinks, it indicates that the direction indicators on the left side are turned on.

Right Directioin Indicator: When this icon blinks, it indicates that the direction indicators on the right side are turned on.

Error Notication: It indicates that the scooter has detected an error.

Temperature Warning: It indicates that the battery temperature has reached 55°C (131°F) or is below 0°C (32°F).

* At this point, the scooter cannot accelerate normally and may not be charged. Do not use until the temperature has reverted to the normal range.

Bluetooth: It indicates that the scooter has been successfully connected to the mobile device.

Battery Level: The total battery power equals 5 bars.

* The battery power is very low when the rst battery bar is red. Please charge your scooter immediately.

Locking Reminder: When the icon lights up, it means the scooter is locked. If abnormal movements are detected, the scooter will start beeping and

the tail light will falsh.

Diagram

EN EN

Dashboard & Power Button

Speedometer

Temperature Warning

Locking Reminder

Bluetooth

Speed Mode

Walk Mode

Headlight

Error Notication

Battery Level

Power Button

Model

Mode E2 II Speed limit E2 Plus II Speed limit

15 km/h (9.3 mph)

20 km/h (12.4 mph)

15 km/h (9.3 mph)

20 km/h (12.4 mph)

25 km/h (15.5 mph)

E2 II Ranges*

25 km (15.5 miles)

20 km (12.4 miles)

E2 Plus II Ranges*

25 km (15.5 miles)

20 km (12.4 miles)

D (Standard mode)

E (Energy-saving mode)

S (Sport mode)

Bell

Handlebar

Electronic Throttle

Direction Indicator Switch

Left Direction Indicator

Right Direction Indicator

Left Direction Indicator

Right Direction Indicator

Snap Hook

Dashboard

Brake Lever

Headlight

Stem

Safety Button

Returning markFolding Mechanism

Quick-release Lever

Front Shock Absorber

Front Fender

Hub Motor

Charge Port

Footboard

Buckle

Rear Fender

Drum Brake

Tail Light &

Rear Reector

Side Reector

Front Reector

Kickstand

Battery Compartment

Power Button

License

Plate Holder

01 02

Approx. 20 km/h (12.4 mph)

Approx. 20 km (12.4 miles)

Approx. 12%

Mostly smooth roads or normal asphalt, tarmac roads

-10–40°C (14–104°F)

-10–50°C (14–122°F)

IPX4

Approx. 7.5 h

EN EN

This product is certied to ANSI/CAN/UL-2272 by TUV Rheinland.

The battery complies with UN/DOT 38.3.

The battery complies with ANSI/CAN/UL-2271.

European Union Compliance Statement

Important WEEE information

This symbol on the product or on its packaging indicates that used electrical and electronic products should not be mixed with

unsorted municipal waste. For proper treatment, it is your responsibility to dispose of your waste equipment by arranging to

return it to designated collection points.

Disposing of this product correctly will help save valuable resources and prevent any potential negative eects on human health

and the environment, which could otherwise arise from inappropriate waste handling.

Penalties may be applicable for incorrect disposal of this waste, in accordance with your national legislation.

Please contact your local authority for further details of your nearest designated collection point.

Battery recycling information for Users

This symbol means that batteries and accumulators, at their end-of-life, should not be mixed with unsorted municipal waste.Your

participation is an impor tant part of the eort to minimize the impact of batteries and accumulators on the environment and on

human health. For proper recycling you can return this product or the batteries or accumulators it contains to your supplier or to

a designated collection point.

Disposing of this product correctly will help save valuable resources and prevent any potential negative eects on human health

and the environment, which could otherwise arise from inappropriate waste handling.

Penalties may be applicable for incorrect disposal of this waste, in accordance with your national legislation.

there are separate collection systems for used batteries and accumulators.

Please, dispose of batteries and accumulators correctly at your local community waste collection/recycling center.

Radio Equipment Directive

Ninebot (Changzhou) Tech Co., Ltd. hereby declares that the product listed in this section comply with the essential requirements

and other relevant provisions of the Radio Equipment Directive 2014/53/EU.

Restriction of the use of certain hazardous substances (RoHS) Directive

Ninebot (Changzhou) Tech Co., Ltd. hereby declares the whole produc t including parts (cables, cords, and so on) meets the

requirements of RoHS Directive 2011/65/EU and amendment Commission Delegated Directive (EU) 2015/863 on the restriction of

the use of certain hazardous substances in electrical and electronic equipment ("RoHS recast" or "RoHS 2.0").

Certications

Specications

Approx. 1081 x 475 x 1177 mm

(42.6 x 18.7 x 46.3 in)

Approx. 1081 x 475 x 548 mm (42.6 x

18.7 x 21.6 in)

Approx. 1081 x 475 x 1177 mm

(42.6 x 18.7 x 46.3 in)

Approx. 1081 x 475 x 548 mm

(42.6 x 18.7 x 21.6 in)

Approx. 16.8 kg (37.0 lbs)

Product

Rider

Machine

Battery

Motor

Charger

Ninebot eKickScooter E2 II

Ninebot eKickScooter E2 Plus II

051401DD

Item Parameter

Name

Model

Length × Width × Height

Folded: Length × Width × Height

Max. Payload

Recommended Age

Required Height

Max. Speed

Range at Max. Speed [1]

Max. Slope

Traversable Terrain

Operating Temperature

Storage Temperature

IP Rating

Duration of Charging

Nominal Voltage

Max. Charging Voltage

Charging Temperature

Nominal Energy

Nominal Capacity

Battery Management System

Output Power

Input Voltage

Max. Output Voltage

Rated Output

Tires

Direction Indicators

8.1-inch inner hollow shock-absorbing tires

36.3 W 100-240

V~ 50-60 Hz

25.2 V

24.2 V 1.5 A

Max. power 0.45 kW, 450 W

Model NBW25D201D5N-EU

Front and rear direction indicators

Nominal Power 0.25 kW, 250 W

21.6 V

25.2 V

0°C–44°C (32–111°F)

220 Wh

10.2 Ah

Protection against overvoltage/undervoltage/short circuit/overcur-

rent/over temperature

90 kg (198 lbs)

14–60 years old

130–190 cm (4'3''–6'2'')

[1]: Range at Max. Speed: tested while riding with a full battery, 75 ± 5 kg (165 ± 11 lbs) load, 25 ± 5°C (77 ± 41 °F), at the max. speed on average on pavement.

* Some of the factors that aect range include speed, load, number of starts and stops, ambient temperature, etc.

Tire

Other

051402EE

Approx. 16.2 kg ( 35.7 lbs)Net Weight

Approx. 25 km/h (15.5 mph)

0.3 kW, 300 W

0.50 kW, 500 W
