Seite 1/37
Ninebot eKickScooter
CE.04.00.1040.00-A
XXXX
Product Manual
Manuel du produit
Produkthandbuch
Manuale del prodotto
Manual del producto
Instrukcja obsƂugi
Producthandleiding
Manual do produto
EN
FR
DE
IT
ES
PL
NL
PT
Power Button & Vehicle Status Display
Diagram
1
Power Button
Speed Modes
Power Level
Press the button to power on the scooter;
When the scooter is on, press once to switch speed modes, triple press to turn on/off ambient
light, and press and hold the button for 2 seconds to power it off.
(Vehicle will turn off automatically 5 min after being idle in on status.)
D (Standard mode): Max. Speed 12 km/h (7.5 mph)
S (Sport mode): Max. Speed 16 km/h (9.9 mph)
E (Power-assisting mode):Max. Speed 16 km/h (9.9 mph)
The total battery power equals 4 bars.
* When the battery power is lower than 15%, the ïŹrst battery bar will ïŹ‚ash red. Please charge
your scooter immediately.
* When the battery power is lower than 10%, the ïŹrst battery bar will ïŹ‚ash red with the buzzer
ringing.
Item Description
Handlebar
Electronic Throttle
Brake Lever
Stem
Front Fork
Front Mudguard
Clamp
Shrapnel Push Button
Wheel Motor
ReïŹ‚ecting Sticker
Charge Port
Footboard
Drum Brake
Rear Mudguard
ReïŹ‚ecting StickerKickstand
Battery Compartment
Power Button
Vehicle Status Display
Ambient Light
EN
Approx. 856×400×950 mm (33.7×15.7×37.4 in)
SpeciïŹcations
2
Product Info
Riding
Requirements
Vehicle
Performance
Battery Pack
Motor
Charger
Ninebot eKickScooter C2 Lite
100501E
Item Parameter
Name
Model
L × W × H
Net Weight
Payload Capacity
Recommended Age
Required Height
Max. Speed
Riding Time[1]
Range at Max. Speed[2]
Max. Slope
Traversable Terrain
Operating Temperature
Ambient Temperature For Storage
IP Rating
Charging Duration
Nominal Voltage
Max. Charging Voltage
Nominal Energy
Nominal Capacity
Charging Ambient Temperature
Battery Management System
Input Voltage
Max. Output Voltage
Nominal Output
Rated Output Power
Tire Type
[1]: Riding Time: Tested while riding with a full battery in D mode, 30 kg (66 lbs) load, 25±5°C (77±41°F), at the max. speed of D mode on average on range
testing equipment. : Range at Max. Speed: Tested while riding with a full battery, 30 kg (66 lbs) load, 25 ± 5°C (77 ± 41 °F), at the max. speed on average
[2]
on range testing equipment.
* Some of the factors that affect range include speed, load, number of starts and stops, ambient temperature, etc.
7-inch Rubber Tire
100—240 V~ 50—60 Hz
25.2 V
24 V 0.6A
14.4 W
Max. power 130 W
Nominal Power 120 W
21.6 V
25.2 V
56 Wh
2550 mAh
0—45°C (32—113°F)
Approx. 16 km/h (9.9 mph)
Approx. 70 min
Approx. 9 km (5.6 miles)
Approx. 5%
Mostly smooth roads or normal asphalt, tarmac roads
-10—40°C (14—104°F)
-10—50°C (14—122°F)
IPX4
Approx. 5.5 h
20—50 kg (44—110 lbs)
6—10 years
115—145 cm (3'77''—4'76'')
Tire
Model NBW25D200D6D01
Approx. 7.8 kg (17.2 lbs)
*Ranges of Speed Modes D (Standard mode): Approx. 14 km (8.7 miles) S (Sport mode): Approx. 9 km (5.6 miles)
*Tested while riding with a full battery, 30 kg (66 lbs) load, 25 ±5°C (77 ± 41 °F), at the max. speed of each speed
mode on average on range testing equipment.
Overcharge Protection, Overheat Protection, Overdischarge Protection, Short
Circuit Protection, and Overcurrent Protection
EN
